odometer VAUXHALL VIVARO 2014 Owner's Manual

Instruments and controls65AshtraysCaution
To be used only for ash and not forcombustible rubbish.
Portable ashtray
Ashtray container for mobile use in
the vehicle. To use, open cover.
Warning lights, gauges
and indicators
Speedometer
Indicates vehicle speed.
Maximum speed may be restricted by
a speed regulator. As a visible
indication of this, a warning label is
located on the instrument panel.
A warning buzzer will sound for
10 seconds if the vehicle briefly
exceeds the set limit.
Notice
Under certain conditions (e.g. steep
inclines) the vehicle speed may
exceed the set limit.
Odometer
Displays the recorded distance.
Trip odometer
The trip odometer appears below the
odometer and displays the distance
travelled since the last reset.
To reset, with the trip odometer
displayed, press and hold the button
on the end of the wiper lever for a few

74Instruments and controls
U illuminates yellow when the
system is on.
Cruise control, Speed limiter 3 104.Information displays
Driver Information Centre
Depending on vehicle configuration,
the following items appear in the
display:
■ Odometer, trip odometer 3 65
■ Fuel gauge 3 66
■ Engine oil level monitor 3 67
■ Service display 3 67
■ Transmission display 3 68
■ Vehicle messages 3 75
■ Trip computer 3 76
Triple-Info-Display
Displays time, outside temperature
and Infotainment system information.
■ Outside temperature 3 63
■ Clock 3 63
For further information, refer to the
Infotainment system manual.

78Instruments and controls
Interruption of power supply
If the power supply has been
interrupted or if the vehicle battery
voltage has dropped too low, the
values stored in the trip computer will be lost.Tachograph
The tachograph is operated as
described in the operating
instructions supplied. Observe
regulations regarding use.
When a tachograph is fitted the total
distance travelled is shown only on
the tachograph and not in the
odometer within the instrument
display.

168
I
Identification plate .....................150
Ignition switch positions ...............94
Immobiliser .................................. 27
Indicators ...................................... 65
Information displays...................... 74
Instrument panel fuse box .........129
Instrument panel illumination .....128
Instrument panel overview ........... 10
Instrument panel storage ..............55
Interior care ............................... 144
Interior lights ........................ 82, 127
Interior mirrors .............................. 29
Interruption of power supply ......100
Introduction .................................... 3
Isofix child restraint systems ........ 54
J Jump starting ............................. 139
K Keys ............................................. 18
Keys, locks ................................... 18
L
Lashing eyes ............................... 57
Light covers, misted...................... 82
Lighting ......................................... 79
Light switch .................................. 79
Load compartment ....................... 25Load compartment cover .............56
Load compartment lighting ..........82
Loading information .....................58
Load rails and hooks ...................57
Low fuel ....................................... 73
M Malfunction indicator light ............71
Manual adjustment ......................28
Manual anti-dazzle ......................29
Manual mode ............................... 99
Manual transmission .................... 96
Manual transmission automated . 97
Manual windows ..........................30
Messages ..................................... 75
Mirror adjustment ........................... 8
Mirrors .................................... 28, 29
Misted light covers .......................82
N
New vehicle running-in ................94
Number plate light .....................126
O Object detection systems ...........108
Octane rating .............................. 154
Odometer ..................................... 65
Oil ............................................... 117
Oil, engine .......................... 147, 152
Oil level ......................................... 67Oil pressure.................................. 73
Outside temperature ....................63
Overcab storage ..........................56
Overrun cut-off ............................. 95
P Parking .................................. 17, 95
Parking assist ............................ 108
Parking brake ............................ 102
Particulate filter ............................. 95
Performing work ........................116
Pollen filter ................................... 91
Power outlets ............................... 64
Power steering fluid ...................120
Power windows ............................ 30
Preheating ................................... 72
Puncture ..................................... 136
R Radio Frequency Identification (RFID) ..................................... 165
Radio remote control ...................18
Reading lights .............................. 83
Rear air conditioning system .......86
Rear doors ................................... 24
Rear fog light ............................... 73
Rear fog lights ............................. 82
Rear heating system .................... 86
Rear seats .................................... 36
Rear windows .............................. 30
