ARTICLE BEGINNING
GENERAL INFORMATION
METRIC CONVERSIONS
METRIC CONVERSIONS
Metric conversions are making life more difficult for the
mechanic. In addition to doubling the number of tools required,
metric-dimensioned nuts and bolts are used alongside English
components in many new vehicles. The mechanic has to decide which tool
to use, slowing down the job. The tool problem can be solved by trial
and error, but some metric conversions aren't so simple. Converting
temperature, lengths or volumes requires a calculator and conversion
charts, or else a very nimble mind. Conversion charts are only part of
the answer though, because they don't help you "think" metric, or
"visualize" what you are converting. The following examples are
intended to help you "see" metric sizes:
LENGTH
Meters are the standard unit of length in the metric system.
The smaller units are 10ths (decimeter), 100ths (centimeter), and
1000ths (millimeter) of a meter. These common examples might help you
to visualize the metric units:
* A meter is slightly longer than a yard (about 40 inches).
* An aspirin tablet is about one centimeter across (.4 inches).
* A millimeter is about the thickness of a dime.
VOLUME
Cubic meters and centimeters are used to measure volume, just
as we normally think of cubic feet and inches. Liquid volume
measurements include the liter and milliliter, like the English quarts
or ounces.
* One teaspoon is about 4 cubic centimeters.
* A liter is about one quart.
* A liter is about 61 cubic inches.
WEIGHT
The metric weight system is based on the gram, with the most
common unit being the kilogram (1000 grams). Our comparable units are
ounces and pounds:
* A kilogram is about 2.2 pounds.
* An ounce is about 28 grams.
TORQUE

METRIC CONVERSIONS
Article Text (p. 2)
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 09:20PM
Torque is somewhat complicated. The term describes the amount
of effort exerted to turn something. A chosen unit of weight or force
is applied to a lever of standard length. The resulting leverage is
called torque. In our standard system, we use the weight of one pound
applied to a lever a foot long, resulting in the unit called a foot-
pound. A smaller unit is the inch-pound (the lever is one inch long).
Metric units include the meter kilogram (lever one meter long
with a kilogram of weight applied) and the Newton-meter (lever one
meter long with force of one Newton applied). Some conversions are:
* A meter kilogram is about 7.2 foot pounds.
* A foot pound is about 1.4 Newton-meters.
* A centimeter kilogram (cmkg) is equal to .9 inch pounds.
PRESSURE
Pressure is another complicated measurement. Pressure is
described as a force or weight applied to a given area. Our common
unit is pounds per square inch. Metric units can be expressed in
several ways. One is the kilogram per square centimeter (kg/cmý).
Another unit of pressure is the Pascal (force of one Newton on an area
of one square meter), which equals about 4 ounces on a square yard.
Since this is a very small amount of pressure, we usually see the
kiloPascal, or kPa (1000 Pascals). Another common automotive term for
pressure is the bar (used by German manufacturers), which equals 10
Pascals. Thoroughly confused? Try the examples below:
* Atmospheric pressure at sea level is about 14.7 psi.
* Atmospheric pressure at sea level is about 1 bar.
* Atmospheric pressure at sea level is about 1 kg/cm
ý.
* One pound per square inch is about 7 kPa.
CONVERSION FACTORS
CONVERSION FACTORS
ÚÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÂÄÄÄÄÄÄÄÄÄÄÄÄÄÄ¿
³TO CONVERT
³TO ³ MULTIPLY BY ³
ÃÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÅÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÅÄÄÄÄÄÄÄÄÄÄÄÄÄÄ´
³LENGTH
³ ³ ³
³Millimeters (mm)
³Inches ³ .03937 ³
³Inches
³Millimeters ³ 25.4 ³
³Meters (M)
³Feet ³ 3.28084 ³
³Feet
³Meters ³ .3048 ³
³Kilometers(Km)
³Miles ³ .62137 ³
ÃÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÅÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÅÄÄÄÄÄÄÄÄÄÄÄÄÄÄ´
³AREA
³ ³ ³
³Square Centimeters (cm
ý) ³Square Inches ³ .155 ³
³Square Inches
³Square Centimeters ³ 6.45159 ³
ÃÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÅÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÅÄÄÄÄÄÄÄÄÄÄÄÄÄÄ´
³VOLUME
³ ³ ³
³Cubic Centimeters
³Cubic Inches ³ .06103 ³

