Page 261 of 339

VAUXHALL ZAFIRA TOURER 2018.5  Owners Manual Vehicle care259● Since the durability of AdBlue islimited to two years, fluid should
be exchanged if it is too old. Seek the assistance of a workshop.
● Fit the number plate if necessary.
End-of-l

Page 262 of 339

VAUXHALL ZAFIRA TOURER 2018.5  Owners Manual 260Vehicle care
Move the safety catch sideways to theleft vehicle side and open the bonnet.
The bonnet is held open
automatically by a lifter.
If the bonnet is opened during an
Autostop, the engine wi

Page 263 of 339

VAUXHALL ZAFIRA TOURER 2018.5  Owners Manual Vehicle care261When the engine oil level has
dropped to the  MIN mark, top-up
engine oil.
We recommend the use of the same
grade of engine oil that was used at
last change.
The engine oil level must n

Page 264 of 339

VAUXHALL ZAFIRA TOURER 2018.5  Owners Manual 262Vehicle care
If the cooling system is cold, the
coolant level should be above the
filling line mark. Top-up if the level is low.
9 Warning
Allow the engine to cool before
opening the cap. Carefully

Page 265 of 339

VAUXHALL ZAFIRA TOURER 2018.5  Owners Manual Vehicle care263Washer fluid
Fill with clean water mixed with a
suitable quantity of approved
windscreen washer fluid which
contains antifreeze.
Caution
Only washer fluid with a sufficient
antifreeze c

Page 266 of 339

VAUXHALL ZAFIRA TOURER 2018.5  Owners Manual 264Vehicle care
Batteries do not belong in household
waste. They must be disposed of at
an appropriate recycling collection
point.
Laying up the vehicle for more than
four weeks can lead to battery
di

Page 267 of 339

VAUXHALL ZAFIRA TOURER 2018.5  Owners Manual Vehicle care265Warning label
Meaning of symbols:● No sparks, naked flames or smoking.
● Always shield eyes. Explosive gases can cause blindness or
injury.
● Keep the vehicle battery out of reach

Page 268 of 339

VAUXHALL ZAFIRA TOURER 2018.5  Owners Manual 266Vehicle careRear window
Lift wiper arm. Disengage wiper bladeas shown in illustration and remove.
Attach the wiper blade slightly angled
to the wiper arm and push until it
engages.
Lower wiper arm

Page 269 of 339

VAUXHALL ZAFIRA TOURER 2018.5  Owners Manual Vehicle care267Low beam (1)
1. Rotate cap anticlockwise andremove it.
2. Rotate the bulb holderanticlockwise to disengage.
Withdraw the bulb holder from the
reflector housing.
3. Remove the bulb from

Page 270 of 339

VAUXHALL ZAFIRA TOURER 2018.5  Owners Manual 268Vehicle care2.Withdraw the bulb holder from the
reflector housing.
3. Remove the bulb from the plug connector by pulling.
4. Replace the bulb and connect it to
the plug connector.
5. Insert and pus
