10 Specifications
Overview of information and warning symbols
10

* Option/accessory, for more information, see Introduction.349 Introduction
The symbols in the vehicle's various displays
are divided into three main categories:
•Warning symbols
•Indicator symbols
•Information symbols
The following tables list the most common
symbols, their meaning and the pages in this
manual that provide more detailed information.
Warning symbol
The red warning symbol lights up to
indicate a problem related to safety and/or
drivability. A message will also appear in the
main instruments panel's display.
Information symbol
The information symbol lights up and a
text message is displayed to provide the driver
with necessary information about one of the
vehicle's systems.
Symbols in the main instrument panel
Warning symbols
SymbolDescriptionP.
no.
Low oil pressure80
A
Parking brake80
SRS airbags80
Seat belt reminder80
Generator not charg-
ing81
A
Fault in the brake sys-
tem81
Warning symbol81
ACanadian models
Indicator symbols
SymbolDescriptionP.
no.
Fault in the Active
Bending Light
(ABL)*system79
A
Malfunction indicator
light79
A
Anti-lock brake sys-
tem (ABS)79
Rear fog light on79
Stability system
(DSTC), Trailer Stabil-
ity Assist*79
Tire pressure monitor-
ing sensor (TPMS)79
Low fuel level79
Information symbol,
see text in information
display79

10 Specifications
Overview of information and warning symbols
10
350* Option/accessory, for more information, see Introduction.
SymbolDescriptionP.
no.
High beam indicator78
Left turn signal indica-
tor78
Right turn signal indi-
cator78
ACanadian models
Other information symbols
SymbolDescriptionP.
no.
Adaptive Cruise Con-
trol *139,
146
Adaptive Cruise Con-
trol *139,
146
Adaptive Cruise Con-
trol *, Distance Alert*139,
146,
148
Adaptive Cruise Con-
trol *, Distance Alert*139,
146,
148
SymbolDescriptionP.
no.
Adaptive Cruise Con-
trol *139,
146
Adaptive Cruise Con-
trol *, Distance Alert*139,
146,
148
Adaptive Cruise Con-
trol *, Distance Alert*139,
146,
148
Adaptive Cruise Con-
trol*139,
146
Radar sensor*143
Camera*
Laser sensor*161
Collision Warning with
Full Auto-brake and
Pedestrian Detection*163
SymbolDescriptionP.
no.
Driver Alert System*165
Active Bending Lights
(ABL)*96
Fuel filler door (arrow
indicates it is on right
side of vehicle)78
Rain sensor*101
Driver Alert System*166
Driver Alert System*,
Lane Departure Warn-
ing*168
Driver Alert System*,
Lane Departure Warn-
ing*168
Adaptive Cruise Con-
trol *139,
146

10 Specifications
Overview of information and warning symbols
10
* Option/accessory, for more information, see Introduction.351
Information symbols in the center
console display
SymbolDescriptionP.
no.
Audio files232
CD folder232
Video files232
Bluetooth-connected
cell phone241
BluetoothTM hands-
free241
HD radio224
Park Assist*171
Information symbols in the ceiling
console
SymbolDescriptionP.
no.
Seat belt reminder20
Occupant Weight
Sensor27

10 Specifications
Volvo programs
10
352
Volvo On Call Roadside Assistance
Your new Volvo comes with a four year ON
CALL roadside assistance. Additional informa-
tion, features, and benefits are described in a
separate information package in your glove
compartment.
If you require assistance, dial:
In the U.S. 1-800-638-6586 (1-800-63-
VOLVO)
In Canada 1-800-263-0475
Technician certification
In addition to Volvo factory training, Volvo sup-
ports certification by the National Institute for
Automotive Service Excellence (A.S.E.). Certi-
fied technicians have demonstrated a high
degree of competence in specific areas.
Besides passing exams, each technician must
also have worked in the field for two or more
years before a certificate is issued. These pro-
fessional technicians are best able to analyze
vehicle problems and perform the necessary
maintenance procedures to keep your Volvo at
peak operating condition.

10 Specifications

10
353
