VOLKSWAGEN JETTA 2015 Owners Manual

Display
Different cruise control versions are available. The stored speed is shown in the instrument cluster display on some equipment versions.
Status fig. 137
(A) Cruise control temporarily deactivated. Stored speed displayed in small numbers.
(B) System malfunction. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
(C) Cruise control activated. No speed stored in memory.
(D) Cruise control is active. Stored speed displayed in large numbers.
Indicator lights

Lights up Possible cause
% Cruise control is regulating the vehicle speed. #25)3%

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Cruise control operation

Fig. 138 Left-hand side of the multi-function steering wheel: Buttons for operating the cruise control .

In order to: You must: ⇒ fig. 138 Result:
Press and hold the

Rear View Camera system

WARNING
The Rear View Camera system technology cannot overcome the laws of physics and the limits of the system. Careless or unintentional use of the Rear View Camera system may result in accidents and severe injuries.
x Always adjust your speed and driving style to road, traffic, weather, and visibility condi-tions.
x Always keep an eye on the parking direction and the vehicle surroundings. The front of the vehicle swings out more than the rear of the vehicle.
x Never pay so much attention to the graphics shown on the screen that you fail to notice what is going on around you.
x Always watch for people, especially small children, animals, and objects, because the Rear View Camera system may not always be able to detect them.
x The system may not be able to clearly show everything behind the vehicle.
x Use the Rear View Camera system only when the luggage compartment lid is completely closed.
NOTICE
x The Rear View Camera system shows only two-dimensional images on the screen. Due to the lack of depth of field, it may be difficult or impossible to identify protruding objects or recesses in the road, for example.
x Things like thin rods, fences, posts, and trees may not be detected by the Rear View Cam-era system and could damage the vehicle.
Special considerations

x Park the vehicle in a safe place on a firm, level surface.
x Apply the parking brake to help prevent the vehicle from moving ⇒  Parking brake.
x Switch on the ignition.
x Switch on the radio or the navigation system (if not already on) ⇒ Booklet Radio or
⇒ Booklet Navigation system.
x Shift into Reverse (R).
x Tap the function key.
x Adjust the desired settings in the menu.
Camera

Fig. 139

x Wet the camera lens with a commercially available alcohol-based glass cleaner and clean with a
dry cloth ⇒ .
x Remove snow with a brush.
x Remove ice with deicer spray ⇒ .
NOTICE
x Never use abrasive cleaning agents to clean the camera lens.
x Never remove snow or ice on the camera lens with warm or hot water. This can damage the camera lens.
Operation

Fig. 140 Rear View Camera system display (may vary depending on vehicle equipment).

Function Action with the ignition on
Switch off the display manually:
Press a function selection button on the radio or the navi-
gation system ⇒ Booklet Radio or ⇒ Booklet Navigation
system.
OR: Tap the O function button on the screen.
Show the display again: Shift out of Reverse (R), then shift back into Reverse (R).

Parking

Fig. 141 On the screen: Static orientation lines for the parking space behind the vehicle.

Parking using the Rear View Camera system

Step Action:
1. The requirements for parking and maneuvering with the Rear View Camera system
must be fulfilled ⇒ page 255.
2. Position the vehicle in front of the parking space (2) ⇒ fig. 141 A.
3. Shift into Reverse (R).
4. Reverse slowly and steer the vehicle B so that the lateral yellow orientation lines lead into the parking space (2).
Pay attention to the message in the display: Always make sure it is safe to
back up! ⇒  on page 254
5. Align the vehicle in the parking space B so that the yellow orientation lines are parallel with the parking space (3).
6. Stop the vehicle C before (or at the very latest, when) the horizontal yellow line reaches the rear boundary, for example, a curb (4).

NOTICE
Smaller objects up to about 20 inches (50 cm) from the rear of the vehicle will not be detected by the camera and could result in vehicle damage.

Blind Spot Monitor with Rear Traffic Alert
