VOLKSWAGEN GOLF PLUS 2015 Owner´s Manual

Signal chimes
When the vehicle approaches an obstacle located in the range of the ultrasonic sensors, there are audible signal chimes. An intermittent signal chime means that a sufficiently short distance between the vehicle and an obstacle is detected. The shorter the distance, the shorter the intervals between the chimes. The signal chime will sound continuously if the obstacle is very close.
When there is an imminent risk of collision at the front area of the vehicle, the signal chimes beep at the front of the vehicle. When there is a risk of imminent collision at the rear area of the vehicle, the signal chimes beep at the rear of the vehicle.
If you continue to drive the vehicle closer to the obstacle despite a continuous signal chime, the system will no longer be able to measure the distance.
The intermittent signal chime volume decreases after a few seconds if the distance remains the same. The volume remains constant if the signal chime is continuous. As soon as the vehicle moves away from an obstacle again, the intermittent signal chime switches off automatically. If the vehicle moves towards an obstruction again, the intermittent signal chimes beep automatically.
Display
The graphic on the screen displays the scanned areas in several segments. The closer the vehicle drives towards an obstacle, the closer the segment will move to the vehicle in the display. The collision area has been reached at the latest when the second to last segment is displayed. Do not keep driving!

Vehicles with PDC at the front and rear
Area of the vehicle Distance of the vehicle from an obstacle
Signal tone Segment color if an obstacle has been detected color display only)
(A) Rear center Obstacle not in the vehicle’s path
about 12 – 63 in. (31 – 160 cm) – Grey
Rear side about 12 – 23 in. (31 – 60 cm)
(B) Front center about 12 – 47 in. (31 – 120 cm)
Front side about 12 – 23 in. (31 – 60 cm)
(A) Rear center Obstacle in the vehicle’s path
about 12 – 63 in. (31 – 160 cm) Intermittent tone Yellow
Rear side about 12 – 23 in. (31 – 60 cm)
(B) Front center about 12 – 47 in. (31 – 120 cm)
Front side about 12 – 23 in. (31 – 60 cm)

Vehicles with PDC at the front and rear
Area of the vehicle Distance of the vehicle from an obstacle
Signal tone Segment color if an obstacle has been detected color display only)
(A), (B) Obstacle outside of the collision area about 0 – 12 in. (0 – 30 cm) Intermittent tone Red
(A), (B) Obstacle in the collision area about 0 – 12 in. (0 – 30 cm) Constant tone Red

WARNING
Do not allow the images shown on the screen to distract you from the traffic around you.
NOTICE
Failure to observe the illuminated text messages can lead to the vehicle being damaged.
It can take a few seconds before the area scanned by the sensors is displayed on the screen of the factory-installed Infotainment system.
Applicable only in the United States
PDC menu

Function button: action
Front volume : Different volumes can be set separately for the signal chimes for the front by tapping
the - or + function keys, or by adjusting the control.
Front pitch : Different pitches can be set for the signal chimes for the front by tapping the - or + function keys, or by adjusting the control.
Rear volume : Different volumes can be set for the signal chimes for the rear by tapping the - or + function keys, or by adjusting the control.
Rear pitch : Different pitches can be set for the signal chimes for the rear by tapping the - or + function keys, or by adjusting the control.
Audio lowering : Setting the level to which the Infotainment system volume should be reduced when the PDC is active.

Audio volume reduction

Menu option Explanation
Off The volume in the Infotainment system is not reduced.
Low The volume in the Infotainment system is reduced slightly.
Medium The volume in the Infotainment system is reduced to medium.
Strong The volume in the Infotainment system is reduced to a minimum.

Muting the Park Distance Control volume
You can mute the PDC beeping signals by tapping the  function key on Infotainment system screen (if applicable). Tap the function key again to reactivate the acoustic signals.
Switching Park Distance Control back on after it was switched off reactivates the volume. System malfunction warning signals cannot be switched off.
If you manually deactivate the display, PDC remains on and the sound is reactivated.
The mute setting is active if the PDC was switched on using the  button when the selector is in Park (P).

Heating and air conditioning

WARNING
Poor visibility increases the risk of collisions and other accidents that cause serious personal injuries.
x Always make sure all windows are clear of ice, snow and condensation for good visibility to the front, sides, and rear.
x Maximum heating output and defrosting performance are not possible until the engine has reached operating temperature. Wait until you have good visibility before driving off.
x Always make sure you know how to properly use the climate control system as well as the rear window defroster that you will need for good visibility.
x Never use air recirculation for long periods of time. When the air conditioner is off and recirculation mode is on, condensation can quickly form on the windows and greatly reduce visibility.
x Always switch off recirculation mode when it is not needed.
WARNING
Stale air causes driver fatigue and reduces driver alertness, which can cause accidents, collisions and serious personal injury.
x Never switch off the fan for a long period of time and never use air recirculation for a long period of time because no fresh air will enter the passenger compartment.
NOTICE
x If you think the air conditioner is not working properly or may be damaged, switch it off to help prevent more damage. Have the air conditioner checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
x Air conditioner repair requires specialized knowledge and special tools. Volkswagen recommends that you see an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
x Do not smoke when air recirculation is switched on. Smoke drawn into the ventilation system can leave residue on the evaporator and on the dust and pollen active carbon filter, resulting in permanent odors whenever the air conditioner is switched on.
If the air conditioner is switched off, the fresh outside air will not be dehumidified. To help keep the windows from fogging over, Volkswagen recommends leaving the air conditioner (compressor) switched on. Press the !

Emergency starting and starting the engine with a very weak vehicle battery or after the vehicle battery has been replaced may change or delete system settings (including time, date, personal convenience settings, and programming). Check the settings and correct as necessary once the vehicle battery has built up a sufficient charge.
Manual controls

Fig. 149 In the center console: Manual air conditioning controls.

Button/Knob More information: Manual air conditioning ⇒ fig. 149
= Rear window defroster: Works only when the engine is running and switches off automatically after 10 minutes or less.
3 Air recirculation mode ⇒ page 281.
A, [ Buttons for seat heating ⇒ page 88.
!

Button/Knob More information: Climatronic ⇒ fig. 150.
Fan (2)

WARNING
Stale air causes driver fatigue and reduces alertness, which can cause accidents, collisions, and serious personal injury.
x Never switch off the fan for a long time because no fresh air will enter the passenger compartment.
Operation via the Infotainment system

The air conditioner is most efficient when the windows and the power sunroof are closed. If the vehicle is stationary and the passenger compartment becomes very hot due to sunlight, briefly opening the windows and the power sunroof may speed up the cooling process.
Keep the air intake slots in front of the windshield free of ice, snow, and leaves so that the heating and ventilation systems can work properly.
Settings for optimum visibility
When you switch on the cooling system, both the temperature and humidity in the vehicle are reduced. This will help make passengers feel more comfortable and help keep the windows from fogging up.
For manual air conditioning
x Switch off the air recirculation ⇒ Air recirculation.
x Set the fan to the desired speed.
x Turn the temperature knob to the center position.
x Open and adjust all air vents in the instrument panel ⇒ Air vents.
x Turn the air distribution knob to the desired setting.
x Push the !