METRIC CONVERSIONS
Article Text (p. 3)
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 09:20PM³Cubic Inches ³Cubic Centimeters ³ 16.38703 ³
³Liters
³Cubic Inches ³ 61.025 ³
³Cubic Inches
³Liters ³ .01639 ³
³Liters
³Quarts ³ 1.05672 ³
³Quarts
³Liters ³ .94633 ³
³Liters
³Pints ³ 2.11344 ³
³Pints
³Liters ³ .47317 ³
³Liters
³Ounces ³ 33.81497 ³
³Ounces
³Liters ³ .02957 ³
ÃÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÅÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÅÄÄÄÄÄÄÄÄÄÄÄÄÄÄ´
³WEIGHT
³ ³ ³
³Grams
³Ounces ³ .03527 ³
³Ounces
³Grams ³ 28.34953 ³
³Kilograms
³Pounds ³ 2.20462 ³
³Pounds
³Kilograms ³ .45359 ³
ÃÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÅÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÅÄÄÄÄÄÄÄÄÄÄÄÄÄÄ´
³WORK
³ ³ ³
³Centimeter Kilograms
³Inch Pounds ³ .8676 ³
³Pounds/Sq. Inch
³Kilograms/Sq.Centimeter³ .07031 ³
³Bar
³Pounds/Sq. Inch ³ 14.504 ³
³Pounds/Sq. Inch
³Bar ³ .06895 ³
³Atmosphere
³Pounds/Sq. Inch ³ 14.696 ³
³Pounds/Sq. Inch
³Atmosphere ³ .06805 ³
ÃÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÅÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÅÄÄÄÄÄÄÄÄÄÄÄÄÄÄ´
³TEMPERATURE
³ ³ ³
³Centigrade Degrees
³Fahrenheit Degrees ³(øCx(9)/5)+32 ³
³Fahrenheit Degrees
³Centigrade Degrees ³(øF-32)x(5)/9 ³
ÀÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÁÄÄÄÄÄÄÄÄÄÄÄÄÄÄÙCONVERSION FACTORS (Cont.)
ÚÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ¿
³INCHES DECIMALS mm
³
ÃÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ´
³
³
³1/64 ...................... .016 ........................ .397
³
³1/32 ...................... .031 ........................ .794
³
³3/64 ...................... .047 ....................... 1.191
³
³1/16 ...................... .063 ....................... 1.588
³
³5/64 ...................... .078 ....................... 1.984
³
³3/32 ...................... .094 ....................... 2.381
³
³7/64 ...................... .109 ....................... 2.778
³
³1/8 ....................... .125 ....................... 3.175
³
³9/64 ...................... .141 ....................... 3.572
³
³5/32 ...................... .156 ....................... 3.969
³
³11/64 ..................... .172 ....................... 4.366
³
³3/16 ...................... .188 ....................... 4.763
³
³13/64 ..................... .203 ....................... 5.159
³
³7/32 ...................... .219 ....................... 5.556
³
³15/64 ..................... .234 ....................... 5.953
³
³1/4 ....................... .250 ....................... 6.350
³
³17/64 ..................... .266 ....................... 6.747
³
³9/32 ...................... .281 ....................... 7.144
³

