200Vehicle careCaution
Drive slowly. Do not drive jerkily.
Excessive tractive force can
damage the vehicle.
Trailer hitch 3 162.
Appearance care
Exterior care
Locks The locks are lubricated at the factoryusing a high quality lock cylinder
grease. Use de-icing agent only when absolutely necessary, as this has adegreasing effect and impairs lockfunction. After using a de-icing agent,
have the locks regreased by a
workshop.
Washing
The paintwork of your vehicle is
exposed to environmental influences, therefore wash your vehicle regularly.
When using automatic vehicle
washes, we recommend one with
textile brushes and a programme
without wax additives. Restrictions for
filmed or matt painted body parts or
decor tapes, see "Polishing and
waxing".
Never use a steam-jet or high-
pressure jet cleaner for the engine
compartment.Wax painted parts of the vehicle
regularly.
Bird droppings, dead insects, resin,
pollen and the like should be cleaned off immediately, as they contain
aggressive constituents which can
cause paint damage.
If using a vehicle wash, comply with
the vehicle wash manufacturer's
instructions. The windscreen wipers
and rear window wiper must be
switched off and the exterior mirrors
must be folded in. Remove antenna
and external accessories such as roof
racks etc.
If you wash your vehicle by hand,
make sure that the insides of the
wheel housings are also thoroughly
rinsed out.
Clean edges and folds on opened
doors and the bonnet as well as the
areas they cover.
Clean bright metal mouldings with a
cleaning solution approved for
aluminium, to avoid damage.

Vehicle care201Caution
Always use a cleaning agent with
a pH value of four to nine.
Do not use cleaning agents on hot surfaces.
Thoroughly rinse and leather-off the
vehicle. Rinse leather frequently. Use
separate leathers for painted and
glass surfaces: remnants of wax on
the windows will impair vision.
Have the door hinges of all doors
greased by a workshop.
Exterior lights
Headlight and other light covers are
made of plastic. Do not use any
abrasive or caustic agents, do not use an ice scraper, and do not clean them
dry.
Polishing and waxing
Wax the vehicle regularly (at the
latest when water no longer beads).
Otherwise, the paintwork will dry out.
Polishing is necessary only if the paint
has become dull or if solid deposits
have become attached to it.
Paintwork polish with silicone forms a
protective film, making waxing
unnecessary.
Unpainted plastic body parts must not be treated with wax or polishing
agents.
Matt filmed body parts or decor tapes must not be polished, to avoid
gleaming. Do not use hot wax
programmes in automatic car washes if the vehicle is equipped with these
parts.
Matt painted decor parts, e.g. mirror
housing cover, must not be polished. Otherwise these parts would become
agleam or the colour would be
dissolved.
Windows and wiper blades
Switch off wipers before handling in
their movement areas.
Use a soft lint-free cloth or chamois
leather together with window cleaner
and insect remover.When cleaning the rear window from
inside, always wipe in parallel to the
heating element to prevent damage.
For mechanical removal of ice, use a
sharp-edged ice scraper. Press the
scraper firmly against the glass so
that no dirt can get under it and
scratch the glass.
Remove dirt residues from smearing
wiper blades by using a soft cloth and window cleaner. Also make sure to
remove any residues such as wax,
insect residues and similar from the
window.
Ice residues, pollution and continuous wiping on dry windows will damage or
even destroy the wiper blades.
Wheels and tyres Do not use high-pressure jet
cleaners.
Clean rims with a pH-neutral wheel
cleaner.
Rims are painted and can be treated
with the same agents as the body.

