sport mode VAUXHALL ZAFIRA 2014 Owner's Manual

In brief11
1Light switch ........................ 108
Instrument illumination .......113
Rear fog light ....................... 112
Front fog lights ...................111
Headlight range
adjustment ......................... 109
2 Side air vents ...................... 122
3 Turn and lane-change
signals, headlight flash,
low beam and high beam ...111
Exit lighting .......................... 114
Parking lights ...................... 112
Cruise control ....................... 92
4 Steering wheel controls ........77
5 Horn ...................................... 78
Driver airbag ......................... 59
6 Instruments .......................... 83
7 Windscreen wiper,
windscreen washer
system, headlight washer
system .................................. 78
8 Centre air vents ................... 1229Left heated seat ....................49
Deflation detection system ..175
Tyre pressure monitoring
system ................................. 174
Ultrasonic parking assist ......89
Hazard warning flashers .....111
Central locking system ..........31
Sport mode ........................... 89
Right heated seat ..................49
10 Info-Display ........................... 93
Trip computer ...................... 102
Electronic climate control
system ................................. 119
11 Front passenger airbag .........59
12 Glovebox .............................. 67
13 Infotainment system ..............10
14 Climate control system ........ 11615Selector lever, manual
transmission ....................... 133
Manual transmission
automated ........................... 134
Automatic transmission .......128
16 Ashtray .................................. 82
17 Start/Stop button .................. 28
18 Accelerator pedal ................124
19 Ignition switch with
steering wheel lock .............125
Sensor panel for
emergency operation of
Open&Start system ..............28
20 Brake pedal ......................... 138
21 Clutch pedal ........................ 124
22 Steering wheel adjustment ...77
23 Bonnet release lever ...........153

In brief23Sport mode
Activate by pressing the SPORT
button.
The Sport mode is used to make
suspension and steering more direct.
The engine is more responsive to
throttle application. With manual
transmission automated and
automatic transmission, gear
changing is altered.
Sport mode 3 140.
FlexOrganizer
The side walls contain retaining
strips, where various components can be attached to divide the load
compartment or fasten loads.
The system consists of: ■ adapters
■ variable partition net
■ mesh pockets for the side walls
■ hooks in the load compartment
FlexOrganizer 3 71.
Tyre deflation detection
system
If a tyre loses pressure, it becomes
smaller. It then rotates at a different speed than the other tyres. If the
system detects a difference in speed,
control indicator w illuminates red.
Deflation detection system 3 175.

Instruments and controls89
If the control indicator does not go outafter a few seconds, or if it illuminates while driving, there is a fault in the
ABS. The brake system remains
operational but without ABS
regulation.
Antilock Brake System 3 138.
Upshift
[ illuminates green when upshifting
is recommended for fuel saving
reasons.
Sport mode1 illuminates yellow.
The symbol is illuminated when Sport
mode is on 3 131, 3 135.
Winter mode T illuminates yellow.
The symbol is illuminated when
Winter mode is on 3 131, 3 135.
Ultrasonic parking assist
r illuminates or flashes yellow.Illuminates
Fault in system. Have the cause of the
fault remedied by a workshop.
Flashes
Fault due to sensors that are dirty or
covered by ice or snow.
or
Interference due to external sources of ultrasound. Once the source of
interference is removed, the system
will operate normally.
Ultrasonic parking sensors 3 142.
Electronic Stability
Program v flashes or illuminates yellow.
Illuminates for a few seconds when
the ignition is switched on.
Flashes whilst driving
The system is actively engaged.
Engine output may be reduced and
the vehicle may be braked
automatically to a small degree
3 139.Illuminates whilst driving
The system is switched off or a fault
is present. Continued driving is
possible. Driving stability, however,
may deteriorate depending on road
surface conditions.
Have the cause of the fault remedied
by a workshop.
ESP® Plus
3 139.
Engine coolant
temperature W illuminates red.
Illuminates when the engine is running
Stop, switch off engine.Caution
Coolant temperature too high.
Check coolant level. 3 154.
If there is sufficient coolant, consult a workshop.

