VOLKSWAGEN PASSAT 2013 B8 / 6.G Owners Manual

Emergency starting and starting the engine with a very weak vehicle battery or after the vehicle
battery has been replaced may change or delete settings (including time, date, personal convenience
settings and programming). Check the settings and correct as necessary once the vehicle battery has
built up a sufficient charge.
Controls

Fig. 157 In the center console: Manual AC controls.

Fig. 158 In the center console: Climatronic controls.

Button /
Knob More information ⇒ fig. 157 or ⇒ fig. 158.
(2)
e,

Button /
Knob More information ⇒ fig. 157 or ⇒ fig. 158.
!54/ Climatronic: Automatic control for temperature, fan and air distribution. Press the
AUTO button to activate this mode. The indicator light in the button comes on.
/&& Press the OF F button. If the system is switched off, the indicator light in the OF F
button lights up.

WARNING
Stale air causes driver fatigue and reduces alertness, which can cause accidents, collisions,
and serious personal injury.
x Never switch off the fan for a long time, because no fresh air will enter the passenger
compartment.
Air conditioner operation

Press and hold the !

Air vents
To help ensure sufficient heating, cooling and ventilation in the passenger compartment, never close
the air vents completely ⇒ fig. 159 (1).
x To open and close the air vents, turn the thumbwheel in the desired direction. When the
thumbwheel is in the ¡ position, the air vent is closed.
x Use the lever on the vent grille to adjust the airflow direction.
Additional air vents are located in the instrument panel (2), in the footwells as well as in the rear area
of the passenger compartment.
NOTICE
Do not place food, medications, or other heat-sensitive things in front of the air vents. Food,
medications, and other things that are sensitive to heat or cold can be damaged or made
unusable by the air flow from the vents.
The air coming out of the vents flows through the passenger compartment and out through vents
below the rear window. Do not cover these slots with clothing or other things.
Air recirculation

Automatic air recirculation <
In the < setting, fresh air enters the passenger compartment. If the system detects an increased
concentration of pollutants in the outside air, it automatically switches to air recirculation. As soon as
the pollutant level is back in the normal range, air recirculation is switched off.
Unpleasant odors cannot be detected by the system.
Air recirculation is not automatically activated under the following outside temperatures and
conditions:
x The outside air temperature is colder than about +38 °F (+3 °C).
x The cooling system and the windshield wiper are switched off and the outside air temperature is
cooler than about +50 °F (+10 °C).
x The cooling system is switched off, the outside air temperature is cooler than about +59 °F
(+15 °C), and the windshield wiper is switched on.
Switching automatic air recirculation on and off
Switching on: Press the  button repeatedly until the right indicator light under the button comes on.
Switching off: Press the  button repeatedly until no indicator light under the button is on.
It is not possible to activate automatic air recirculation when the outside air temperature is colder than
about +38 °F (+3 °C).
Temporarily deactivating automatic air recirculation
x Press the  button once to switch to air recirculation temporarily in the event of unpleasant odors.
The left indicator light comes on.
x Press the  button again after more than 2 seconds to resume automatic air recirculation. The
right indicator light comes on.
WARNING
Stale air causes driver fatigue and reduces driver alertness, which can cause accidents,
collisions and serious personal injury.
x Never use air recirculation mode over an extended period of time, since no fresh air will
enter the passenger compartment.
x When the air conditioner is off and recirculation mode is on, condensation can quickly
form on the windows and greatly reduce visibility.
x Always switch off recirculation mode when it is not needed.
NOTICE
Do not smoke when air recirculation is switched on. Smoke drawn into the ventilation system
can leave residue on the evaporator and on the dust and pollen active carbon filter, resulting in
permanent odors whenever the air conditioner is switched on.
Climatronic: When backing up and while the automatic wiper/washer is working, air recirculation
is briefly activated to help keep exhaust fumes from getting into the passenger compartment.

