VOLKSWAGEN JETTA 2013 1B / 6.G Service Manual

x OR: The vehicle is unlocked using the 0 button in the remote control vehicle key.
x OR: The luggage compartment lid is opened.
x OR: The vehicle is mechanically unlocked with the vehicle key.
NOTICE
The door handle sensor surfaces can be activated by a strong stream of water or steam if a
valid vehicle key is within range of the vehicle.
The door may not open if the outside and inside door handles are used at the same time.
If the vehicle battery or the battery in the remote control vehicle key is weak or dead, it might not
be possible to unlock and lock the vehicle using Keyless Access. The vehicle can still be manually
locked or unlocked with the key bit .
The driver message Key not in range appears in the instrument cluster display if there is no
remote control vehicle key inside the vehicle or if the system does not recognize the remote control
vehicle key. The key may not be recognized, for example, if it is covered by something that interferes
with the signal (such as a briefcase), or if the remote control vehicle key battery is weak. Electronic
devices such as cell phones can also interfere with the signal.
Dirt on the door handles that contains a lot of salt (especially in winter) can affect the way the door
handle sensors work. Cleaning the door handles can help with this problem .
If the automatic transmission is not in Park (P) position, the electronic steering column lock will not
lock and the vehicle will not lock via sensors in the front door handles or the remote control vehicle
key.
Anti-theft alarm system

x Forcibly opening the luggage compartment lid.
x Switching on the ignition with an invalid key.
x Disconnecting the vehicle battery.
Deactivating the alarm
Unlock the vehicle with the unlock button on the remote control vehicle key or switch on the ignition
with a valid vehicle key.
For vehicles with Keyless Access, the alarm can be deactivated by grasping one of the front door
handles when a valid vehicle key is in range or by holding the remote control vehicle key to the right of
the steering column trim and pressing the starter button .
After the alarm has stopped and the vehicle is opened again in the same or a different area that is
protected by the alarm, the alarm is triggered again. For example, the alarm will sound again if the
luggage compartment lid is opened after one of the doors has been opened.
The anti-theft alarm system is not activated when the vehicle is locked with the power lock
switch 1 on the inside of the driver or front passenger doors.
If the driver door is mechanically unlocked using the vehicle key bit, only the driver door is un-
locked, not the entire vehicle. Switching on the ignition deactivates the anti-theft alarm system and
activates the central locking button. To unlock the doors, use the central locking button or remote
control vehicle key.
If the vehicle battery is dead or weak, the anti-theft alarm system will not work properly.

Doors

Child safety lock

Fig. 25 In the left rear door: Child safety lock A deactivated, B activated.

Fig. 26 In the right rear door: Child safety lock A deactivated, B activated.

WARNING
When the child safety lock is engaged, that rear door cannot be opened from the inside.
x Never leave children, disabled persons, or anyone who cannot help themselves, in the
vehicle when locking the doors. This could result in people being locked in the vehicle. This
could result in people being trapped in the vehicle in an emergency. Depending on the time
of year, people trapped in the vehicle can be exposed to very high or very low temperatures.
x A closed vehicle can become very hot or very cold, depending on the season. Particularly
in the summer, heat build-up in the passenger and luggage compartment of a parked vehicle
can result in temperatures in the vehicle that are much higher than the outside temperatures.
Temperatures can quickly reach levels that can cause unconsciousness and death, particu-
larly to small children.

Luggage compartment lid

Opening the luggage compartment lid

Fig. 27 A: Button to unlock and open the luggage compartment lid in the remote control vehicle key. B:
Button to unlock and open the luggage compartment lid in the driver door.

Fig. 28 Opening luggage compartment lid from the outside.

x Lift the luggage compartment lid slightly at the button ⇒fig. 28 (arrow). The luggage compartment
lid opens automatically.
WARNING
Improper or unsupervised unlocking or opening of the luggage compartment lid can cause
severe injuries. Never open the luggage compartment lid when someone is in the way.
x If a bicycle or luggage rack is installed on the luggage compartment lid, it may be hard to
see that the luggage compartment lid is unlatched. An unlatched luggage compartment lid
may open suddenly when the vehicle is moving.
At temperatures below +32 °F (0 °C), the luggage compartment lid may not open automatically
after you unlock it. It will be necessary to lift it by hand.
Closing the luggage compartment lid

Fig. 29 Opened luggage compartment lid: Recessed grips for closing.

x A closed but unlocked luggage compartment lid automatically locks at speeds above about 5 mph
(10 km/h).
WARNING
Improper or unsupervised closing of the luggage compartment lid can cause severe injuries.
Never close the lid when someone is in the way.
x Never leave your vehicle unattended or let children play around your vehicle, especially
with the luggage compartment lid left open. A child could crawl into the vehicle and pull the
luggage compartment lid shut, becoming trapped and unable to get out. A closed vehicle can
become very hot or very cold depending on the season. Temperatures can quickly reach
levels that can cause unconsciousness or death, particularly to small children.
Make sure that the remote control vehicle key is not in the luggage compartment before closing
the luggage compartment lid.

Power windows
