VOLKSWAGEN JETTA SPORTWAGEN 2014 1B / 6.G Owners Manual

Side view

Fig. 1 Vehicle side overview.
Key to fig. 1:
(1) Fuel filler flap
(2) Roof antenna
(3) Outside door handles
(4) Outside mirror
– Additional turn signal light
(5) Lift points for the jack
(6) Roof rails
(7) Side marker light

Front view

Fig. 2 Vehicle front overview.
Key to fig. 2:
(1) Inside mirror
(2) Front windshield wipers
(3) Engine hood release
(4) Headlights (on both left and right)
(5) Fog lights/static cornering lights (on both left and right, if equipped)
(6) Threaded hole for the front towing eye (behind cover)

Rear view

Fig. 3 Vehicle rear overview.
Key to fig. 3:
(1) Rear window
– Rear window defroster
(2) High-mounted brake light
(3) Taillights (on both left and right) ,
(4) Area for:
– Rear hatch release
– Rear Assist camera (if equipped)
(5) License plate lights
(6) Threaded hole for the rear towing eye (behind cover)
(7) Roof antenna
(8) Rear windshield wiper

Driver door overview

Fig. 4 Overview of controls in the driver door.
Key to fig. 4:
(1) Door handle
(2) Power locking button for locking and unlocking the vehicle 0 – 1
(3) Knob for adjusting the outside mirrors
– Adjusting outside mirrors , – / – 2
– Outside mirror heating ?
(4) Buttons for operating the power windows
– Power windows
– Safety switch for rear power windows _
(5) Indicator light for the power locking system
(6) Lever for releasing the engine hood
(7) Storage compartment
(8) Bottle holder
(9) Reflector
(10) Rear hatch release switch q

Driver side overview

Fig. 5 Driver side overview.
Key to ⇒ fig. 5:
(1) Instrument cluster:
– Instruments
– Display
– Warning and indicator lights
(2) Headlight switch

(5) Multi-function steering wheel controls (if equipped)
– Volume setting for radio, navigation system notifications (if applicable), or telephone calls & – '
– Mute switching for radio or activation of voice control
– Display Phone main menu or accept telephone calls -
– Audio, navigation

Center console overview
Upper center console

Fig. 6 Overview of the upper center console.
Key to fig. 6:
(1) Switch for emergency flashers
(2) PASSENGER AIR BAG OF F  light (front airbag for front seat passenger)
(3) Radio or Radio & Navigation system (factory-installed) ⇒ booklet Radio or
⇒ booklet Navigation system
(4) Controls for:
– Manual A/C
– Climatronic
(5) Air vents / – J
(6) Passenger seat heating button [
(7) Driver seat heating button A

Lower center console

Fig. 8 Overview of the lower center console.
Key to fig. 8:
(1) Lever for:
– Manual transmission
– Automatic transmission
(2) Parking brake lever
(3) Storage compartment with cup holders in the center console
(4) Storage compartment
– with 12 Volt socket
(5) Center armrest with storage compartment
(6) Button for:
– Anti-slip regulation (ASR) m

Front passenger side overview

Fig. 9 Overview of the front passenger side.
Key to fig. 9:
(1) Passenger front airbag location in the instrument panel (approximate)
(2) Opening handle for the glove compartment
(3) Air vent / – J
(4) Inside the glove compartment: SET button for Tire Pressure Monitoring System

Symbols on the roof console

Symbol Meaning
* / s   Interior and reading lights
g c h
# $ Power sunroof and sunshade

/ a 3-button module (if equipped) ⇒ booklet Mobile Phone Package.