Refueling
Applicable only in the United States, Canada, and South Korea

WARNING
Even if empty, portable fuel containers can leak and cause a fire and serious personal
injuries, especially in a crash.
x For your safety, we strongly recommend that you do not travel with a portable fuel
container in your vehicle.
x If, under exceptional circumstances, you must transport a portable fuel container, please
observe the following:
– Never fill a portable fuel container while it is anywhere in or on the vehicle (for
example, in the luggage compartment or on top of the luggage compartment lid). Static
electricity can build up while filling and can ignite fuel vapors, causing a fire.
– Always place a portable fuel container on the ground before filling. Never spill fuel
inside the vehicle or luggage compartment. Fuel vapors are highly flammable.
– Always keep the filler nozzle completely inside the portable container before and
during filling.
– If filling a portable container made of metal, the filler nozzle must always be in contact
with the container. This will help prevent static electricity from discharging and causing a
fire.
– Always observe local and state or provincial laws about the use, storage, and
transportation of portable fuel containers.
– Make certain that the portable fuel container meets industry standards, such as ANSI /
ASTM F852-86.
NOTICE
x Remove fuel spills from the vehicle immediately to help prevent damage to the paint, tires,
and wheel housings.
x Refueling with gasoline when your vehicle has a diesel engine or refueling with diesel fuel
when your vehicle has a gasoline engine can cause very serious and expensive engine and
fuel system damage that is not covered by any Volkswagen Limited Warranty.
x If you put any amount of incorrect fuel in the fuel tank, do not start the engine under any
circumstances. Immediately contact the nearest authorized Volkswagen dealer or authorized
Volkswagen Service Facility for assistance. These fuels contain substances that can severely
damage the fuel system and the engine if the engine is started.
x Vehicles with diesel engines must never be refueled or driven with gasoline, kerosene,
heating oil, or other non-specified fuels that have not been expressly approved for use with the
diesel engine. Other kinds of fuel can cause serious damage to the fuel system and the engine
that is not covered by any Volkswagen Limited Warranty.
Fuels can pollute the environment. Spilled fuel must be collected and disposed of properly,
following all applicable environmental regulations.
There is no emergency release for the fuel filler flap. Contact an authorized Volkswagen dealer or
an authorized Volkswagen Service Facility for assistance.

Applicable only in Mexico and the AGCC

WARNING
Even if empty, portable fuel containers can leak and cause a fire and serious personal
injuries, especially in a crash.
x For your safety, we strongly recommend that you do not travel with a portable fuel
container in your vehicle.
x If, under exceptional circumstances, you must transport a portable fuel container, please
observe the following:
– Never fill a portable fuel container while it is anywhere in or on the vehicle (for
example, in the luggage compartment or on top of the luggage compartment lid). Static
electricity can build up while filling and can ignite fuel vapors, causing a fire.
– Always place a portable fuel container on the ground before filling. Never spill fuel
inside the vehicle or luggage compartment. Fuel vapors are highly flammable.
– Always keep the filler nozzle completely inside the portable container before and
during filling.
– If filling a portable container made of metal, the filler nozzle must always be in contact
with the container. This will help prevent static electricity from discharging and causing a
fire.
– Always observe local and state or provincial laws about the use, storage, and
transportation of portable fuel containers.
– Make certain that the portable fuel container meets industry standards, such as ANSI /
ASTM F852-86.
NOTICE
x Remove fuel spills from the vehicle immediately to help prevent damage to the paint, tires,
and wheel housings.
x Refueling with gasoline when your vehicle has a diesel engine or refueling with diesel fuel
when your vehicle has a gasoline engine can cause very serious and expensive engine and
fuel system damage that is not covered by any Volkswagen Limited Warranty.
x If you put any amount of incorrect fuel in the fuel tank, do not start the engine under any
circumstances. Immediately contact the nearest authorized Volkswagen dealer or authorized
Volkswagen Service Facility for assistance. These fuels contain substances that can severely
damage the fuel system and the engine if the engine is started.
Fuels can pollute the environment. Spilled fuel must be collected and disposed of properly,
following all applicable environmental regulations.
There is no emergency release for the fuel filler flap. Contact an authorized Volkswagen dealer or
an authorized Volkswagen Service Facility for assistance.
