Vehicle care179The instrument cluster and the
displays should only be cleaned using
a soft damp cloth. If necessary use a
weak soap solution.
Clean fabric upholstery with a
vacuum cleaner and brush. Remove
stains with an upholstery cleaner.
Clothing fabrics may not be
colourfast. This could cause visible
discolourations, especially on light- coloured upholstery. Removable
stains and discolourations should be
cleaned as soon as possible.
Clean seat belts with lukewarm water or interior cleaner.Caution
Close Velcro fasteners as open
Velcro fasteners on clothing could damage seat upholstery.
The same applies to clothing with
sharp-edged objects, like zips or
belts or studded jeans.
Plastic and rubber parts
Plastic and rubber parts can be
cleaned with the same cleaner as
used to clean the body. Use interior cleaner if necessary. Do not use any
other agent. Avoid solvents and petrol in particular. Do not use high-
pressure jet cleaners.
Page 182 of 209

180Service and maintenanceService and
maintenanceGeneral information ...................180
Service information ..................180
Recommended fluids, lubricants
and parts .................................... 181
Recommended fluids and lubricants ................................ 181General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for the vehicle is available at
the workshop.
Service display 3 80.
Engine identification 3 184.
European service intervals Maintenance of your vehicle is
required every 25,000 miles or after 2 years, whichever occurs first,
unless otherwise indicated by the
service display.
A shorter service interval can be valid for severe driving behaviour, e.g. for
taxis and police vehicles.
The European service intervals are
valid for the following countries:Andorra, Austria, Belgium, Croatia,
Czech Republic, Denmark, Estonia,
Finland, France, Germany, Greece,
Hungary, Iceland, Ireland, Italy,
Latvia, Liechtenstein, Lithuania,
Luxembourg, Netherlands, Norway,
Poland, Portugal, Slovakia, Slovenia,
Spain, Sweden, Switzerland, United
Kingdom.
Confirmations Confirmation of service is recorded inthe Service and Warranty Booklet.
The date and mileage is completed
with the stamp and signature of the
servicing workshop.
Make sure that the Service and
Warranty Booklet is completed
correctly as continuous proof of
service is essential if any warranty or goodwill claims are to be met, and is
also a benefit when selling the
vehicle.
Service display The service interval is based on
several parameters depending on
usage.
Page 183 of 209

Service and maintenance181The service display, located in the
Driver Information Centre (DIC),
indicates when the next service is
due. Seek the assistance of a
workshop.
Service display 3 80.Recommended fluids,
lubricants and parts
Recommended fluids andlubricants
Only use products that meet the
recommended specifications.
Damage resulting from the use of
products not in line with these
specifications will not be covered by
the warranty.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
aging control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.
Dexos is the newest engine oil quality
that provides optimum protection for petrol and diesel engines. If it is
unavailable, engine oils of other listed qualities must be used.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 185.
Topping up engine oil
Engine oils of different manufacturers
and brands can be mixed as long as
they comply with the required engine
oil quality and viscosity.
Use of engine oil with only
ACEA A1/B1 or only A5/B5 quality is
prohibited, since it can cause long-
term engine damage under certain
operating conditions.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 185.
Page 184 of 209

182Service and maintenanceAdditional engine oil additives
The use of additional engine oil
additives could cause damage and
invalidate the warranty.
Engine oil viscosity grades
The SAE viscosity grade gives
information of the thickness of the oil.
Multigrade oil is indicated by two
figures, e.g. SAE 5W-30. The first
figure, followed by a W, indicates the
low temperature viscosity and the
second figure the high temperature viscosity.
Select the appropriate viscosity grade
depending on the minimum ambient
temperature 3 185.
All of the recommended viscosity
grades are suitable for high ambient
temperatures.
Coolant and antifreeze
Use only silicate-free long life coolant (LLC) antifreeze approved for the
vehicle. Consult a workshop.
The system is factory filled with
coolant designed for excellent
corrosion protection and frost
protection down to approx. -28 °C.This concentration should be
maintained all year round. The use of additional coolant additives that
intend to give additional corrosion
protection or seal against minor leaks
can cause function problems. Liability
for consequences resulting from the
use of additional coolant additives will be rejected.
Brake fluid
Over time, brake fluid absorbs
moisture which will reduce braking
effectiveness. The brake fluid should
therefore be replaced at the specified interval.
AdBlue Only use AdBlue to reduce the
nitrogen oxides in the exhaust
emission 3 121.
Page 185 of 209

