VOLKSWAGEN BEETLE CONVERTIBLE 2013 3.G Owner's Guide
Manufacturer: VOLKSWAGEN, Model Year: 2013, Model line: BEETLE CONVERTIBLE, Model: VOLKSWAGEN BEETLE CONVERTIBLE 2013 3.GPages: 281, PDF Size: 5.27 MB
Page 31 of 281
Maximum power
output (SAE net)
Injection
technology
Engine ID
code
Maximum torque No. of
cylinders
Displacement
170 hp at 5700 rpm
(125 kW at 5700 rpm) SRE
CBTA,
CBUA
2.5L
177 lb-ft at 4250 rpm
(240 Nm at 4250 rpm)
5 cylinder
151 CID
(2480 ccm)
200 hp at 5100 –
6000 rpm
(147 kW at 5100 –
6000 rpm)
TSI®
CCTA,
CBFA
2.0T
207 lb-ft at 1700 – 5000 rpm
(280 Nm at 1700 – 5000
rpm)
4 cylinder
121 CID
(1984 ccm)
Diesel engines
Maximum power
output (SAE net)
Injection
technology
Engine ID
code
Maximum torque No. of
cylinders
Displacement
140 hp at 4000 rpm
(103 kW at 4000 rpm)
TDI® with
DPF
CJAA
2.0L TDI
236 lb-ft at 1750 – 2500 rpm
(320 Nm at 1750 –
2500 rpm)
4 cylinders
120 CID
(1968 ccm)
Applicable only in Canada
Engine data
Page 32 of 281
Wheelbase 99.9 in. (2537 mm)
Minimum turning circle diameter (wall to wall)2 35.4 ft (10.8 m)
Track2, front 61.8 – 62.2 in. (1570 – 1580 mm)
Track2, rear 60.4 – 61.2 in. (1536 – 1556 mm)
Ground clearance (unloaded) about 5.3 in. (136 mm)3
NOTICE
x Please be careful when parking your vehicle in areas with parking barriers or curbs. These
vary in height and could damage your bumper and related parts if the front of your vehicle hits
a barrier or curb that is too high while you are getting into or out of a parking spot.
x Always be careful when you enter a driveway or drive up or down steep ramps or over
curbs or other obstacles. Parts of the vehicle close to the ground may be damaged (such as
bumper covers, spoilers, and parts of the engine, suspension, and exhaust systems).
2 Slight differences to these figures are possible, depending on wheel and
tire size fitted and the level selected.
3 Varies depending on your vehicle's equipment (engine, tires, wheels, tire
inflation pressure, driving situation and other factors).
