VOLKSWAGEN PASSAT CC 2015 1.G Owner's Guide

Storing speed for the speed warning
Navigate to MFI > Speed warning (Speed warning -- mph or
Speed warning -- km/h) display.
Press the /+ button to save the current speed and to activate the
warning.
If the speed is not right, press buttons * or + on the multi-function
steering wheel to set a different speed within about 5 seconds. Then
press the /+ button a second time or just wait a few seconds. The
speed is saved and the warning is activated.
To deactivate, toggle to --- mph or --- km/h and press the /+ but-
ton. The set speed is deleted.
Manually erasing trip memory 1 or 2
Navigate to MFI > Route.
Select the memory to be erased.
Press the /+ button for about 2 seconds.
Enabling and disabling displays
Use the Settings menu, submenu MFI data to enable displays you
want to be available under the MFI menu in the instrument cluster
display. The units in which data is displayed can also be changed ⇒ 
Settings menu
Settings menu

Settings
menu
Function
Lights &
Vision
Vehicle lighting settings
Time Set hours and minutes for the instrument cluster
clock, the Radio & Navigation System clock, and the
analog clock. The digital clocks can be set to show
the time in 12 or 24 hour format, and can also be set
to daylight savings time.
Snow tires Set up a visual and acoustic speed warning. Use the
feature only when winter tires are installed that have
a speed rating less than top vehicle speed.
Compass Calibrate the compass on vehicles without a factory-
installed navigation system. To calibrate, follow the
instructions in the instrument cluster display
Units Set the units in which temperature, fuel consumption,
and distances should be displayed (for example,
whether to show distance driven in miles or kilome-
ters).
Service View the service reminder display
Factory
setting
Reset the functions in the Settings menu back to the
factory settings.

Lights & Vision submenu

Lights &
Vision menu
Function
Coming
Home
Set how long the headlights and inside lights stay on
after locking or unlocking the vehicle. Feature can
also be switched on or off
Leaving
Home
Footwell
light
Set footwell lighting brightness or switch this feature
on or off.
Conv. turn
sig.
Enable/disable convenience turn signal (lane change
feature). When the feature is enabled, the turn signal
flashes at least 3 times when the turn signal is tapped
Factory
setting
Resets the functions in the Lights & Vision submenu
back to the factory settings.
Back The display returns to the Settings menu.

Personal convenience settings

▪ Mirror down
Settings / Lights & Vision menu
▪ Coming Home / Leaving Home
▪ Convenience turn signal (lane change feature)
The stored settings are recalled when the ignition is switched on.
Please also see information about the memory seat ⇒ Seat functions.

Volkswagen Car-Net: Connecting you and your vehicle

WARNING
Application software and Volkswagen Car-Net services that are
unsuitable or improperly used can cause accidents, serious
personal injury and vehicle damage.
Volkswagen Car-Net services can be used only where ade-
quate cellular and GPS signals are available
Volkswagen recommends using only services and applica-
tion software that are provided by Volkswagen or Verizon
Telematics, Inc. (VzT) specifically for your vehicle.
Protect the mobile device and its application software from
misuse.
Never modify application software and Volkswagen Car-Net
services.
Always read and heed the operating instructions for the mo-
bile device.
WARNING
Driver distraction causes accidents, collisions and serious per-
sonal injury! Using application software and Volkswagen Car-
Net services while driving can distract the driver from traffic.
Always drive attentively and responsibly.
Volkswagen Car-Net service