Technical data183Technical dataVehicle identification..................183
Vehicle Identification Number ..183
Identification plate ...................184
Engine identification ................184
Vehicle data ............................... 185
Recommended fluids and lubricants ................................ 185
Engine data ............................. 186
Vehicle weight ......................... 187
Vehicle dimensions .................190
Capacities ................................ 195
Tyre pressures ........................ 196Vehicle identification
Vehicle IdentificationNumber
The Vehicle Identification Number is
visible through the windscreen.
The VIN is also displayed behind a
removable plastic cover on the right-
hand side door step.
Page 186 of 209

184Technical dataIdentification plate
The identification plate is located on
the right-hand door pillar.
Information on identification plate:1:Manufacturer2:Type approval number3:Vehicle Identification Number4:Permissible gross vehicle weight
rating in kg5:Permissible gross combination
weight in kg6:Maximum permissible front axle
load in kg7:Maximum permissible rear axle
load in kg8:Engine coding9:Vehicle-specific or country
specific data
Notice
The VIN plate on your vehicle may
differ from the illustration shown.
The combined total of front and rear
axle loads must not exceed the
permissible gross vehicle weight. For
example, if the front axle is bearing its
maximum permissible load, the rear
axle can only bear a load that is equal
to the gross vehicle weight minus the front axle load.
The technical data is determined in
accordance with European
Community standards. We reserve
the right to make modifications.
Specifications in the vehicle
documents always have priority over
those given in this manual.
Engine identification
The technical data tables show the
engine identifier code. Engine data
3 186.
To identify the respective engine,
refer to the engine power in the EEC
Certificate of Conformity provided
with your vehicle or other national
registration documents.
It is also possible, using the Vehicle
Identification Number (VIN), to
determine the engine type that is
installed in your vehicle. For further
information consult a workshop.
Page 187 of 209

Technical data185Vehicle data
Recommended fluids and lubricants
Required engine oil qualityEngine oil quality: Europedexos 2✔
For countries with International
service interval 3 180, you may use
the oil qualities listed below:
Engine oil quality: Internationaldexos 2✔GM-LL-A/B-025✔ACEA C3
diesel engines with DPF✔ACEA A3/B4
diesel engines without DPF✔Engine oil viscosity gradesAmbient temperaturedown to -25 °CSAE 5W-30 or
SAE 5W-40below -25 °CSAE 0W-30 or
SAE 0W-40
Page 188 of 209

186Technical dataEngine dataSales designation1.6 CDTi 901.6 CDTi 1151.6 CDTi BiTurbo 1201.6 CDTi BiTurbo 140Engine identifier codeR9M 408R9M 408R9M 450R9M 450Number of cylinders4444Piston displacement [cm3
]1598159815981598Engine power [kW] (PS)66 (90)85 (115)88 (120)103 (140)at rpm3500350035003500Torque [Nm]260300320340at rpm1500175015001750Fuel typeDieselDieselDieselDiesel
Page 189 of 209

Technical data187Vehicle weightKerb weight, basic model
Optional equipment and accessories increase the kerb weight.
Loading information 3 71.ModelEngineWheelbaseRoofPayload ClassGross Vehicle Weight ratingKerb weight 1)2)VanR9ML1H1100027001661120029001661H2120029001760-1771L2H1120029001691-1695H21200290017751)
Kerb weight and gross vehicle weight increase on models fitted with bad road equipment package - refer to VIN plate.
2) Minimum vehicle weight according to Type Approval, including all fluids, vehicle tools and a 90% fuel load. Excludes the weight of
the driver and deletable options, e.g. spare wheel, bulkhead and sliding side load door. Final weight may vary according to the
specification of the vehicle, e.g. options, deleted options and accessories.
Page 190 of 209

188Technical dataModelEngineWheelbaseRoofPayload ClassGross Vehicle Weight ratingKerb weight1)2)CombiR9ML1H1100027001901120029001901L2H11200290019011)
Kerb weight and gross vehicle weight increase on models fitted with bad road equipment package - refer to VIN plate.
2) Minimum vehicle weight according to Type Approval, including all fluids, vehicle tools and a 90% fuel load. Excludes the weight of
the driver and deletable options, e.g. spare wheel, bulkhead and sliding side load door. Final weight may vary according to the
specification of the vehicle, e.g. options, deleted options and accessories.ModelEngineWheelbaseRoofPayload ClassGross Vehicle Weight ratingKerb weight 1)2)Platform cabR9ML2H11200290015501)
Kerb weight and gross vehicle weight increase on models fitted with bad road equipment package - refer to VIN plate.
2) Minimum vehicle weight according to Type Approval, including all fluids, vehicle tools and a 90% fuel load. Excludes the weight of
the driver and deletable options, e.g. spare wheel, bulkhead and sliding side load door. Final weight may vary according to the
specification of the vehicle, e.g. options, deleted options and accessories.
