VOLKSWAGEN GOLF 2013 5G / 7.G Owner's Guide

Maximum power
output (SAE net)
Injection
technology
Engine
ID
code
Maximum torque (SAE net) No. of cylinders
Displacement
170 hp at 5700 rpm
(125 kW at
5700 rpm)
CBTA
CBUA
2.5L
177 lb-ft at 4250 rpm
(240 Nm at 4250 rpm)
5 cylinders
151 CID
(2480 ccm)
256 hp at 6000 rpm
(188 kW at
6000 rpm)
TSI® CRZA
2.0L
243 lb-ft at 2,400 – 5,200 rpm
(330 Nm at 2400 – 5200 rpm)
4 cylinders
121 CID
(1984 ccm)

Diesel engines

Maximum power
output (SAE net)
Injection
technology
Engine
code
Maximum torque No. of cylinders
Displacement
140 hp at 4,000 rpm
(103 kW at 4,000 rpm
with DPF)
TDI® CJAA
2.0L
236 lb-ft at 1750 rpm
(320 Nm at 1750 rpm)
4 cylinders
120 CID
(1968 ccm)

Dimensions

Vehicle key set

Remote control vehicle keys

Fig. 19 Remote control vehicle key with panic button.

Canadian customers can contact an authorized Volkswagen dealer or Volkswagen Service Facility or
call the Volkswagen Canada Customer CARE Center at 1-800-822-8987.
NOTICE
The remote control vehicle keys contain electrical components. Protect them from damage,
moisture and rough handling.
Do not press the buttons on the remote control vehicle key unless you actually want to use the
function in question. Since terrain and conditions vary, pressing a button on the remote control vehicle
key when it is not necessary may unlock the vehicle or set off the panic alarm, even if you think you
are out of range.
Remote control vehicle key functions can be temporarily disrupted by interference from
transmitters near the vehicle that use the same frequency range (such as radio equipment or cellular
phones).
Things between the remote control vehicle key and vehicle, bad weather, as well as a weak
battery can reduce the operating range.
If the remote control vehicle key buttons 46 or the power locking buttons 47 are pushed
repeatedly in quick succession, the power locking system is switched off for a brief period to help keep
it from being overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the rear
hatch is opened in this span of time, the vehicle is automatically locked afterwards.
Mechanical key

Fig. 20 Mechanical key.

Indicator light in the remote control vehicle key

Fig. 21 Indicator light in the remote control vehicle key.

Power locking and closing system

Description of the power locking system

overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the rear hatch is
opened during this time, the vehicle is automatically locked afterwards.
Unlocking or locking the vehicle from the outside

Fig. 24 Remote control vehicle key with panic button.

Unlocking or locking the vehicle from the inside

Fig. 25 In the driver and front passenger doors: Power locking button.
