key VAUXHALL VIVARO 2014 Owner's Manual

Introduction.................................... 2
In brief ............................................ 6
Keys, doors and windows ............18
Seats, restraints ........................... 32
Storage ........................................ 55
Instruments and controls .............60
Lighting ........................................ 79
Climate control ............................. 84
Driving and operating ...................93
Vehicle care ............................... 115
Service and maintenance ..........146
Technical data ........................... 149
Customer information ................164
Index .......................................... 166Contents

6In briefIn briefInitial drive informationVehicle unlockingUnlocking with key
Turn the key in the driver's door lock.
Open the doors by pulling the
handles.
Unlocking with remote control
Press button c (or press and hold) to
unlock vehicle.
Radio remote control 3 18, Central
locking system 3 20, Load
compartment 3 25.

In brief17
Starting the engine
■ Turn key to position A
■ move the steering wheel slightly to release the steering wheel lock
■ operate clutch and brake
■ do not operate accelerator pedal
■ diesel engines: turn the key to position M for preheating and wait
until control indicator !
extinguishes in the Driver
Information Centre.
■ turn key to position D and release.
Starting the engine 3 94.
Parking
■ Always apply parking brake without
pushing the release button. Apply
as firmly as possible on a downhill
or uphill slope. Depress foot brake
at the same time to reduce
operating force.
■ Switch off the engine. Turn the ignition key to position St and
remove it. Turn the steering wheel
until the steering wheel lock is felt
to engage.
■ If the vehicle is on a level surface or
uphill slope, engage first gear
before switching off the ignition. On
an uphill slope, turn the front
wheels away from the kerb.
If the vehicle is on a downhill slope, engage reverse gear before
switching off the ignition. Turn the
front wheels towards the kerb.
■ Lock the vehicle and activate the anti-theft alarm system 3 26 with
button e on the remote control.■ Do not park the vehicle on an easily
ignitable surface. The high
temperature of the exhaust system
could ignite the surface.
■ Close the windows.
■ The engine cooling fans may run after the engine has been switchedoff 3 116.
■ After running at high engine speeds
or with high engine loads, operate
the engine briefly at a low load or
run in neutral for approx.
30 seconds before switching off, in
order to protect the turbocharger.
Keys, locks 3 18.
Laying the vehicle up for a long period
of time 3 115.

18Keys, doors and windowsKeys, doors and
windowsKeys, locks ................................... 18
Doors ........................................... 24
Vehicle security ............................ 25
Exterior mirrors ............................ 28
Interior mirrors ............................. 29
Windows ...................................... 29Keys, locks
Keys Replacement keys
The key number is specified on the
key or on a detachable tag.
The key number must be quoted
when ordering replacement keys as it
is a component of the immobiliser
system.
Locks 3 143.
Lock cylinders
Designed to free-wheel if they are forcefully rotated without the correct
key or if the correct key is not fully
inserted. To reset, turn cylinder with
the correct key until its slot is vertical, remove key and then re-insert it. If the
cylinder still free-wheels, turn the key through 180° and repeat operation.
Car Pass
The Car Pass contains security
related vehicle data and should
therefore be kept in a safe place.When the vehicle is taken to a
workshop, this vehicle data is needed in order to perform certain operations.
Radio remote control
Used to operate: ■ Central locking system
■ Anti-theft locking system
■ Anti-theft alarm system
Depending on model, the vehicle may use a 2 button or 3 button remote
control.

Keys, doors and windows19
The remote control has a range of
approx. 5 metres. It can be restricted
by external influences. The hazard
warning flashers confirm operation.
Handle with care, protect it from
moisture and high temperatures and
avoid unnecessary operation.
Fault If the central locking system cannot
be operated with the remote control,
it may be due to the following:
■ Range exceeded
■ Battery voltage too low
■ Frequent, repeated operation of the
remote control while not in range,
which will require reprogramming
by a workshop
■ Interference from higher-power radio waves from other sources
Unlocking 3 20.
Remote control battery
replacement
Replace the battery as soon as the
range reduces.
Batteries do not belong in household
waste. They must be disposed of at
an appropriate recycling collection
point.
2-button remote control
Open battery compartment by
inserting a coin into the slot and
twisting.
Replace the battery (battery type CR 2016), paying attention to the
installation position.
Reattach both halves of the cover,
ensuring they engage correctly.
3-button remote control
Remove screw and open battery
compartment by inserting a coin into
the slot and twisting.
Replace the battery (battery type
CR 2016), paying attention to the
installation position.
Reattach both halves of the cover,
ensuring they engage correctly.

