Opening or closing power windows

Fig. 39 In the driver door: Switches for the power windows.

ignition and the driver door has been opened, the power windows
cannot be opened or closed.
A separate button for controlling the window is located in the front
passenger door.
Power windows – features

For one-touch closing: Pull the switch for the window up briefly as
far as it goes.
Stopping automatic movement: Pull/press the switch again.
Reactivating the one-touch feature
If the vehicle battery is disconnected or dead and the windows are not
completely closed, the one-touch feature will not work and must be
reactivated:
Switch on the ignition.
Close all windows and doors.
Pull up the switch for the respective window and hold it for at least
2 seconds in this position.
Release the switch, pull up and hold again. The one-touch feature
is now reactivated.
The one-touch feature can be reactivated for one or more windows at
the same time.
Convenience closing
The convenience closing feature lets you close the windows and the
power sunroof as follows:
On vehicles with Keyless Access, using the door handle sensors ⇒ 
Power locking and closing system.
From inside the vehicle, pull up and hold the switch for the driver
window until all windows and the sunroof are closed ⇒ Power locking
and closing system.
Convenience closing first closes the windows and then the power
sunroof. All turn signals blink once to confirm that the windows and
power sunroof are closed.

WARNING
Improper use of power windows can result in serious personal
injury.
Never let anyone get in the way of a power window when
closing it.
When locking the vehicle from the outside, make sure that no
one, especially children, remains in the vehicle. The windows
will not open in case of an emergency.
Always take the key with you when you leave the vehicle. You
can still use the power windows for several minutes after the
ignition is switched off as long as the driver or front passenger
door has not been opened.
Always use the safety switch when children are in the back
seat to disable the rear power windows and keep them from be-
ing opened and closed.
NOTICE
The windows must go down slightly when you unlock the vehi-
cle. Otherwise the windows and seals could be damaged when
opening the doors.
If the power windows malfunction, the one-touch feature, as well
as pinch protection may not work properly. See an authorized
Volkswagen dealer or authorized Volkswagen Service Facility right
away.
Power window pinch protection

If the window meets resistance a second time, so that it stops and
goes back down, one-touch closing is deactivated for about
10 seconds.
If you pull the power window button up all the way and hold it dur-
ing this 10 second interval, the window will close without pinch pro-
tection ⇒ .
Closing the window without pinch protection
Try to close the window again within 10 seconds by holding the
switch. Pinch protection is turned off for a short distance in the
window track!
If closing takes longer than about 10 seconds, pinch protection is
turned on again. The window stops again if there is resistance.
If the window still will not close, please see an authorized
Volkswagen dealer or an authorized Volkswagen Service Facility.
WARNING
Without pinch protection, power windows will close with
enough force to cause serious personal injury.
Always be careful when closing power windows.
Always make sure that no one is in the way when overriding
pinch protection to close power windows!
Pinch protection cannot prevent fingers or other parts of the
body from being pressed against the window frame; injuries
may result.
Pinch protection is also active during convenience closing of the
windows and the power sunroof ⇒ Power windows – features.

Power sunroof

vehicle interior and cause extensive damage to the electrical
system. This could result in further vehicle damage.
Remove leaves and other objects from the sunroof guiderails
regularly either by hand or using a vacuum cleaner.
If the power sunroof malfunctions, pinch protection may not func-
tion properly. See an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility.
Opening or closing the power sunroof

Fig. 40 In the headliner: Switch for the power sunroof.

roof for a short time as long as the driver or front passenger door has
not been opened.
Sliding headliner
Use the handle in the front area of the roof opening to move the slid-
ing headliner to the desired position.
Power sunroof – convenience closing feature

resistance or there is something in the way, the power sunroof opens
again immediately.
Check why the power sunroof did not close.
Try to close the power sunroof again by pulling the h switch brief-
ly.
If the power sunroof still cannot close, the power sunroof will stop
where the resistance is located. The power sunroof will close the next
time without pinch protection.
Closing the power sunroof without pinch protection
Within 5 seconds after the pinch protection was triggered, pull the
switch ⇒ fig. 40 until the power sunroof closes completely.
The power sunroof will now close without pinch protection!
If the power sunroof still will not close, please see an authorized
Volkswagen dealer or an authorized Volkswagen Service Facility.
WARNING
Careless or unsupervised use of the sunroof can cause serious
injuries.
Always make sure that no one is in the way of the power sun-
roof when it is closing.
Always take all vehicle keys with you when leaving the vehi-
cle.
Never leave children or persons requiring assistance unat-
tended in the vehicle, especially if they have access to the ve-
hicle key. Unsupervised use of the remote control vehicle key
can lock the vehicle, start the engine, switch on the ignition and
operate the sunroof.
The sunroof can still be opened or closed for a short period
after the ignition has been switched off, as long as the driver or
passenger door is not opened.

WARNING
Without pinch protection, the power sunroof will close with
enough force to cause serious personal injury.
Always be careful when closing the power sunroof.
Always make sure that no one is in the way when overriding
the pinch protection to close the power sunroof!
Pinch protection cannot prevent fingers or other parts of the
body from being pressed against the edge of the roof; injuries
may result.
Pinch protection is also active during convenience closing of the
windows and the power sunroof ⇒ Convenience closing.
If the power sunroof malfunctions, pinch protection may not func-
tion properly. See an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility for assistance.
