VOLKSWAGEN GOLF GTI 2013 5G / 7.G Owners Manual

Luggage compartment
Introduction
In this section you’ll find information about:
Folding the rear seat backrest forward and back into place
Luggage compartment cover
Luggage compartment pass-through
Tie-downs
Shopping bag hooks
Always stow heavy objects in the luggage compartment and make sure that the rear seat backrests
are securely latched in their upright position. Always secure objects to the tie-downs with suitable
straps. Never overload the vehicle. Remember that the vehicle load, as well as how it is distributed,
can affect vehicle handling and braking ⇒ .
More information:
x Safety belts
x Airbag system
x Lights
x Transporting
x Trailer towing
x Tires and wheels
WARNING
An open or unlocked luggage compartment poses special risks for children.
x Close and lock the rear hatch and all doors when the vehicle is not in use. First, make
certain that no one is left inside.
x Never leave your vehicle unattended or let children play around the vehicle, especially
with the rear hatch left open. A child could crawl into the vehicle and pull the hatch shut,
becoming trapped and unable to get out. This could cause severe or fatal injuries.
x A closed vehicle can become very hot or very cold, depending on the season.
Temperatures can quickly reach levels that can cause unconsciousness or death, particularly
to small children.
x Never let children play in or around the vehicle.
x Never let anyone ride in the luggage compartment.

WARNING
Unsecured or incorrectly stowed items can fly through the vehicle, causing serious personal
injury during hard braking or sharp steering or in an accident. Loose items can also be struck
and thrown through the passenger compartment by the front airbags if they inflate. To help
reduce the risk of serious personal injury:
x Always stow all objects securely in the vehicle. Always put luggage and heavy items in the
luggage compartment.
x Always secure objects in the passenger compartment properly with suitable straps so that
they cannot move into the deployment zone of a side or front airbag during sudden braking,
in a sudden maneuver, or in a collision.
x Always keep storage compartments closed while driving.
x Never stow hard, heavy, or sharp objects in the vehicle's open storage compartments, on
the luggage compartment cover, or on the top of the instrument panel.
x Always remove hard, heavy, or sharp objects from clothing and bags in the vehicle
interior and stow them securely in the luggage compartment.
WARNING
Transporting heavy objects causes the handling characteristics of the vehicle to change and
increases braking distances. Heavy loads which are not properly stowed or secured in the
vehicle can lead to a loss of vehicle control and cause serious personal injury.
x Transporting heavy items causes the handling characteristics of the vehicle to change by
shifting the vehicle's center of gravity.
x Always distribute luggage evenly and as low as possible within the vehicle. The vehicle
capacity weight figures apply when the load is distributed evenly in the vehicle (passengers
and luggage).
x Always stow luggage and heavy items in the luggage compartment as far forward of the
rear axle as possible and secure them with appropriate straps to the tie-downs provided.
x Never exceed the vehicle's Gross Vehicle Weight Rating or Gross Axle Weight Ratings,
which are printed on the Safety Compliance Certification Label located on the door jamb of
the driver door. Exceeding the permissible weight can cause the vehicle to skid and behave
differently.
x Always adapt your speed and driving style to accommodate your payload and its weight
distribution within your vehicle.
x Be especially cautious and gentle when stepping on the accelerator pedal and avoid
sudden braking and other maneuvers.
x Brake earlier than you would if you were not driving a loaded vehicle.
NOTICE
The defroster heating wires or antenna in the rear window can be damaged by objects that rub
against them.

Folding the rear seat backrest forward and back into place

Fig. 97 Rear seat backrest: release button 1; red mark 2.

WARNING
Improper folding and improper latching of the rear seat backrest can cause serious personal
injury.
x Always make sure there are no people or animals in the area around the rear seat backrest
when folding it forward.
x Never fold the rear seat backrest forward or back while the vehicle is moving.
x When folding the rear seat backrest back up, make sure that the safety belt does not get
caught or damaged.
x Keep hands, fingers, feet and other body parts out of the way when folding the rear seat
backrest forward or back.
x Each rear seat backrest must be securely latched in the upright position so that the safety
belts on the rear seats can provide protection. This is particularly the case for the middle seat
on the rear seat bench.
x If a seat is used with an unsecured backrest, the passenger will move forward together
with the rear seat backrest during sudden braking, driving maneuvers, or in a collision.
x If the red marking on the button (2) is visible, this indicates that the backrest is not latched
into place. Always check to make sure that the red marking is not visible whenever the rear
seat backrest is in the upright position.
x No one, including children, may ride on the rear seats if the rear seat backrest is folded
down or not correctly latched.
NOTICE
Before folding the rear seat backrest forward, adjust the front seats so that the rear seat's head
restraint or backrest cushion will not touch the front seats.
Luggage compartment cover

Fig. 98 In the luggage compartment: Installing and removing the luggage compartment cover.

