VOLKSWAGEN JETTA 2013 1B / 6.G User Guide

Applicable only in the United States
Symbols on the roof console

Symbol Meaning
*  / s  Interior and reading lights .
g c h Power sunroof .
a
/ Three-button module ⇒Booklet Mobile Phone Package.

Applicable only in Canada
Symbols on the roof console

Symbol Meaning
*  / s  Interior and reading lights .
g c hª ¯ Power sunroof

Instrument cluster

– To advance the clock, push the E

– To advance the clock, push the E

For information on maintenance intervals, please see the ⇒Booklet Warranty and Maintenance.
For vehicles with time- or distance driven-dependent service, only fixed service intervals are dis-
played.
Service reminder
If service is due in the near future, a service reminder is displayed when the ignition is switched on.
On vehicles without text messages, a wrench symbol > and a miles (kilometers) indicator are
shown in the instrument cluster display. The distance shown in miles (kilometers) is the maximum
distance the vehicle can be driven without having a service completed. The display changes after a
few seconds. A clock symbol is displayed and the number of days until the required service is shown.
Service event
When service is due, a warning chime sounds when the ignition is switched on, and a flashing
wrench symbol > is displayed for several seconds.
Viewing service message
The current service message can be accessed when the ignition is switched on, the engine is
switched off, and the vehicle is stopped:
x Push the

Volkswagen Information System

The instrument cluster display is divided into 3 parts. The time (digital clock) is displayed in the top
part. The bottom part contains the odometer and the trip odometer (“trip”). You can select the following
displays for the middle part:
 -- mi (fuel range estimate)
-- miles (trip memory 1 and 2)
ø -- mph (average speed)
-- mph (digital speed display)
c-- mph (speed warning)
--°F (outside temperature)
-- h/min (travel time)
-- mpg (current fuel consumption)
ø-- mpg (average fuel consumption)
Applicable only in Canada
Menu structure – overview

Applicable only in the United States
Using the instrument cluster menus

Fig. 12 On the windshield wiper control stalk: control buttons 1 and 2 on the windshield wiper lever.

▪ Push the /+

▪ A warning chime will sound you if you reach the set speed; there may also be a visual message.
▪ The set speed will blink for a few seconds after you toggle to xx km/h.
▪ Press the 42)0 rocker switch (2) while the set speed is blinking to increase or decrease the speed.
--°C: Current outside temperature
-- h/min: Travel time since last reset of trip memories 1 and 2.
▪ Push the /+
