VOLKSWAGEN PASSAT CC 2014 1.G Owners Manual

4. Install the cover again.
5. Have the power sunroof checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. Emergency closing may cause the power sunroof and its pinch protection to malfunction.
Emergency release for the selector lever lock

Fig. 177 Removing the selector gate cover.

Fig. 178 Releasing the selector lever lock (Versions A and B).

Removing the selector gate cover
x Pull upward on the cover around the selector lever sleeve ⇒ fig. 177.
x Slip the cover up and over the selector lever ⇒ .
Emergency release for the selector lever (Version A)
x With the screwdriver from the vehicle tool kit, carefully push the release lever ⇒ fig. 178 A in the direction of the arrow and hold it in this position.
x Press the release button in the selector lever handle and shift the selector lever to Neutral (N).
x Carefully press the selector gate cover back in place, making sure that the electrical wiring stays in the correct position and is not pinched or damaged.
Emergency release for the selector lever (Version B)
x Push the release lever B in the direction of the arrow and hold it in this position.
x Press the release button in the selector lever handle and shift the selector lever to Neutral (N).
x Carefully press the selector gate cover back in place, making sure that the electrical wiring stays in the correct position and is not pinched or damaged.
WARNING
Never shift the transmission out of Park (P) without first setting the electronic parking brake. Otherwise, the vehicle can start to roll unexpectedly, especially on hills or inclines, and cause an accident and serious injuries.
NOTICE
Even with the selector lever is in Neutral (N), the automatic transmission will be damaged if the vehicle is towed (or you let it coast) for an extended period or at high speed with the engine shut off.

Vehicle tool kit

Storage

Fig. 179 In the luggage compartment underneath the floor panel 1: Spare tire and cover 3 for vehicle tool kit.

Contents

Fig. 180 Contents of the vehicle tool kit.

Wheel trim

Hubcaps

Fig. 181 Pulling the hubcap off.

Fig. 182 Twisting the hubcap off.

Wheel bolt caps

Fig. 183 Pulling cover caps off wheel bolts.

Installing the wheel cover
Make sure that the valve cutout is aligned with the tire valve, and press the wheel cover onto the wheel rim. Make sure that the wheel cover is latched onto the rim along the entire circumference.

Changing a wheel