20Keys, doors and windows
Replace screw and tighten.
Central locking system Unlocks and locks the front doors,
sliding side doors, load compartment
and fuel filler flap.
With the 3-button remote control, the
front doors and sliding side doors/
load compartment can be unlocked
and locked separately.
For safety reasons, the vehicle
cannot be locked if the key is in the
ignition switch.
Unlocking the vehicle
Unlocking with key
Turn key in driver's door lock towards the front of the vehicle.Unlocking with 2-button remote
control
Depending on vehicle configuration:
■ Press button c: All doors and the
load compartment are unlocked.
■ Press button c once to unlock the
front doors, and press c twice to
unlock all doors and the load
compartment.
Unlocking with 3-button remote
control
Depending on vehicle configuration:
■ Press button c: Front doors are
unlocked. Press and hold button c:
All doors and the load compartment are unlocked.

Keys, doors and windows21
■Press button c: Front doors and
sliding side doors are unlocked.
Press and hold button c: All doors
and the load compartment are
unlocked.
■ Press button c: Driver's door only is
unlocked. Press and hold c: All
doors and the load compartment
are unlocked.
If no door is opened within approx. 30 seconds after the vehicle has been unlocked, the vehicle is re-locked
automatically.
Locking the vehicle Close doors, load compartment and
fuel filler flap. If the doors are not
closed properly, the central locking
system will not work.
Locking with key
Turn key in driver's door lock towards
the rear of the vehicle.Locking with 2-button remote control
Depending on vehicle configuration:
■ Press button e briefly: All doors and
the load compartment are locked.
■ Press button e once to lock the front
doors, and press e twice to lock all
doors and the load compartment.
Locking with 3-button remote control
Press button e briefly: All doors and
the load compartment are locked.
Notice
Where fitted, alarm monitoring of the passenger compartment 3 26 is
switched off by pressing and holding
button e (which is confirmed by an
audible signal).
If this was done unintentionally,
unlock the doors again and press
button e briefly to lock the vehicle.

22Keys, doors and windows
Load compartmentLocking and unlocking load
compartment with 2-button remote
control
Depending on vehicle configuration:
■ Press button e or c once: Load
compartment is locked or unlocked.
■ Press button e or c twice: Load
compartment is locked or unlocked.
Locking and unlocking load
compartment with 3-button remote
control
Depending on vehicle configuration:
■ Press button G: Load
compartment is locked or unlocked.
■ Press button G: Load
compartment and sliding side doors
are locked or unlocked.
Central locking switch Locks or unlocks the doors, load
compartment and fuel filler flap from
the passenger compartment.
Press switch:
e=locky=unlock
Slam door locks
Certain models feature load
compartment locks which are isolated for added security.
With slam door locks, while the doors can be locked and unlocked using the
remote control, the load compartment
must be manually opened by turning
the key in the lock.

Keys, doors and windows23Automatic locking
Automatic locking after driving
off This security feature can be
configured to automatically lock the
doors, load compartment and fuel
filler flap as soon as the vehicle is
driven.
Activation
With the ignition switched on, press and hold e on the central locking
switch for approx. 5 seconds. An audible signal confirms activation.
Deactivation
With the ignition switched on, press and hold y on the central locking
switch for approx. 5 seconds. An audible signal confirms deactivation.Child locks9 Warning
Use the child locks whenever
children are occupying the rear
seats.
The child safety lock for the sliding
door is located on its rearward facing
edge.
Using a key or suitable screwdriver,
turn the child lock in the rear door to
the horizontal position. The door
cannot be opened from the inside. For
deactivation, turn the child lock to the vertical position.

24Keys, doors and windowsDoors
Sliding door
Ensure the side door is fully closed
and secure before driving the vehicle.
The door can be locked from inside
the vehicle with the interior lock
switch.
Rear doors
To open the left hand rear door pull the outside handle. The door is
opened from inside the vehicle by
pulling the interior handle.
The right hand rear door is released
using the lever.
9 Warning
The rear lights may be obscured if
the rear doors are open and the
vehicle is parked on the roadside.
Make other road users aware of the vehicle, by using a warning
triangle or other equipment
specified in the road traffic
regulations.
The doors are retained in the 90º
position by locking stays. To open the
doors to 180º or further, pull the door
release handles and swing open to
the desired position.
9 Warning
Ensure extended opening doors
are secured when fully opened.
Opened doors may slam closed due to the force of the wind!
Always close the right hand doorbefore the left hand door.
