VOLKSWAGEN JETTA GLI 2014 1B / 6.G Owners Manual

Manually locking the passenger doors

Fig. 154 On the front side of the right rear door: Emergency lock, covered by a rubber seal.

Fig. 155 On the front side of the right rear door: Locking the vehicle with the key bit in the vehicle key.

Opening the luggage compartment lid from inside the luggage
compartment

Fig. 156 Behind the rear seat backrest: Release of the rear seat back.

Fig. 157 Opening the luggage compartment lid from inside the luggage compartment.

There is no emergency release for the fuel filler flap. Contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
Emergency closing of the power sunroof

Fig. 158 In headliner: Removing cover.

Fig. 159 Hexagonal head screw for closing the power sunroof.

2. Insert a commercially available 1/6 in. (4 mm) Allen wrench7 into the hexagonal head screw
⇒ fig. 159 (1).
3. Turn the wrench counterclockwise to close the power sunroof.
4. Install the cover again.
5. Have the power sunroof checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. Emergency closing may cause the power sunroof and its pinch protection to malfunction.
Emergency release for the selector lever lock

Fig. 160 Removing the selector gate cover.

Fig. 161 Releasing the selector lever lock.

Preparations
x Set the parking brake. If the parking brake cannot be set firmly, you must find another way to help prevent the vehicle from moving.
x Switch off the ignition.
Removing the selector gate cover
x Pull upward on the cover around the selector lever sleeve ⇒ fig. 160.
x Slip the cover up and over the selector lever ⇒ .
Emergency release for the selector lever
x Push the colored release lever ⇒ fig. 161 in the direction of the arrow and hold it in this position.
x Press the release button in the selector lever handle and shift the selector lever to Neutral (N).
x Carefully press the selector gate cover back in place, making sure that the electrical wiring stays in the correct position and is not pinched or damaged.
WARNING
Never shift the transmission out of Park (P) without first firmly applying the parking brake. Otherwise, the vehicle can start to roll unexpectedly, especially on hills or inclines, and cause an accident and serious injuries.
NOTICE
Even with the selector lever is in Neutral (N), the automatic transmission will be damaged if the vehicle is towed (or you let it coast) for an extended period or at high speed with the engine shut off.

Vehicle tool kit

The vehicle tool kit is in the luggage compartment in one of several places, such as under the luggage
compartment floor panel ⇒ fig. 162.
x Open the luggage compartment lid, Luggage compartment.
x Grasp the floor panel by the handle and lift it up in the direction of the arrow ; remove it if necessary.
Completely retract the jack after use. Otherwise it will not fit in its compartment and cannot be stowed safely.
Contents

Fig. 163 Contents of the vehicle tool kit.

Wheel trim

Hubcaps

Fig. 164 Pulling the hubcap off.

Fig. 165 Twisting the hubcap off.

Wheel bolt caps

Fig. 166 Pulling cover caps off wheel bolts.