METRIC CONVERSIONS
Article Text (p. 4)
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 09:20PM³19/64 ..................... .297 ....................... 7.541 ³
³5/16 ...................... .313 ....................... 7.938
³
³21/64 ..................... .328 ....................... 8.334
³
³11/32 ..................... .344 ....................... 8.731
³
³23/64 ..................... .359 ....................... 9.128
³
³3/8 ....................... .375 ....................... 9.525
³
³25/64 ..................... .391 ....................... 9.992
³
³13/32 ..................... .406 ...................... 10.319
³
³27/64 ..................... .422 ...................... 10.716
³
³7/16 ...................... .438 ...................... 11.113
³
³29/64 ..................... .453 ...................... 11.509
³
³15/32 ..................... .469 ...................... 11.906
³
³31/64 ..................... .484 ...................... 12.303
³
³1/2 ....................... .500 ...................... 12.700
³
³33/64 ..................... .516 ...................... 13.097
³
³17/32 ..................... .531 ...................... 13.494
³
³35/64 ..................... .547 ...................... 13.891
³
³9/16 ...................... .563 ...................... 14.288
³
³37/64 ..................... .578 ...................... 14.684
³
³19/32 ..................... .594 ...................... 15.081
³
³39/64 ..................... .609 ...................... 15.478
³
³5/8 ....................... .625 ...................... 15.875
³
³41/64 ..................... .641 ...................... 16.272
³
³21/32 ..................... .656 ...................... 16.669
³
³43/64 ..................... .672 ...................... 17.066
³
³11/16 ..................... .687 ...................... 17.463
³
³45/64 ..................... .703 ...................... 17.859
³
³23/32 ..................... .719 ...................... 18.256
³
³47/64 ..................... .734 ...................... 18.653
³
³3/4 ....................... .750 ...................... 19.050
³
³49/64 ..................... .766 ...................... 19.447
³
³25/32 ..................... .781 ...................... 19.844
³
³51/64 ..................... .797 ...................... 20.241
³
³13/16 ..................... .813 ...................... 20.638
³
³53/64 ..................... .828 ...................... 21.034
³
³27/32 ..................... .844 ...................... 21.431
³
³55/64 ..................... .859 ...................... 21.828
³
³7/8 ....................... .875 ...................... 22.225
³
³57/64 ..................... .891 ...................... 22.622
³
³29/32 ..................... .906 ...................... 23.019
³
³59/64 ..................... .922 ...................... 23.416
³
³15/16 ..................... .938 ...................... 23.813
³
³61/64 ..................... .953 ...................... 24.209
³
³31/32 ..................... .969 ...................... 24.606
³
³63/64 ..................... .984 ...................... 25.003
³
³1 ......................... 1.000 ..................... 25.400
³
ÀÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÙEND OF ARTICLE

MIRRORS - POWER
Article Text
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 09:21PM
ARTICLE BEGINNING
1993 ACCESSORIES & EQUIPMENT
Volkswagen Power Mirrors
Volkswagen; Corrado SLC, Passat
DESCRIPTION & OPERATION
Mirrors can be adjusted electrically from inside by operating
control knob on driver door panel. Adjustment control operates only
when ignition is on. To adjust driver-side or passenger-side mirror,
rotate control knob to "L" or "R". Control knob is a 4-way rocker
switch which is pressed top (up), bottom (down), left (out) or right
(in). See Fig. 1.
If electrical control of mirror does not operate, adjust
mirror by hand by pushing lightly on edge of mirror glass. When rear
defogger is on, outside mirrors are electrically heated.Fig. 1: Controlling Mirror Switch
Courtesy of Volkswagen United States, Inc.
TROUBLE SHOOTING
Left Or Right Power Mirror Inoperative
Check power mirror switch, power mirror motor(s), wiring,
ground connection(s) and fuse(s). Use operator's manual to identify
fuse(s).
REMOVAL & INSTALLATION
MIRROR GLASS
WARNING: Press only on center of glass. Always wear protective gloves

MIRRORS - POWER
Article Text (p. 2)
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 09:21PM
while handling mirror glass (in case of accidental breakage).
NOTE: Mirror glass is only clipped in place.
Removal & Installation
Tape upper and lower edges of mirror housing. See Fig. 2 & 3.
Remove mirror glass using knife blade Pry Bar (VW-80-200). Pry off at
bottom and then top. While holding mirror, unplug electrical
connector, and remove mirror glass. To install, connect electrical
connector. Put mirror pins in notches, and press mirror into place.
See Fig. 2 & 3. Check mirror for proper function.Fig. 2: Removing Mirror Glass
Courtesy of Volkswagen United States, Inc.Fig. 3: Removing Mirror Glass (Open)
Courtesy of Volkswagen United States, Inc.
POWER MIRROR ASSEMBLY

MIRRORS - POWER
Article Text (p. 3)
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 09:21PM
WARNING: Always wear protective gloves while handling mirror glass (in
case of accidental breakage). Hold glass to prevent it from
falling out.
Removal & Installation
1) Disconnect battery ground cable. Lower window. Remove
control knob and boot. Remove door trim, and loosen moisture barrier
in area of rearview mirror control. Remove lock nut. Unplug electrical
connector.
2) Pivot mirror inward, and remove mounting screw. Pivot
mirror outward, and remove second mounting screw. Remove mirror with
base and control. To install, reverse removal procedure.
WIRING DIAGRAMS
See appropriate chassis wiring diagram in WIRING DIAGRAMS.
END OF ARTICLE

