* Option/accessory, for more information, see Introduction.125 Automatic gearbox Powershift*
D: Automatic gear positions. +/–: Manual gear
positions.
Powershift is a 6-stage automatic gearbox that
has double mechanical clutch discs in contrast
to a conventional automatic gearbox. A con-
ventional automatic gearbox has a hydraulic
torque converter instead that transfers power
from engine to gearbox.
Powershift transmission operates in the same
way and has similar controls and functions as
the Geartronic automatic transmission, descri-
bed in the previous section.
Powershift or Geartronic?In the event of uncertainty as to whether or not
the car is equipped with Powershift transmis-sion, this can be verified by checking the des-
ignation on the transmission's label under the
bonnet - see page 370. The designa-
tion ”MPS6” means that it is Powershift – trans-
mission otherwise it is Geartronic automatic
transmission.
HSAThe HSA (Hill Start Assist) function means that
the pressure in the brake system remains for
several seconds while the foot is moved from
the brake pedal to the accelerator pedal before
setting off or reversing uphill.
The temporary braking effect releases after
several seconds or when the driver acceler-
ates.
To bear in mindThe transmission's double clutch has overload
protection that is activated if it becomes too
hot, e.g. if the car is held stationary with the
accelerator pedal on an uphill gradient for a
long time.
Overheated transmission causes the car to
shake and vibrate, and the warning symbol illu-
minates and the information display shows a
message. The transmission can also overheat
during slow driving in queues (10 km/h orslower) on an uphill gradient, or with a trailer
hitched. The transmission cools down when
the car is stationary, with foot brake depressed
and the engine running at idling speed.
Overheating during slow driving in queues can
be avoided by driving in stages: Stop the car
and wait with your foot on the brake pedal until
there is a moderate distance to the traffic
ahead, drive forward a short distance, and then
wait another moment with your foot on the
brake pedal.
IMPORTANT
Use the foot brake to hold the car stationary
on an uphill gradient - do not hold the car
with the accelerator pedal. The gearbox
could then overheat.
For important information regarding Powershift
transmission and towing - see page 304.
Text message and actionIn some situations the display may show a
message at the same time as a symbol is illu-
minated.
ProCarManuals.com

03 Your driving environment
DRIVe Start/Stop*
03

* Option/accessory, for more information, see Introduction.129 Limitations
The engine does not auto-stopEven if the Start/Stop function is activated, the
engine does not stop automatically if:
ConditionsM/AA
the car has not achieved
approx. 5 km/h (= fast walking
pace) first after a key start or the
last auto-stop.M + A
the driver has opened the seat-
belt's buckle.M + A
the capacity of the battery is
below the minimum permissible
level.M + A
the engine does not have normal
operating temperature.M + A
outside temperature is below
freezing point or above
approx. 30 °C.M + A
the environment in the passenger
compartment differs from the
preset values - indicated by the
ventilation fan running at a high
speed.M + A
ConditionsM/AA
the car is reversed.M + A
battery temperature is below
freezing point or above
approx. 55 °C.M + A
the driver makes greater steering
wheel movements.M + A
the exhaust system's particulate
filter is full - the temporarily dis-
engaged Start/Stop function is
reactivated once an automatic
cleaning cycle has been per-
formed (see page 290).M + A
the road is very steep.M + A
a trailer is connected electrically
to the car’s electrical system.M + A
the atmospheric air pressure is
less than equivalent to 1500-2000
metres above sea level - the cur-
rent air pressure varies with the
prevailing weather conditions.A
adaptive cruise control Queue
Assist is activated.A
ConditionsM/AA
the driver’s door has been
opened with the gear selector in
D position.A
the gear selector is moved out of
the D position to S positionB or
"+/-".
A
AM = Manual gearbox, A = Automatic gearbox.BSport mode.
The engine auto-startsAn engine that has stopped automatically may
restart in some cases without the driver having
decided that the journey should continue. In
the following cases the engine also starts auto-
matically if the driver has not depressed the
clutch pedal (manual gearbox) or takes his/her
foot off the brake pedal (automatic gearbox):
ConditionsM/AA
Misting forms on the windows.M + A
The environment in the passen-
ger compartment deviates from
the preset values.M + A
The outside temperature falls
below freezing point or exceeds
approx. 30 °C.M + A
ProCarManuals.com

03 Your driving environment
Parking brake
03
138
Disengaging the parking brake
Parking brake control - release.
Cars with manual gearbox
Releasing manually
1. Insert the remote control key in the ignition
switch.1
2. Press the foot brake pedal down firmly.
3. Pull the control.
> The parking brake releases and the
combined instrument panel symbol
goes out.
NOTE
The parking brake can also be released
manually by depressing the clutch pedal
instead of the brake pedal. Volvo recom-
mends the use of the brake pedal.
Releasing automatically1. Start the engine.
2. Engage 1st gear or reverse gear.
3. Ease up the clutch and depress the accel-
erator.
> The parking brake releases and the
combined instrument panel symbol
goes out.
Cars with automatic gearbox
Releasing manually
1. Insert the remote control key in the ignition
switch1.
2. Press the foot brake pedal down firmly.
3. Pull the control.
> The parking brake releases and the
combined instrument panel symbol
goes out.
Releasing automatically1. Put the seatbelt on.
2. Start the engine.
3. Press the foot brake pedal down firmly.
4.
Move the gear selector to position D or R
and depress the accelerator.
> The parking brake releases and the
combined instrument panel symbol
goes out.
NOTE
For safety reasons, the parking brake is only
released automatically if the engine is run-
ning and the driver is wearing a seatbelt. The
parking brake is released immediately on
cars with automatic gearbox when the
accelerator pedal is depressed and the gear
selector is in position D or R.
Heavy load uphillA heavy load, such as a trailer, can cause the
car to roll backward when the parking brake is
released automatically on a steep incline.
Avoid this by depressing the control while driv-
ing off. Release the control when the engine
achieves traction.