90Instruments and controlsPreheating and diesel
particle filter ! illuminates or flashes yellow.
Illuminates Preheating activated. Only activates
when outside temperature is low.
Flashes Control indicator ! flashes if the
diesel particle filter requires cleaning
and previous driving conditions did
not permit automatic cleaning.
Continue driving and if possible do
not allow engine speed to drop below
2000 rpm.
The control indicator ! goes off as
soon as the self-cleaning operation is complete.
Diesel particle filter 3 127.
Deflation detection system
and tyre pressure
monitoring system
w illuminates or flashes red or yellow.Control indicator illuminates red
Tyre pressure loss. Stop immediately
and check tyre pressure. A maximum speed of 50 mph is permitted for run-
flat tyres 3 172.
Control indicator illuminates
yellow
Fault in system or tyre without
pressure sensor mounted (e.g. spare
wheel). Consult a workshop.
Flashes
Flashes three times to indicate system initialisation.
Deflation detection system 3 175,
tyre pressure monitoring system
3 174.
Interactive driving system, continuous damping
control, sport mode IDS+ illuminates yellow.
Illuminates for approximately
10 seconds after the driver's door is
opened. Illumination whilst drivingindicates a fault in the system. The
system switches to the harder chassis setting for reasons of safety. Have the
cause of the fault remedied by a workshop.
IDS Plus
3 140, Continuous damping
control 3 141, Sport mode 3 140.
Engine oil pressure I illuminates red.
Illuminates when the ignition is
switched on and goes out shortly after
the engine starts.
Illuminates when the engine isrunningCaution
Engine lubrication may be
interrupted. This may result in
damage to the engine and/or
locking of the drive wheels.
1. Depress clutch.
2. Select neutral gear, set selector lever to N.

Driving and operating129
On vehicles with Open&Start system,
P flashes in the transmission display
when the ignition is switched off if P is
not engaged or the parking brake is
not applied.
If Sport mode is activated, 1 is
illuminated.
If the Winter programme is activated,
T is illuminated.
Selector leverP=park position, front wheels
locked, engage only when the
vehicle is stationary and the
parking brake is appliedR=reverse gear, engage only
when vehicle is stationaryN=neutralD=automatic mode with all gears
The selector lever can only be moved out of P or N when the ignition is on
and the foot brake is depressed
(Selector lever lock).
When the selector lever is in N, the
selector lever lock is activated after a
delay and only if the vehicle is
stationary.
When the selector lever is in the P or
N position, control indicator j in the
gear indicator strip illuminates red
when the selector lever is locked. If
the selector lever is not in the P
position when the ignition is switched
off, control indicator j and P in the
gear indicator strip flash.
To engage P or R, press the release
button on selector lever.
When position N is selected, press
foot brake or engage parking brake
before starting.

Driving and operating131
No automatic shifting to a higher geartakes place at a high engine speed.
For reasons of safety, kickdown is
also available in manual mode.
Electronic driving
programmes ■ Following a cold start, the operating
temperature programme increases
engine speed to quickly bring the
catalytic converter to the required
temperature.
■ The automatic neutral shift function
automatically shifts to idling when
the vehicle is stopped with a
forward gear engaged.
■ When Sport mode is engaged, the vehicle shifts at higher engine
speeds (unless cruise control is
on). Sport mode 3 140.Winter programme T
Activate the Winter programme to
assist starting off on a slippery road surface.
Activation on vehicles without manual
mode
Press the T button with P, R , N , D or
3 engaged. The vehicle starts off in
3rd gear.
Activation on vehicles with manual mode
In automatic mode, press the T
button. Depending on road
conditions, the vehicles starts off in 2nd or 3rd gear.
Deactivation
The Winter programme is switched off by:
■ pressing the T button again,
■ manually selecting 2 or 1,
■ changing to manual mode,
■ turning off the ignition,
■ or if the transmission oil temperature is too high.

136Driving and operating
■ The adaptive programme tailorsgearshifting to the driving
conditions, e.g. greater load or
gradients.
■ When Sport mode is engaged, shift
times are reduced and the
transmission shifts at higher engine speeds (unless cruise control is
on). Sport mode 3 140.
Winter programme T
Activate the Winter programme if you
have problems starting off on a
slippery road surface.
Activation
Press the T button. The transmission
switches to automatic mode. The
vehicle starts off in 2nd gear. Sport
mode is deactivated.
Deactivation
The Winter programme is switched off by:
■ pressing the T button again
■ turning off the ignition,
■ switching to manual mode (when switched back to automatic mode,
the Winter programme is again
active)
■ when clutch temperature is too highKickdown
If the accelerator pedal is pressed
past the pressure point, the
transmission shifts to a lower gear depending on engine speed.
Fault
To prevent damage to the manual transmission automated, the clutch is
engaged automatically at high clutch
temperatures.
A illuminates in the event of a fault.
Continued driving is possible. Manual
mode cannot be used for shifting.

