Removing and reinstalling the rear head restraints

Fig. 40 Removing the rear head restraint (version A).

Fig. 41 Removing the rear head restraint (version B).

x If necessary, press the flat blade of the screwdriver from the vehicle tool kit into the slit of the trim
cap ⇒ fig. 41 (2) in the direction of the arrow and hold it in this position.
x At the same time press button (2) while a second person pulls out the head restraint completely.
x Fold the backrest of the rear seat bench back so that it locks securely.
Reinstalling the rear head restraint (both versions)
x Unlock the backrest of the rear seat bench and fold it forward ⇒  Luggage compartment.
x Position head restraint properly over the head restraint guides of the respective seat backrest and insert the head restraint into the guides.
x Push the head restraint down while pressing button ⇒ fig. 40 (2) or ⇒ fig. 41 (2).
x Fold the backrest of the rear seat bench back so that it locks securely.
x Adjust the head restraint according to the occupant's size ⇒  Adjusting the front and rear head restraints.
WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the risk of neck injury in a crash.
x Always reinstall head restraints as soon as possible so that vehicle occupants are proper-ly protected.
NOTICE
When removing or reinstalling the head restraint, take care that the head restraint does not strike the headliner or other parts of the vehicle. The headliner or other parts of the vehicle could otherwise be damaged.
Adjusting the steering wheel position

Fig. 42 Manual adjustment for the steering wheel position.

x Push down on the lever ⇒ fig. 42 (1).
x Adjust the steering wheel so that it can be held with hands at the 9 o'clock and 3 o'clock positions on the outside of the steering wheel rim and with the arms slightly bent at the elbow.
x Pull the lever up firmly until it is flush with the steering column ⇒ .
WARNING
Improper use of the steering column adjustment feature can result in serious personal injury and even death.
x Always pull the lever (1) firmly upward after adjusting the steering column so that the steering wheel does not change position suddenly while the vehicle is moving.
x Never adjust the steering column while the vehicle is moving. If you find that you need to adjust the steering wheel while driving, stop the vehicle in a safe place and make the proper adjustment.
x Never adjust the steering wheel so that it points toward your face. Always make sure that the steering wheel points toward your chest. Otherwise, the airbag system cannot protect you properly in the event of a crash.
x Always hold the steering wheel on the outside of the steering wheel rim with your hands at the 9 o'clock and 3 o'clock positions to help reduce the risk of serious personal injury if the driver's airbag inflates.
x Never hold the steering wheel at the 12 o'clock position or with your hands anywhere inside the steering wheel or on the steering wheel hub. Holding the steering wheel the wrong way increases the risk of severe injury to the arms, hands, and head if the driver airbag de-ploys.
Center armrest

Fig. 43 Front center armrest.

Fig. 44 Folding down the rear center armrest (arrow).

Seat functions

x If the outside temperature or the temperature inside the passenger compartment is +77 °F (+25 °C) or more.

Function Action for seat heating ⇒ fig. 45
Switch on: Press the A or e button. Seat heating is switched on to
maximum.
Adjust the heat-
ing level:
Press the A or e button repeatedly until the desired
heating level is set.
Switch off: Press the A or e button repeatedly until all indicator
lights in the button are off.

Special seat heating features
On the driver and the passenger side, the seat heating will resume at the setting that was set when the ignition was last switched off. However, this feature only works if the key is not taken out of the ignition switch, or, for vehicles with Keyless Access, the driver door is not opened or the vehicle is not locked.
People suffering from a low level of perceived pain or a lowered awareness of pain as from medica-
tion, paralysis, or chronic illness (e.g. diabetes) should NEVER use the seat heating feature ⇒ !
The use of seat heating by persons with these conditions could result in burns to the back, buttocks, and legs that may take a long time to heal and may never heal completely. If you have any of these conditions, you should take regular breaks and get out of the vehicle, particularly on long trips. Consult your doctor for advice regarding your specific condition.
WARNING
Certain medical conditions, such as paralysis and diabetes, and certain medications can increase the risk of serious burns when the seat heating feature is switched on.
x Vehicle occupants who have a low level of perceived pain or a lowered awareness of pain can receive serious burns to the back, buttocks, and legs that take a long time to heal or may never heal completely.
x Never use the seat heating feature if you or your passengers are at risk of being burned because of a medical condition. Take regular breaks and get out of the vehicle, particularly on long trips. Consult your doctor for advice regarding your specific condition.
x Never let exposed skin remain in contact with the seat upholstery when the seat heating is being used.
WARNING
A wet seat can cause the seat heating to malfunction and increase the risk of serious burns.
x Always make sure the seats are dry before using the seat heating.
x Never sit on the seat with wet clothes.
x Never put damp or wet things including clothes on the seat.
x Never spill liquids on the seats.

