VOLKSWAGEN T-ROC 2018 Owners Manual

ator. The 12-volt vehicle battery will not be charged by the alternator while the
vehicle is in motion.
Switch off any electrical consumers that are not required. Inform a qualified workshop. Have the
electrical system checked.
The start/stop system cannot start the engine Start/stop system
and vehicle battery (12-volt)
The central warning lamp lights up yellow and the text message 12 V battery low. Charge by driving.
is displayed.
The charge level of the vehicle battery is insufficient.
Recharge the 12-volt vehicle battery by driving the vehicle for an extended time.
The start/stop system cannot start the engine Start/stop system
and vehicle battery (12-volt)
The central warning lamp lights up red and the text message Replace 12 V battery. Workshop. is
displayed.
The vehicle battery condition is not ok.
Seek expert assistance and have the battery checked and replaced if necessary.
The start/stop system cannot start the engine Start/stop system
Wheels and tyres
Tyre monitoring system
Introduction
This chapter contains information on the followingsubjects:
Tyre Pressure Loss Indicator
Troub
The tyre monitoring system warns the driver when the tyre pressures are too low.
The tyre monitoring system monitors various parameters (for example, rolling circumference) of all
wheels using ABS sensors (indirect measurement).

WARNING
The intelligent tyre monitoring system technology cannot overcome the laws of physics, and
functions only within the limits of the system. Incorrect handling of the wheels and tyres can lead to
a sudden loss of pressure in the tyres, tread separation and even tyre blow-out.

Tyre
pressure
an extent that the tread peels off and the tyre bursts.
Tyre pressure
eck the tyre pressure regularly when the tyres are cold. If necessary, adjust the tyre pressure in
the cold tyre to the recommended tyre pressure for the tyres installed on your vehicle Tyre
pressure
amage.


If the tyre pressure is too low, this will increase fuel consumption and tyre wear.

When new tyres are driven at high speeds for the first time, they can expand slightly and trigger a
one-off pressure warning.

Old tyres should be replaced only by tyres that have been approved by Volkswagen for the vehicle
type.

Do not rely solely on the tyre monitoring system. Check your tyres regularly to ensure that they are
properly inflated and have no signs of damage, such as punctures, cuts, cracks, and blisters. Remove
any objects that become embedded in the tyre tread but have not penetrated into the body of the
tyre itself.
Tyre Pressure Loss Indicator
First read and observe the introductoryinformation and safety warnings
Functional description
The Tyre Pressure Loss Indicator uses data from the ABS sensors and other functions to compare the
speed of rotation and the rolling circumference of the individual wheels.
The rolling circumference can change:

The Tyre Pressure Loss Indicator may react with a delay or not display anything at all in the event
of a sporty driving style, when driving on snow-covered or icy roads or unpaved roads or when
driving with snow chains.
Synchronising the Tyre Pressure Loss Indicator

button or function button, depending on version Vehicle settings menu
tem.



button.
After an extended driving time with driving at different speeds, the system will automatically learn
the new values and monitor them.


t to rear.

The Tyre Pressure Loss Indicator does not work if there is a fault in the ESC or ABS
Troubleshooting

After a warning about the tyre pressure being too low, switch the ignition off and then back on
again. The Tyre Pressure Loss Indicator can be re-synchronised only after this has been done.
Troubleshooting for Tyre Pressure Loss Indicator
First read and observe the introductoryinformation and safety warnings
lit up
Do not drive on!
s Tyre pressure

synchronise the Tyre Pressure Loss Indicator Tyre Pressure Loss Indicator

flashes for 65 seconds and then remains lit continuously
Do not drive on!

-synchronise the Tyre Pressure Loss Indicator Tyre Pressure Loss Indicator


WARNING
Differing tyre pressures or tyre pressures that are too low can cause tyre damage, tyre failure, loss of
vehicle control, accidents, serious injury and death.
lights up, stop the vehicle as soon as possible and check all the tyres
Useful information about wheels and tyres
vehicle stability and increase the braking distance.
lead
to a tyre bursting and the loss of control over the vehicle.
recommended tyre pressure can be found on a sticker Tyre pressure
em cannot function correctly unless all cold tyres have the correct tyre
pressure.
Tyre pressure
Tyre pressure
warm up the tyre to such an extent that the tread may separate and the tyre could burst. This could
cause the driver to lose control of the vehicle.
the tyre bursts, leading you to lose control of the vehicle.
rely and the vehicle will not
handle well.
to the nearest qualified workshop and check and correct the tyre pressure Useful information
about wheels and tyres

Tyre Pressure Loss Indicator. In the event of a malfunction, the indicator lamp will flash for 65
seconds and then light up continuously. However, the indicator lamp will go out when the road
conditions or driving style change.
Useful information about wheels and tyres
Introduction
This chapter contains information on the followingsubjects:
Handling wheels and tyres
Wheel rims and wheel bolts
Tyre pressure
Tread depth and wear indicators
Tyre damage
Spare wheel or temporary spare wheel
Tyre lettering and tyre type
Maximum load and speed range for tyres
Winter tyres
Snow chains
The tyres are the most heavily loaded and most underestimated parts of a vehicle. Tyres are very
important as the narrow tyre contact surfaces are the only contact between the vehicle and the
road.
The service life of tyres is dependent on tyre pressure, driving style, handling and correct fitting.

WARNING
New tyres or tyres which are old, worn down or damaged cannot provide full vehicle control and
braking efficiency.
injuries.
s must be fitted with radial tyres of the same type, size (rolling circumference) and
the same tread pattern.
particularly carefully for the first 600 km in order to prevent accidents and serious injury.
the tyre pressure is too low, it is possible that the tyre temperature will increase to such an extent
when driving that the tread peels off and the tyre bursts.

must be replaced as soon as possible.

grip.
he vehicle pulls to one side when driving, stop the car
immediately and check the wheels and tyres for damage.
injury, never loosen the bolts on wheel rims with bolted-on rim rings.
damaged, even if the damage is not visible.
ally at high
speeds, and thus cause accidents and serious injuries. Avoid using tyres that are more than six years
old. If you have no alternative, drive slowly and with extra care at all times.

WARNING
If the wheels are incorrectly fastened or if wheel bolts are missing, the wheels could come loose,
leading to a loss of control over the vehicle, causing accidents and serious injuries.

type.
available, tighten the wheel bolts with the wheel wrench and have the torque checked without delay
by the nearest qualified workshop.
Handling wheels and tyres

Fig. 193 Illustration: diagram showing how to swap wheels
First read and observe the introductoryinformation and safety warnings

Rotating wheels
Regularly rotating the wheels as shown in the illustration Fig. 193is recommended to help ensure
that tyres wear evenly. All the tyres will then last for about the same time.
Volkswagen recommends having the wheels changed by a qualified workshop.
Avoiding damage to the wheel rims and tyres


Tyre lettering and
tyre type
worn tyres must be replaced immediately Tyre damage
fluid

Tyres that are older than 6 years
Tyres age through physical and chemical processes that can impair their function. Tyres that have
been stored unused for an extended period of time age more quickly than tyres that are used all the
time.
Volkswagen recommends replacing tyres that are older than 6 years with new tyres. This also applies
to tyres which appear to still be in good condition and whose tread depth has not yet reached the
minimum value stipulated by legislation
Winter and all-year tyres also largely lose their effectiveness through ageing regardless of the
remaining tread depth.
The age of each tyre can be determined using the manufacturing date Tyre lettering and tyre
type
Storing tyres
es mounted on the
wheel rim vertically.
should be stored vertically (standing on the tread).
New tyres
with new tyres as the tyres have to be run in. Tyres
that have not been run in have reduced grip and braking efficiency

lace tyres at least on an axle-by-axle basis
type.
-approved tyres.
Re-synchronising the Tyre Pressure Loss Indicator
The Tyre Pressure Loss Indicator must be re-synchronised each time one or more wheels is changed.
This also applies if the wheels have been swapped, e.g. from the front to the rear Tyre monitoring
system

WARNING
Aggressive liquids and other substances can cause visible and invisible damage to the tyres, which
can cause the tyre to burst.
from the tyres.

WARNING
Even if they have not been used, old tyres can suddenly lose pressure or burst, especially at high
speeds, and thus cause accidents and serious injuries.
ith
extra care at all times.

WARNING
New tyres must be run in as they initially have reduced grip and braking efficiency.
km in order to prevent accidents and serious injury.

WARNING
Wheels must have the necessary clearance. If the wheels do not have the necessary clearance, the
tyre could rub on parts of the running gear, vehicle body and the brake lines. This can lead to a fault
in the brake system and to tread separation and thus to a tyre bursting.
and must not rub on any vehicle body parts.

Avoid heavy impacts and drive round obstacles whenever possible. Tyres can be deformed by
potholes and kerb edges especially. This can cause damage to the tyres and wheel rims.

Old tyres should be disposed of as required by legislation.

Volkswagen-approved tyres are guaranteed to have the dimensions that are suitable for the vehicle.
In the case of other tyres, the tyre seller must provide a certificate from the tyre manufacturer
stating that the tyre is also suitable for the vehicle. This certificate must be stored in a safe place in
the vehicle.
Wheel rims and wheel bolts
First read and observe the introductoryinformation and safety warnings
Wheel rims, tyres and wheel bolts are matched to the vehicle type. If different wheel rims are fitted,
the correct wheel bolts with the correct length and correctly shaped bolt heads must be used.
For technical reasons, it is not generally possible to use the wheel rims from other vehicles. This can
also apply to wheel rims of the same vehicle type.
The tightening torque of the wheel bolts must be checked regularly with a properly functioning
torque wrench.
Wheel bolts
The correct wheel bolts must be used for each vehicle type; these bolts must always be tightened
with the correct tightening torque Wheel bolts
Wheel rims with bolted rim rings or trim elements
Rims with bolted-on rings or trim elements consist of several components. These components are
joined together using special bolts. Damaged wheel rims must be replaced and must always be
repaired only by a qualified workshop. Volkswagen recommends using a Volkswagen dealership for
this purpose
Wheel rim identification
In some countries, new wheel rims must contain information on certain properties. The following
information may appear on the wheel rim:



ed (month/year)

WARNING
The use of unsuitable or damaged wheel rims can impair vehicle safety and cause accidents and
serious injuries.
ave been approved for the vehicle.


WARNING
Incorrect loosening and tightening of the bolts on wheel rims with bolted-on rings can cause
accidents and serious injuries.
on wheel rims with bolted-on rings.
-on rings must be carried out by a qualified workshop. Volkswagen
recommends using a Volkswagen dealership for this purpose.
Tyre pressure

Fig. 194 Symbols on the tyre pressure sticker.

Fig. 195 On the driver door pillar: tyre pressure sticker (alternatively on the inside of the tank flap).
