VOLKSWAGEN GOLF 2013 5G / 7.G User Guide

Applicable only in the United States
Instrument cluster

Instrument explanations ⇒ fig. 11:
(1) Button for setting the instrument cluster clock1.
– With the ignition on, push the

Instrument explanations ⇒ fig. 12:
(1) Button for setting the instrument cluster clock2.
– With the ignition on, push the

x Warning and information texts
x Odometer displays
x Time
x Outside temperature
x Compass display
x Open door, engine hood, or rear hatch ⇒ fig. 13
x Selector lever position
x Multi-Function Indicator (MFI) and menus for different settings
x Service reminder display 22
x Alternative speed display (Settings menu)
Compass

Fig. 14 Compass zones.

x Select the compass zone according to the current location ⇒ fig. 14.
x Adjust and confirm compass zone (1-15) by using the arrow buttons.
Calibrating the compass
In order to calibrate the compass, you need a valid compass zone for the location and enough room to
drive in a circle.
x Switch on the ignition.
x Select the Settings menu followed by the Compass and Calibration menu items.
x Confirm the Please drive a full circle to calibrate message by pressing the OK
button on the multi-function steering wheel, and then drive in a complete circle at about 6 mph
(10 km/h).
During calibration, CAL is shown in the instrument cluster display. The calibration is complete when
the compass direction is displayed.
Service reminder display

Resetting the service reminder display
If the service was not performed by an authorized Volkswagen dealer or an authorized Volkswagen
Service Facility, the service reminder can be reset as follows:

Vehicles with Premium text message display:
Select the Settings menu.
In the Service submenu, select the Reset menu item.
Confirm request by pressing the OK button on the multi-function steering
wheel.


Vehicles with Basic text message display:
Switch off the ignition.
Push the E

Volkswagen Information System

Menu structure – overview

Both mirrors
– Factory setting
– Back
▪ Lights & Vision
– Footwell light
– Conv. turn sig. (convenience turn signal)
– Factory setting
– Back
▪ Time
– Hours
– Minutes
– 24 hr. mode
– Daylight save
– Back
▪ Snow tires (winter tires)
– On
– + 5 mph (10 km/h)
– - 5 mph (10 km/h)
– Back
▪ Units
– Temperature
– Consump./dist.
– Back
▪ Alt. speed dis. (alternative speed display On / Off)
▪ Service
– Info
– Reset
– Back
▪ Factory setting
Using the instrument cluster menus

Fig. 15 In vehicles without a multi-function steering wheel: Use button 1 in the windshield wiper lever to
confirm menu items and rocker switch 2 to switch menus.

Fig. 16 Right side of the multi-function steering wheel (if applicable): Controls for the menus in the instrument
cluster.