Removing the luggage compartment cover
x Unhook the supporting straps from the rear hatch ⇒ fig. 98 (top arrows).
x Pull the luggage compartment cover back and out of the side brackets (bottom arrows).
Installing the luggage compartment cover
x Slide the luggage compartment cover forward into the side brackets (bottom arrows).
x Hook the supporting straps onto the rear hatch (top arrows).
WARNING
In a sudden braking or other maneuver, or in a collision, unsecured or improperly secured
objects or animals on the luggage compartment cover can cause serious personal injury.
x Never leave hard, heavy or sharp objects in bags or loose on the luggage compartment
cover.
x Never let animals ride on the luggage compartment cover.
NOTICE
To help prevent damage to the luggage compartment cover, the luggage compartment may
only be loaded to a height at which the luggage compartment cover will not press on the cargo
when the rear hatch is closed.
Luggage compartment pass-through

Fig. 99 In the rear seat backrest: Opening the luggage compartment pass-through.

Fig. 100 In the luggage compartment: Opening the pass-through.

Tie-downs

Fig. 101 In the luggage compartment: Tie-downs.

WARNING
Elastic straps have to be stretched when being attached to the tie-downs in the luggage
compartment. Hooks on these straps can cause serious personal injury if not handled
properly and attached securely.
x Always protect eyes and face from injury from the hooks when attaching them to the tie-
downs in the luggage compartment.
x Always hold the hooks on elastic straps firmly when attaching to the vehicle and do not let
them snap back and hit you.
x First attach the hooks on the straps to the tie-downs at the rear seat backrest in the
luggage compartment and then to the tie-downs near the loading edge of the luggage
compartment. This way, if one of the hooks on the elastic straps snaps back, it will move
away from you, decreasing the risk of personal injury.
The maximum load for the tie-downs is about 380 lbs. (172 kg).
For suitable straps and luggage stowage systems, please see an authorized Volkswagen dealer
or authorized Volkswagen Service Facility.
Shopping bag hooks

Fig. 102 In the luggage compartment: Shopping bag hooks.

NOTICE
The maximum load for each shopping bag hook is 5 lbs. (2.5 kg).

Roof rack
Introduction
In this section you’ll find information about:
Attaching the roof rack base carrier and roof rack
Securing a load on the roof rack
The roof of your vehicle has been designed to optimize aerodynamics and does not have traditional
rain gutters that are used to attach many kinds of roof racks.
Since the rain gutters are molded into the roof to provide efficient aerodynamics, only Volkswagen-
approved base carrier mounts and roof racks can be used.
When should the roof rack be removed?
x When it is no longer needed.
x Before driving through an automatic car wash.
x When the vehicle would otherwise be too high for minimum clearance to enter, for example, a
garage.
More information:
x Lights
x Transporting
x Saving fuel and helping the environment
x Tires and wheels
x Parts, accessories, repairs and modifications
WARNING
Transporting heavy or bulky loads on the roof rack will change the way the vehicle handles
by shifting the vehicle's center of gravity and increasing the wind drag.
x Always secure the load properly with suitable and undamaged straps so that the load will
not shift.
x Cargo that is large, heavy, bulky, long or flat will have a negative effect on the vehicle's
aerodynamics, center of gravity and overall handling.
x Always avoid sudden maneuvers and hard braking.
x Always adapt your speed and driving to the heavier load and the weight distribution in the
vehicle. Take road, weather, traffic, and visibility conditions into account as well.
NOTICE
x Always remove the roof rack before driving through an automatic car wash.
x Your vehicle is higher when the roof rack is installed, especially when it is loaded. Compare
the vehicle height with existing clearance heights, such as underpasses and garage doors.
x Always make sure that the roof rack system and anything being carried on it does not
interfere with the roof antenna, the power sunroof or the rear hatch.
x Make sure that the rear hatch does not touch items on the roof rack when opened.
If a roof rack is installed, fuel consumption increases due to increased air resistance.
