Checking and refilling windshield washer fluid

Fig. 73 In the engine compartment: Cap of the windshield washer fluid reservoir.

x When refilling, do not confuse one type of operating liquid with another! Otherwise serious
malfunctions and engine damage can occur!

Mirrors

For example, visibility through the rear window could be impaired if there is a sunshade on the rear
window or clothing on the luggage compartment cover, or if the rear window is covered with ice, snow,
or dirt.
Manually adjustable inside mirror
x Home position: Lever on the bottom edge of the mirror points forward.
x To adjust to non-glare visibility, move the lever so that it points backward ⇒ fig. 74.
Outside mirrors

Fig. 75 In the driver door: Adjusting knob for the outside mirrors.

WARNING
Incorrectly estimating distances with the right outside mirror can cause collisions and
serious injury.
x The right outside mirror has a convex (curved) surface. This widens your field of vision.
But vehicles or other objects seen in a convex mirror will lo/+ smaller and farther away than
they really are.
x If you use the right outside mirror to judge distances from vehicles behind you when
changing lanes, you could estimate incorrectly and cause a crash and serious injuries.
x Whenever possible, use the inside mirror to more accurately judge distance and size of
vehicles or other objects seen in the convex mirror.
x Always make sure you have a clear view to the rear of the vehicle.
NOTICE
Always fold in the outside mirrors when taking the vehicle through an automatic car wash.
To reduce fuel consumption, use outside mirror heating only when needed.
If power mirror adjustment does not work, the outside mirrors can be adjusted by hand by
pressing on the edges of the mirror surface.

Driving tips

WARNING
Heavy loads will influence the way your vehicle handles and increase stopping distances. Heavy loads that are not properly stowed or secured can cause loss of control and serious injury.
x Secure the load properly to keep it from shifting.
x Always remember when transporting heavy objects that a change in the center of gravity also changes the way your vehicle handles:
– Always distribute the load as evenly as possible.
– Secure heavy objects properly as far forward in the luggage compartment as possible.
– Always tie down heavy items securely with suitable straps.
x Securely latch the rear seat backrest in the upright position.
x Never exceed the Gross Axle Weight Rating or the Gross Vehicle Weight Rating on the safety compliance sticker on the left door jamb. Exceeding permissible weight can cause the vehicle to skid and handle differently.
x Always adapt your speed and driving to the heavier load and the weight distribution in the vehicle. Take road, weather, traffic, and visibility conditions into account as well.
x Always accelerate gently and avoid sudden braking and driving maneuvers.
x Always brake earlier than you would if you were not driving a loaded vehicle.
Stowing luggage

Driving with an open rear hatch can lead to serious personal injury. If you have to drive with an open rear hatch, make sure that all objects and the hatch itself are properly secured and take appropriate measures to keep toxic exhaust fumes from entering the vehicle.
WARNING
Driving with an unlatched or open rear hatch can lead to serious personal injury.
x Never transport objects larger than those that fit completely in the luggage compartment, because the rear hatch cannot be fully closed properly.
x After closing the rear hatch, always pull up on it to make sure that it is properly closed and cannot open suddenly when the vehicle is moving.
x Always stow all objects securely in the luggage compartment. Loose objects can fall out of the luggage compartment and injure others on the road behind you.
x Drive carefully; anticipate what other drivers will do.
x Avoid abrupt or sudden acceleration, steering, or braking, because the unlatched rear hatch can move suddenly.
x Always mark objects sticking out from the luggage compartment clearly for others to see. Obey all applicable legal requirements.
x Never use the rear hatch to “clamp” or “hold” objects that stick out of the luggage compartment.
x Always remove any luggage rack or other rack mounted on the rear hatch (along with any luggage on the rack) before driving with an open rear hatch.
WARNING
Driving with an open rear hatch can cause poisonous carbon monoxide in the engine exhaust to get into the passenger compartment.
x Carbon monoxide causes drowsiness, inattentiveness, poisoning, and loss of consciousness. It can lead to accidents and severe personal injuries.
x Always keep the rear hatch closed while driving to help keep poisonous exhaust fumes from being drawn into the vehicle.
x Never transport objects that are too large to fit completely into the luggage area, because then the rear hatch cannot be fully closed.
x If you absolutely must drive with an open rear hatch, do the following to reduce the risk of carbon monoxide poisoning:
– Close all windows and the power sunroof.
– Switch off the climate control system's air recirculation feature.
– Open all air vents in the instrument panel.
– Set the fresh air fan to the highest speed.
NOTICE
The open rear hatch changes the vehicle length and height.
Driving a loaded vehicle

x Securely stow all luggage.
x Drive especially carefully and accelerate gently.
x Avoid sudden braking and driving maneuvers.
x Brake earlier than you would if you were not driving a loaded vehicle.
x If applicable, observe information about driving with a roof rack.
WARNING
Heavy loads can change the way your vehicle handles and increase stopping distances. Heavy loads that are not properly stowed or secured can shift suddenly, causing loss of control and serious injury.
x Secure the load properly to keep it from shifting.
x Always remember when transporting heavy objects that they change the vehicle's center of gravity and also the way it handles.
– Always distribute the load as evenly as possible.
– Secure heavy objects as far forward in the luggage compartment as possible.
x Securely latch the rear seat backrest in the upright position.
x Never exceed the Gross Axle Weight Rating or the Gross Vehicle Weight Rating on the safety compliance sticker on the left door jamb. Exceeding permissible weight can cause the vehicle to skid and handle differently.
x Always adapt speed and driving to the heavier load and the weight distribution in the vehicle. Take road, weather, traffic, and visibility conditions into account as well.
x Always accelerate gently and avoid sudden braking and driving maneuvers.
x Always brake earlier than you would if you were not driving a loaded vehicle.
Weights and axle weights

WARNING
Exceeding maximum permissible weight ratings can result in vehicle damage, accidents, and serious personal injury.
x Never let the actual weights at the front and rear axles exceed the permissible Gross Axle Weight Rating. Also, never let the total of these actual weights exceed the Gross Vehicle Weight Rating.
x Always remember that the vehicle's handling and braking will be affected by extra load and the distribution of this load. Adjust your speed accordingly.
NOTICE
x Always distribute the load evenly and as low as possible in the vehicle. The vehicle capacity weight figures apply when the load is distributed evenly in the vehicle (passengers and luggage).
x When transporting a heavy load in the luggage compartment, carry the load as close to the rear axle (as far forward) as possible so that the vehicle's handling and braking are affected as little as possible.