N - REMOVE/INSTALL/OVERHAUL
Article Text
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 09:21PM
ARTICLE BEGINNING
1993 ENGINE PERFORMANCE
Removal, Overhaul & Installation
Corrado SLC
CAUTION: When battery is disconnected, vehicle computer and memory
systems may lose memory data. Driveability problems may
exist until computer systems have completed a relearn
cycle. See the COMPUTER RELEARN PROCEDURES article in
GENERAL INFORMATION before disconnecting battery.
INTRODUCTION
Removal, overhaul and installation procedures are covered in
this article. If component removal and installation is primarily an
unbolt and bolt-on procedure, only a torque specification may be
furnished.
CAUTION: When disconnecting battery, obtain and record radio
anti-theft code. If wrong code is entered into radio after
power is restored, radio will become inoperable.
IGNITION SYSTEM
NOTE: Corrado SLC ignition system removal and installation
information not available from manufacturer. These vehicles
are equipped with a distributorless ignition system.
DISTRIBUTOR
FUEL SYSTEM
FUEL SYSTEM PRESSURE RELEASE
To relieve fuel system pressure, remove fuel pump fuse (No.
5, 13 or 18) or fuel pump relay to deactivate fuel pump. Place a clean
shop rag around fuel line fitting and slowly loosen fitting.
WARNING: Fuel system pressure release procedure is not available
from manufacturer. Fuel will discharge when disconnecting
fuel system components. Disconnect ignition coil output
stage wiring harness to deactivate ignition. DO NOT smoke
or work near heaters or other fire hazards. Keep a fire
extinguisher handy.
FUEL PUMP
Removal & Installation (Corrado SLC)
1) Obtain and record radio anti-theft code. Disconnect

N - REMOVE/INSTALL/OVERHAUL
Article Text (p. 2)
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 09:21PM
negative battery cable. Remove luggage compartment floor covering and
fuel pump access cover. Disconnect wiring harness and fuel lines from
fuel pump.
2) Using Wrench (3217), loosen fuel pump screw cap. Remove
flange and sealing ring from fuel tank opening. Loosen fuel pump by
twisting it to left. Remove fuel pump from fuel tank.
3) When installing fuel pump, ensure that fuel gauge sending
unit is not bent. Sending unit must be installed with a frontal angle
of 5 degrees. Align mark on flange with fuel tank. To complete
installation, reverse removal procedure.
FUEL PUMP CHECK VALVE
FUEL RAIL & INJECTORS
Removal & Installation (Corrado SLC)
1) Remove ignition wires. Remove hose from mass airflow
sensor. Disconnect hose to fuel evaporative (frequency) solenoid valve
at throttle body.
2) Disconnect throttle position sensor and idle air control
valve. Disconnect accelerator cable from throttle body. Disconnect and
plug coolant hoses at throttle body.
3) Disconnect hose from air intake heated tube. Detach fuel
lines at cylinder head cover and remove from fuel rail. Disconnect
vacuum hose from fuel pressure regulator. Remove upper intake
manifold.
4) With upper intake manifold removed, disconnect wiring
harness from fuel injector(s). Pry off retaining clip(s) from
injector(s). To install injectors, lubricate "O" rings with fuel. To
complete installation, reverse removal procedure.
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS (CORRADO SLC)ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄApplication Ft. Lbs. (N.m)
EGR Temperature Sensor ...................... 15 (20)
Knock Sensors ............................... 18 (25)
Oxygen Sensor ............................... 37 (50)
Throttle Body Bolts ......................... 18 (25)
Upper Intake Manifold Bolts ................. 18 (25)
INCH Lbs. (N.m)
FUEL RAIL BOLTS ............................. 84 (10)
Intake Air Temperature Sensor ............... 84 (10)
ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄEND OF ARTICLE

P - EGR FUNCTION TESTING
Article Text
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 09:21PM
ARTICLE BEGINNING
1989-95 ENGINE PERFORMANCE
Volkswagen EGR Function Testing
All Models
EGR VALVE (EXCEPT DIESEL)
1) Run engine at idle speed. Using a hand-held vacuum pump,
apply 12 in. Hg to EGR valve. Engine should run rough or stall. If
not, check EGR valve pintle for movement. If EGR pintle is moving, EGR
port is plugged. If EGR valve does not function, replace EGR valve.
2) To check EGR port vacuum supply, connect vacuum gauge to
EGR vacuum line using a "T" fitting. Start engine and increase engine
speed to about 3000 RPM. Vacuum gauge should indicate vacuum. If
vacuum is not present, vacuum source is plugged. Repair as necessary
and repeat test.
END OF ARTICLE
