VOLKSWAGEN EOS 2013 1.G Owners Manual

Fig. 170 Inside the luggage compartment: Release lever for luggage compartment lid.

Fig. 172 Right side of luggage compartment: Emergency release of fuel filler flap.

x Within 2 seconds, pull the switch again and hold it until the sunroof closes completely. The sunroof
will close with extra force. Pinch protection will be disabled while the sunroof is closing!
In some cases, the emergency closing procedure for the CSC roof can be used to close the
power sunroof
Emergency closing of the CSC roof

Fig. 174 CSC roof switch in the center console.

Fig. 175 Driver's door control to open and close all windows.

Possible situations for emergency closing
Provided the preliminary requirements have been met, the CSC roof can be closed using the
emergency procedure if you have one or more of the following problems:
x The windows in the doors will not go down.
x The soft-close feature of the luggage compartment lid is not working.
x Sensors that determine the position of the CSC roof when it is opening and closing are not
working.
Emergency CSC roof closing
x Check whether there is enough room behind the vehicle for the luggage compartment lid to swing
out backwards.
x Open the driver and passenger door and leave the doors open.
x Press your thumb on the top part of the Volkswagen emblem on the luggage compartment lid, and
flip lower part of the emblem outward. This unlocks the rear lid. But do not lift the luggage
compartment lid.
x Switch the ignition off and back on again.
x Start the engine.
x Pull and hold the center console lever ⇒ fig. 174 for at least 30 seconds.
x Release the lever.
x Pull and hold the lever again and immediately pull back and hold the driver door switch ⇒ fig. 175
(1) until the CSC roof has completely closed and locked.
It takes a few seconds for the closing process to start after you pull both controls. A tone sounds and
the indicator light X in the instrument cluster display lights up during the emergency closing process.
There may also be a message in the instrument cluster display.
The closing process is immediately interrupted if you let go of the lever or the switch or if one of the
cancel conditions changes ( 324, Cancel conditions for emergency closing). The process can be
restarted by again pulling the center console lever and the switch in the driver door.
x After emergency roof closing is complete, continue to hold the lever and switch to close all
windows.
x OR: After emergency closing, pull switch (1).
x OR: Insert the key in the lock of the driver's door, turn in the closing direction, and hold until all
windows are closed.
x Have the vehicle checked immediately by an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility.
Cancel conditions for emergency closing
Emergency closing the CSC roof is canceled if any of the following situations occurs:
x The lever in the center console or the switch in the driver door is released.
x The ignition is switched off.
x Any door is shut.
x The vehicle battery voltage is less than 9 Volts.
x The luggage compartment lid is closed before the roof frames are locked into the mountings on the
windshield.
x The vehicle moves at a speed greater than about 0.6 mph (1 km/h).
x The outside temperature is below +5° F (- 15° C).
Emergency closing using the lever-switch combination is possible only if the CSC control unit has
detected a malfunction that is caused by one of the listed feasible problems 324, Possible situations
for emergency closing.

Do not interrupt the emergency CSC roof closing process once you have initiated it unless this is
absolutely necessary.
If the CSC roof gets stuck while opening or closing, it may be possible to close it using the
emergency process before it lowers itself automatically.
Stowing the Automatic Rollover Support System®

Fig. 176 Deployed rollover protection support behind the rear seat backrest.

Vehicle tool kit

Storage

Fig. 179 Luggage compartment with luggage compartment cover 1 and floor covering 2 folded up.

Fig. 180 Tool box 1 and restraining strap 2 on the floor of the luggage compartment 1.

Completely retract the jack after use. Otherwise it will not fit in its compartment and cannot be
stowed safely.
Contents

Fig. 181 Contents of the vehicle tool kit.

Wheel covers

Hubcaps

Fig. 182 Pulling off hubcap.

Fig. 183 Twisting off the hubcap.