224F
Fault messages .......................... 102
First aid kit ................................... 80
Fixed air vents ........................... 128
Fog lights .................................... 111
Fog tail light ............................... 179
Folding centre seatback ...............73
Folding front centre passenger seat ........................................... 48
Folding mirrors ............................. 39
Foot well lights ............................ 112
Front airbag system .....................61
Front courtesy lights ...................112
Front door pockets........................ 74
Front fog lights ...........101, 111, 176
Front reading light....................... 114
Front seats.................................... 45
Front storage ................................ 73
Front turn lights .......................... 176
Fuel cut-off system .....................134
Fuel economy gauge ....................91
Fuel economy mode ...................100
Fuel economy rating ...........102, 104
Fuel for diesel engines ..............159
Fuel gauge ................................... 90 Fuel tank ..................................... 212
Fuse box ..................................... 182
Fuses ......................................... 181G
Gauges ......................................... 89
Gear shifting ................................. 98
General information ...................162
Glovebox ..................................... 72
Glovebox cooler ......................... 128
Glove box lighting .......................114
Grab handles ................................ 76
H Hand brake ................................. 146
Hand brake - see Parking brake. 147
Hazard warning flashers ............111
Headlight flash ........................... 109
Headlight range adjustment ......109
Headlights .................. 108, 109, 175
Headlights when driving abroad 110
Head restraint adjustment .............8
Head restraints ............................ 44
Heated exterior mirrors .................15
Heated mirrors ............................. 40
Heated rear window ...............15, 43
Heating ........................................ 48
Heating and ventilation system . 116
Heat-reflecting windscreen ...........41
High beam ......................... 100, 109
Hill start assist ........................... 147
Horn ....................................... 14, 83I
Identification plate .....................207
Idle speed control .......................134
Ignition switch positions .............131
Immobiliser .................................. 38
Indicators ...................................... 89
Info Display ................................. 102
Information displays.................... 101
Infotainment system ...................102
Initial drive information.................... 6
Instrument cluster ........................89
Instrument panel fuse box .........182
Instrument panel illumination .....181
Instrument panel illumination control .................................... 112
Instrument panel overview ........... 10
Instrument panel storage ..............71
Instrument panel tray ....................71
Interior care ............................... 202
Interior lighting ............................ 112
Interior lights ...................... 112, 180
Interior mirrors .............................. 40
Introduction .................................... 3
ISOFIX .......................................... 64
J Jack ............................................ 185
Journey record............................ 104
Jump starting ............................. 197

225KKeys ............................................. 19
Keys, locks ................................... 19
L
Lashing eyes ............................... 77
Lashing straps .............................. 77
Laying up the vehicle ..........165, 171
LED spotlights ............................ 112
Light covers, misted.................... 112
Lighting ....................................... 108
Lighting features .........................114
Light switch ................................ 108
Load compartment ................33, 76
Load compartment cover .............77
Load compartment grille ...............79
Load compartment lighting .........114
Loading information .....................80
Load-through feature ....................74
Low fuel ..................................... 100
Luggage floor net .........................77
M
Malfunction indicator light ............97
Manual adjustment ......................39
Manual anti-dazzle ......................40
Manual transmission .................. 145
Maximum speed limiter............... 153
Messages ................................... 102
Mirror adjustment ........................... 8Mirrors .................................... 39, 40
Misted light covers .....................112
N New vehicle running-in ..............131
Number plate light .....................179
O
Object detection systems ...........154
Odometer ..................................... 90 Oil ............................................... 167
Oil, engine .................. 167, 204, 208
Oil pressure .................................. 99
Outside temperature ....................85
Overcab storage ..........................76
Overrun cut-off ........................... 135
P Parking ................................ 18, 138
Parking assist ............................ 154
Parking brake ............................ 147
Parking distance control .............154
Parking heater ............................ 122
Particulate filter ........................... 139
Pedals......................................... 130
Performing work ........................166
Phone controls.............................. 83
Phone holder ................................ 71
Power button ........................ 17, 131
Power outlets ............................... 87
Power steering fluid ....................169Power windows ............................ 42
Preheating ........................... 99, 133
Puncture ..................................... 194
R
Radio Frequency Identification (RFID) ..................................... 221
Radio remote control ...................20
REACH ....................................... 218
Reading lights ............................ 114
Rear air conditioning system .....121
Rear courtesy lights ....................112
Rear door manual lock .................24
Rear doors .............................. 24, 31
Rear fog light .....................101, 112
Rear heating system .................. 120
Rear parcel shelf .......................... 77
Rear seats ................................... 49
2nd row seats ............................ 49
3rd row seats............................. 49
Folding ...................................... 49
Installing .................................... 49
Rear seat access ......................49
Removing .................................. 49
Seat cushion adjustment ...........49
Rear seats lights .........................112
Rear view camera ...................... 157
Rear windows .............................. 42
Rear window wiper and washer ..85
