VAUXHALL ZAFIRA 2014 Repair Manual

Seats, restraints59
NEVER use a rearward-facing child
restraint on a seat protected by an
ACTIVE AIRBAG in front of it; DEATH or SERIOUS INJURY to the CHILDcan occur.
Beyond the warning required by
ECE R94.02, for safety reasons
never use a forward-facing child
restraint system on the passenger
seat with active front airbag.
9 Danger
Do not use a child restraint system
on the passenger seat with active
front airbag.
Front airbag system
The front airbag system consists of
one airbag in the steering wheel and
one in the instrument panel. These
can be identified by the word
AIRBAG .
Additionally there is a warning label
on the side of the instrument panel,
visible when the front passenger door
is open, or on the passenger's sun
visor.
The front airbag system is triggered in
the event of an accident of a certain
severity. The ignition must be on.

60Seats, restraints
The forward movement of the front
seat occupants is decelerated,
thereby considerably reducing the risk of injury to the upper body and
head.
9 Warning
Optimum protection is only
provided when the seat is in the
proper position 3 46.
Keep the area in which the airbag
inflates clear of obstructions.
Fit the seat belt correctly and
engage securely. Only then the
airbag is able to protect.
Side airbag system
The side airbag system consists of an
airbag in each front seat backrest.
This can be identified by the word
AIRBAG .
The side airbag system is triggered in the event of an accident of a certain
severity. The ignition must be on.
The risk of injury to the upper body
and pelvis in the event of a side-on
collision is considerably reduced.
9 Warning
Keep the area in which the airbag
inflates clear of obstructions.
Notice
Only use protective seat covers that have been approved for the vehicle.Be careful not to cover the airbags.

Seats, restraints61Curtain airbag system
The curtain airbag system consists ofan airbag in the roof frame on each
side. This can be identified by the
word AIRBAG on the roof pillar.
The curtain airbag system is triggered
in the event of an accident of a certain severity. The ignition must be on.
The risk of injury to the head in the
event of a side impact is considerably reduced.
The curtain airbag system does not
protect the third row of seats.
9 Warning
Keep the area in which the airbag
inflates clear of obstructions.
The hooks on the handles in the
roof frame are only suitable for
hanging up light articles of
clothing, without coat hangers. Do not keep any items in these
clothes.
Child restraints
Child restraint systems We recommend the Vauxhall childrestraint system which is tailored
specifically to the vehicle.
When a child restraint system is being
used, pay attention to the following
usage and installation instructions
and also those supplied with the child restraint system.
Always comply with local or national
regulations. In some countries, the
use of child restraint systems is
forbidden on certain seats.
Selecting the right system The rear seats are the most
convenient location to fasten a child
restraint system.
Children should travel facing
rearwards in the vehicle as long as
possible. This ensures that the child's
backbone, which is still very weak, is
under less strain in the event of an
accident.

62Seats, restraints
Suitable are restraint systems that
comply with ECE 44-03 or
ECE 44-04. Check local laws and
regulations for mandatory use of child restraint systems.
Never hold a child whilst travelling in
the vehicle. The child will become too
heavy to be held in the event of a
collision.
When transporting children, use the
child restraint systems suitable for the
child's weight.
Ensure that the child restraint system to be installed is compatible with the
vehicle type.
Ensure that the mounting location of
the child restraint system within the
vehicle is correct.
Allow children to enter and exit the vehicle only on the side facing away
from the traffic.
When the child restraint system is not in use, secure the seat with a seat beltor remove it from the vehicle.Notice
Do not affix anything on the child
restraint systems and do not cover
them with any other materials.
A child restraint system which has
been subjected to stress in an
accident must be replaced.

Seats, restraints63Child restraint installation locationsPermissible options for fitting a child restraint system
Weight and age class 1)
On front passenger
seatOn outboard
seats in the
second rowOn centre seat
in the second
rowOn the seats
in the third
rowGroup 0: up to 10 kg or approx. 10 months
Group 0+: up to 13 kg or approx. 2 yearsXU, +UXGroup I: 9 to 18 kg or approx. 8 months to 4 yearsXU, +, ++UUFGroup II: 15 to 25 kg or approx. 3 to 7 years
Group III: 22 to 36 kg or approx. 6 to 12 yearsXUUUFU=Universal suitability in conjunction with three-point seat belt.UF=Can be used universally for forward-facing child restraint systems in combination with a three-point seat belt.+=Vehicle seat available with ISOFIX attachments. When attaching using ISOFIX, only the ISOFIX child restraint
systems permitted for the vehicle may be used.++=Vehicle seat available with ISOFIX attachments. When attaching using ISOFIX and Top-tether , universally permitted
ISOFIX child restraint systems may be used.X=No child restraint system permitted in this weight class.1) We recommend the use of each system until the child reaches the upper weight limit.

64Seats, restraints
Permissible options for fitting an ISOFIX child restraint systemWeight classSize classFixtureOn front passenger
seatOn outboard seats
in the second rowOn centre seat in
the second rowOn the seats in
the third rowGroup 0: up to 10 kgEISO/R1XILXXGroup 0+: up to 13 kgEISO/R1XILXXDISO/R2XILXXCISO/R3XILXXGroup I: 9 to 18 kgDISO/R2XILXXCISO/R3XILXXBISO/F2XIL, IUFXXB1ISO/F2XXIL, IUFXXAISO/F3XIL, IUFXXIL=Suitable for particular ISOFIX restraint systems of the "specific-vehicle", "restricted" or "semi-universal" categories.
The ISOFIX restraint system must be approved for the specific vehicle type.IUF=Suitable for ISOFIX forward-facing child restraint systems of universal category approved for use in this weight class.X=No ISOFIX child restraint system approved in this weight class.

Seats, restraints65
ISOFIX size class and seat deviceA – ISO/F3=Forward-facing child restraint system for children of maximum size in the weight class 9 to 18 kg.B – ISO/F2=Forward-facing child restraint system for smaller children in the weight class 9 to 18 kg.B1 – ISO/F2X=Forward-facing child restraint system for smaller children in the weight class 9 to 18 kg.C – ISO/R3=Rear-facing child restraint system for children of maximum size in the weight class up to 18 kg.D – ISO/R2=Rear-facing child restraint system for smaller children in the weight class up to 18 kg.E – ISO/R1=Rear-facing child restraint system for young children in the weight class up to 13 kg.

66Seats, restraintsIsofix child restraint
systems
Fasten vehicle-approved ISOFIX
child restraint systems to the
mounting brackets. Specific vehicle
ISOFIX child restraint system
positions are marked in the table by
IL.
Top-tether child restraint
systems
Fasten Top-tether child restraint
systems to the fastening eyes of the
second row of seats. The strap must
run between the two guide rods of the
head restraint.
When using ISOFIX and Top-tether
for seat mounting, universally
permitted child restraint systems for
ISOFIX may be used.

Storage67StorageStorage compartments................67
Load compartment .......................69
Roof rack system .........................75
Loading information .....................75Storage compartments9Warning
Do not store heavy or sharp
objects in the storage
compartments. Otherwise, the
storage compartment lid could
open and vehicle occupants could be injured by objects being thrown
around in the event of hard
braking, a sudden change in
direction or an accident.
Glovebox
The glovebox features a pen holder.
The glovebox should be closed whilst driving.
Cupholders
Cupholders are located in the centre
console, in the doors and the rear side panelling.

68Storage
Additional cupholders are located in
the centre seat backrest when it is
folded down.
Sunglasses storage
Fold down and open.
Do not use for storing heavy objects.
Underseat storage
Lift at recessed edge and pull out.
Maximum load: 1.5 kg. To close, push in and engage.