Remote Vehicle Access – Interact with your vehicle through your
Volkswagen Car-Net iPhone® or Android® app, computer or a
Volkswagen Car-Net Customer Specialist (text and data rates apply).
Diagnostics & Maintenance – Manage your vehicle health with
diagnostic checks and service scheduling.
You can access Volkswagen Car-Net services via your Volkswagen
Car-Net iPhone® or Android® app (text and data rates apply) and the
Volkswagen Car-Net website (http://www.vw.com/carnet). If you have
a question or would like to subscribe, please either press the • button
in your vehicle or contact the Volkswagen Car-Net Response Center
at 1-877-820-2290. For more information or to log on to your
Volkswagen Car-Net account, visit http://www.vw.com/carnet.
Note: Please review the Volkswagen Car-Net Terms of Service and
Privacy Policy at http://www.vw.com/carnet.
Subscription required
Automatic Crash Notification (ACN) may be engaged for up to 6
months, starting from the date of new vehicle sale, without activating
a trial or paid subscription.
The Manual Emergency Call service and all other Volkswagen Car-
Net features require a trial or paid subscription. To begin your trial or
paid subscription, authentication and activation are required. For
more information, please visit the website
(http://www.vw.com/carnet), press the • button in the 3-button mod-
ule in your vehicle or contact the Volkswagen Car-Net Response
Center at 1-877-820-2290.
The LED light in the 3-button module will be green during the trial
period and whenever you have an active subscription. The LED light
will go off if the trial period is over and the customer has not sub-
scribed to the Volkswagen Car-Net services. The LED light will be red
only during a VW Car-Net hardware malfunction or fault ⇒ 3-button
module.
Once a trial or paid Volkswagen Car-Net subscription has been
activated, please advise all who use the vehicle that different
kinds of data can be sent and received automatically by the ve-
hicle, including speed, location and more.

WARNING
Vehicle health reports do not replace the information provided
by the vehicle warning and indicator lights. Failure to heed
warning lights and instrument cluster text messages can cause
the vehicle to break down in traffic and result in a collision and
serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
Park the vehicle at a safe distance from moving traffic and
where no part of the hot catalytic converter and exhaust system
can come into contact with flammable materials under the vehi-
cle, such as dry grass, brush, spilled fuel, etc.
A broken down vehicle presents a high accident risk for itself
and others. Switch on emergency flashers and set up a warning
triangle to warn oncoming traffic.
Before opening the engine hood, always switch off the en-
gine and let the engine cool down.
Always be very careful when working in the engine compart-
ment, which is a potentially dangerous area in any motor vehi-
cle and can cause serious personal injury.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.
Volkswagen collects, processes, transmits, uses and shares in-
formation about you and your vehicle in accordance with the
Volkswagen Car-Net Terms of Service and Privacy Policy. See the
Volkswagen Car-Net Terms of Service and Privacy Policy at
http://www.vw.com/carnet for more details.
Volkswagen Car-Net services use a system based on a wireless
communication network. If all technical and other conditions are met
and Volkswagen Car-Net still does not work properly, please try using
the service again later.

Features

Safe & Secure:
Feature Description
Roadside
Assistance
Press the > button in the 3-button module:
The vehicle will connect directly to the
Volkswagen Roadside Assistance Call Center.
The vehicle’s location is also transmitted in
order to more quickly provide assistance.
Stolen Vehicle Lo-
cation Assistance
For use by law en-
forcement authori-
ties only. See
Terms of Service at
www.vw.com/carnet
for details.
After you have reported your vehicle as stolen
to law enforcement, you may provide the case
information to the Volkswagen Car-Net Re-
sponse Center. Once the information has been
verified, the VW Car-Net Customer Specialist
will be able to provide law enforcement with
vehicle location data sent by the VW Car-Net
module.


Family Guardian:
Feature Description
Boundary
Alert
By logging on to your Volkswagen Car-Net account,
you can designate an area on a map as a “virtual
fence.” The vehicle owner can then choose notification
channels (text message or email) for receiving alerts
when the vehicle crosses the defined boundary (texts
and data rates apply).
Speed Alert
Volkswagen Car-Net can be configured to inform the
vehicle owner whenever the vehicle exceeds a speed
set by the owner. The owner can select to be informed
through multiple channels, including text messages
and email (text and data rates apply).


Remote Vehicle Access:
