16 - Circlip Ensure seated
correctly
17 - Wheel bearing 72 mm diameter Pressing out Page 42-64 Pressing in page. Page 42-65 18 - Hex bolt, 10 Nm (7 ft lb) 19 - Backing plate
20 - Parking brake cable Adjusting parking
brake Page 46-36 21 - Spring clip
22 - Hex socket head bolt,
10 Nm (7 ft lb)
23 - Speed sensor Before inserting, clean
and coat with
lubricating paste G
000 650 Page 4 of 8Wheel bearings, servicing - disc brakes (four wheel drive vehicles)12/7/2004http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&type=repair&id=VW.B4.SU01.42.6

Downloaded from www.Manualslib.com manuals search engine 42-63

24 - Drive shaft with speed
sensor rotor Removing and
installing drive shaft
Page 42-37 and
Page 42-38 Removing and
installing rotor, Fig. 6 25 - Brake line Page 5 of 8Wheel bearings, servicing - disc brakes (four wheel drive vehicles)12/7/2004http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&type=repair&id=VW.B4.SU01.42.6

Downloaded from www.Manualslib.com manuals search engine 42-64
Fig. 1 Hub, pressing out Fig. 2 Wheel bearing, pressing out Page 6 of 8Wheel bearings, servicing - disc brakes (four wheel drive vehicles)12/7/2004http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&type=repair&id=VW.B4.SU01.42.6

Downloaded from www.Manualslib.com manuals search engine 42-65
Note:
Only use puller with leg clamp e.g. Kukko 204-2
(commercial type). Fig. 3 Inner race, pulling off of hub Note:
First install lower circlip. Fig. 4 Wheel bearing, pressing in Page 7 of 8Wheel bearings, servicing - disc brakes (four wheel drive vehicles)12/7/2004http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&type=repair&id=VW.B4.SU01.42.6

Downloaded from www.Manualslib.com manuals search engine 42-66
Note:
First install backing plate on control arm.
Tightening torque: 10 Nm (7 ft lb) Fig. 5 Hub, pressing in Fig. 6 Speed sensor rotor, pressing in - Drive rotor off outer joint using a drift (rotor will be
destroyed).
- Drive new rotor carefully onto stop using a plastic
hammer. Page 8 of 8Wheel bearings, servicing - disc brakes (four wheel drive vehicles)12/7/2004http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&type=repair&id=VW.B4.SU01.42.6

Downloaded from www.Manualslib.com manuals search engine 44-1


Vehicle alignment

Test requirements:
Measuring equipment correctly calibrated
Vehicle unladen1)

Tires inflated to correct pressure
Vehicle accurately aligned, suspension
bounced and rocked several times
Suspension, steering and steering linkage
checked for excessive play and damage.

Note:
Vehicle alignment should not be checked
before the vehicle has completed 1000 to 2000
km (600 to 1200 miles) as then the coil springs
have had time to settle.
The cause of vehicle imbalance may also be,
excessive residual imbalance and/or vertical
wheel runout.
1)
Unladened means: the weight of the vehicle
ready for the road (fuel tank completely filled,
spare wheel, vehicle tools and vehicle jack). Page 1 of 7Vehicle alignment12/7/2004http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&type=repair&id=VW.B4.SU01.44.1

Downloaded from www.Manualslib.com manuals search engine 44-2
Vehicle alignment specifications (front wheel drive vehicles) Front axle
Suspension strut axle
Engine up to 85 kW (115
hp) 110 - 128 kW
(148 - 172 hp)
Version Base suspension Plus
suspension
Total toe1)
(not pressed)
0 10' 0 10' Camber2)
(in straight- ahead position) Maximum permissible
difference between sides -1 20' 20'


max. 20' -1 10' 20'


max. 20' Toe angle difference at 20left and right lock -1 10' 30' -1 40' 30' Caster (not adjustable) Maximum permissible difference between
sides +1 40' 30'

max. 30' +3 20' 30'

max. 30' 1)
Only adjust total toe on right toe rod
2)
Camber corrections can only be made at the wheel bearing housing/suspension strut connection.
Camber adjustment Page 44-6 . Note:
After adjusting steering geometry check position of steering wheel; correct if necessary. Page 2 of 7Vehicle alignment12/7/2004http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&type=repair&id=VW.B4.SU01.44.1

Downloaded from www.Manualslib.com manuals search engine 44-3
Rear axle
Torsion beam trailing arm axle
Engine/version all
Camber1)

Maximum permissible difference between sides -1 30' 10'

max. 20' Total toe 1)
(at specified wheel camber)
Maximum permissible deviation from direction of travel +20' 10'


max. 20' 1)
not adjustable Page 3 of 7Vehicle alignment12/7/2004http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&type=repair&id=VW.B4.SU01.44.1

Downloaded from www.Manualslib.com manuals search engine 44-4
Vehicle alignment specifications (four wheel drive vehicles) Front axle
Suspension strut axle
Engine 85 kW (115 hp) 128 kW (172
hp)
Version Base
suspension Plus
suspension
Total toe1)
(not pressed)
0 10' 0 10' Camber2)
(in straight- ahead position) Maximum permissible
difference between sides -1 20' 20'


max. 30' -1 10' 20'


max. 20' Toe angle difference at 20left and right lock -1 10' 30' -1 40' 30' Caster (not adjustable) Maximum permissible difference between
sides +1 40' 30'

max. 30' +3 20' 30'

max. 30' 1)
Only adjust total toe on right toe rod
2)
Camber corrections can only be made at the wheel bearing housing/suspension strut connection.
Camber adjustment Page 44-6 . Note:
After adjusting steering geometry check position of steering wheel; correct if necessary. Page 4 of 7Vehicle alignment12/7/2004http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&type=repair&id=VW.B4.SU01.44.1

Downloaded from www.Manualslib.com manuals search engine 44-5
Rear axle
Semi-trailing arm axle
Engine 85 kW, 128 kW
(115 hp, 172 hp)
Camber1)

Maximum permissible difference between sides -1 15' 30'

max. 30' Total toe 1)
(at specified camber)
Maximum permissible deviation from direction of travel +15' 20'


max. 20' 1)
Camber and toe corrections possible using eccentric rubber mounting Repair Manual, Suspension, Wheels, Brakes, Steering, Repair Group 42 . Page 5 of 7Vehicle alignment12/7/2004http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&type=repair&id=VW.B4.SU01.44.1