NOTICE
x To help prevent damage to electrical and other parts in the seat, do not kneel on the front seats or apply concentrated pressure to a small area of the seat or backrest.
x Liquids, sharp objects and things that do not let the heat in the seat escape into the air, including, for example, a child restraint, a blanket, or seat covers on the seat can damage seat heating.
x If you smell an odor, immediately shut off seat heating and have it checked by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
x Never install leather upholstery on a vehicle with seat heating that originally had cloth upholstery. The seat heating elements for seats with cloth seats will overheat if the cloth up-holstery is replaced with leather upholstery.
Switch off seat heating when it is not needed to help reduce unnecessary power consumption.

Safety belts

WARNING
Not wearing a safety belt or wearing an improperly positioned safety belt increases the risk of severe personal injury or death. Safety belts offer optimum protection only when they are used properly.
x Properly worn safety belts are the single most effective means of reducing the risk of serious injury and death in a collision or other accident. For this reason, always wear your safety belt properly and make sure all passengers wear their safety belts properly as well whenever the vehicle is moving.
x The driver must always make sure that every person in the vehicle is properly seated on a seat of his or her own, properly fastens the safety belts belonging to that seat before the vehicle starts to move, and keeps the belts properly fastened while riding in the vehicle. This applies even when just driving around town. Therefore, always wear your safety belts and make sure that everybody in your vehicle is properly restrained.
x Always secure children in the vehicle with a restraint system appropriate for their age,
weight and height ⇒  Child safety and child restraints.
x Always fasten safety belts correctly before driving off and make sure that all passengers are properly restrained.
x Never attach the safety belt to the buckle of another seat. Attaching the safety belt to the wrong buckle will reduce safety belt effectiveness and can cause serious personal injury.
x Never let any objects or liquids get into the safety belt latch and prevent it from working properly.
x Never remove a safety belt while the vehicle is moving. Doing so will increase your risk of being injured or killed.
x Never strap more than one person, including small children, into any single safety belt.
x Never let children or babies ride sitting on your lap, and never place a safety belt over a child sitting on your lap.
x Never wear belts over rigid or breakable objects in or on your clothing, such as eyeglass-es, pens, keys, etc., as these may cause injury.
x Several layers of heavy clothing (such as a coat worn over top of a sports jacket) may interfere with proper positioning of the safety belt and reduce the overall effectiveness of the system.
x Never use comfort clips or devices that create slack in the shoulder belt. However, special clips may be required for the correct use of some child restraint systems.
x Safety belts offer optimum protection only when the seat backrest is upright and belts are correctly positioned on the body.

WARNING
Damage to safety belts reduces their overall effectiveness and increases the risk of serious personal injury and death whenever the vehicle is being used.
x Never let safety belts become damaged by being caught in the door or seat hardware.
x Torn or frayed safety belts can tear, and damaged safety belt hardware can break in an accident.
x Inspect belts regularly for damage. If webbing, bindings, buckles, or retractors are dam-aged, have the belts replaced immediately with the correct replacement belts approved by Volkswagen for your vehicle, model, and model year.
x Safety belts that were subject to stress in an accident and stretched must be replaced with a correct, new safety belt, preferably by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
x Replacement after a crash may be necessary even if a safety belt shows no visible dam-age. Anchorages that have been loaded must also be inspected.
x Damaged safety belts must be replaced; they cannot be repaired.
x Never try to repair a damaged safety belt yourself. Never remove or modify the safety belts in any way.
x Have safety belts, bindings, retractors and buckles replaced by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
x Always keep the belts clean. Dirty belts may not work correctly and can impair the func-tion of the inertia reel.
Warning light

Fig. 46 Warning light in the instrument cluster.
