Vehicle care131Vehicle tools
Tools
The jack, adapters, ratchet, torx key,
hub cap hook, towing eye and spare
wheel security tool are contained in a
unit, stowed under the driver's seat.
Spare wheel 3 138.
Vehicles with a tyre repair kit: The
towing eye and torx key are stored
within the tyre repair kit case, stowed
under the front seat.
Tyre repair kit 3 133.
Wheels and tyres
Tyre condition, wheel condition
Drive over edges slowly and at right
angles if possible. Driving over sharp
edges can cause tyre and wheel
damage. Do not trap tyres on the kerb when parking.
Regularly check the wheels for
damage. Seek the assistance of a
workshop in the event of damage or
unusual wear.
Tyres
Factory-fitted tyres are matched to the chassis and offer optimum driving comfort and safety.
Winter tyres Winter tyres improve driving safety attemperatures below 7 °C and shouldtherefore be fitted on all wheels.In accordance with country-specific
regulations, a notice indicating the
maximum permissible speed for the
tyres must be affixed within the
driver's field of vision.
Tyre designations E.g. 195/65 R 16 C 88 Q195=Tyre width, mm65=Cross-section ratio (tyre
height to tyre width), %R=Belt type: RadialRF=Type: RunFlat16=Wheel diameter, inchesC=Cargo or commercial use88=Load index e.g. 88 is
equivalent to 567 kgQ=Speed code letter
Speed code letter:
Q=up to 100 mphS=up to 112 mphT=up to 118 mphH=up to 130 mphV=up to 150 mphW=up to 168 mph

160Technical dataVehicle dimensionsTypeVanCombi/Tour9)Platform cabWheelbaseShortLongShortLongLongLength [mm]47825182478251825130Width without exterior mirrors [mm]19041904190419041904Width with two exterior mirrors [mm]22322232223222322232/243410)Height - unladen (without antenna) [mm] 11)
Standard roof
19681968196819681981
High roof24922492---Wheelbase [mm]30983498309834983498Track width [mm]
Front
16151615161516151615
Rear163016301630163016309) Tour available with short wheel base only.
10) With wide arm exterior mirrors.
11) Vehicle height without body conversion.

Technical data161
Loadspace dimensions
Wheelbase
VanShortLongRoof heightStandardHighStandardHighMaximum rear door aperture height [mm]1335181813351818Rear door aperture width (at floor) [mm]1390139013901390Maximum load area height [mm]1387191313871913Maximum load area width [mm]1690169016901690Width between wheel arches [mm]1268126812681268Maximum load floor length [mm]2400240028002800Loading height unladen [mm]543547542548Sliding side door aperture width [mm]1000100010001000Sliding side door aperture height [mm]1285128512851285