140Driving and operating9Warning
Do not let this special safety
feature tempt you into taking risks
when driving.
Adapt speed to the road
conditions.
Control indicator v 3 89.
Deactivation
ESP® Plus
can be deactivated when
Sport mode is engaged for high-
performance driving:
Hold the SPORT button depressed
for about 4 seconds. Control indicator v illuminates. ESPoff also appears in
the service display.9 Warning
Do not deactivate ESP® Plus
if a
run-flat tyre has lost pressure.
ESP® Plus
is reactivated by pressing
the SPORT button. ESPon appears in
the service display. ESP® Plus
is also
reactivated the next time the ignition is switched on.
Sport mode 3 140.
Interactive driving system Interactive driving system (IDS Plus
)
combines the electronic stability
program (ESP® Plus
) with the antilock
brake system (ABS) and continuous damping control (CDC) to improve
driving dynamics and vehicle safety.
Sport mode
Suspension and steering become
more direct and provide better
contact with the road surface. The
engine reacts more quickly to
accelerator pedal movements.
Automatic gear changing is also more
responsive.
Control indicator IDSPlus
3 90.
Activation
Press SPORT button.
Control indicator 1 3 89.

Driving and operating141
Winter programme activation not
possible.
Deactivation
Briefly press the SPORT button.
Sport mode is deactivated the next
time the ignition is switched on or if
the Winter programme is activated.
Continuous damping
control Continuous damping control (CDC)
changes suspension with damping
adaptation of each shock absorber to the current driving situation and road
conditions.
When Sport mode is engaged, the
damping control is adapted to a
sportier driving style.
Control indicator IDS+ 3 90.Automatic level control
The rear level of the vehicle is
automatically adjusted to the load
conditions while driving. Suspension
and ground clearance are increased,
which improves driving conditions.
The automatic level control is
activated after the vehicle has been
driven for some distance, depending
on the vehicle loading and the road
conditions.
Do not use full payload in the event of
a fault. Have the cause of the fault
remedied by a workshop.
Cruise control
The cruise control can store and
maintain speeds of approx.
20 to 120 mph. Deviations from the
stored speeds may occur when
driving uphill or downhill.
For safety reasons the cruise control
cannot be activated until the foot
brake has been operated once.
Do not use the cruise control if it is not advisable to maintain a constant
speed.

212
Hazard warning flashers ............111
Headlight flash ........................... 109
Headlight range adjustment ......109
Headlights................................... 108
Headlights when driving abroad 109
Head restraint adjustment .............8
Head restraints ............................ 44
Heated mirrors ............................. 39
Heated rear window ..................... 42
Heating ........................................ 49
Heating and ventilation system . 116
High beam ........................... 92, 109
Hill start assist ........................... 139
Horn ....................................... 13, 78
I
Identification plate .....................196
Ignition switch positions .............125
Immobiliser .................................. 37
Indicators ...................................... 83
Information displays...................... 93
Instrument cluster ........................83
Instrument panel illumination .....165
Instrument panel illumination control .................................... 113
Instrument panel overview ........... 10
Interactive driving system ...........140
Interactive driving system, continuous damping control,
sport mode ............................... 90Interior care ............................... 189
Interior lighting ............................ 113
Interior lights ...................... 113, 164
Interior mirrors .............................. 39
Interruption of power supply 132, 137
Introduction .................................... 3
Isofix child restraint systems ........ 66
J Jump starting ............................. 184
K Key, memorised settings ..............28
Keys ............................................. 26
Keys, locks ................................... 26
L
Lashing eyes ............................... 71
Lighting ...................................... 101
Lighting features .........................114
Light switch ................................ 108
Load compartment ................34, 69
Load compartment cover .............69
Load compartment fuse box ......169
Loading information .....................75
Load rails and hooks ...................70
Low engine oil level .....................91
Low fuel ....................................... 91M
Malfunction indicator light ............87
Manual anti-dazzle ......................39
Manual mode .....................130, 135
Manual transmission .................. 133
Manual transmission automated 134
Manual windows ..........................40
Memorised settings ......................28
Mirror adjustment ........................... 9
Misted light covers .....................112
Moonroof ..................................... 43
N New vehicle running-in ..............124
Number plate light .....................163
O Object detection systems ...........142
Odometer ..................................... 83
Oil, engine .......................... 192, 197
Open&Start system .....................28
Open&Start system .....................91
Outside temperature ....................80
Overrun cut-off ........................... 126
P Parking ................................ 17, 126
Parking assist ............................ 142
Parking brake ............................ 139
Parking lights ............................. 112
