VOLVO XC60 TWIN ENGINE 2019 Owners Manual

C L I M A T E C O N T R O L

CLIMATE CONTROL
* Option/accessory.200
Climate
The vehicle is equipped with electronic climatecontrol. The climate system cools, heats anddehumidifies the air in the passenger compart-ment.
All of the climate system functions are controlledfrom the center display and the buttons on thecenter console.
Certain rear seat functions can also be controlledfrom the climate controls* on the rear of the tun-nel console.

Related information
Climate zones (p. 200)
Climate control sensors (p. 200)
Perceived temperature (p. 201)
Climate control system voice commands(p. 201)
Parking climate (p. 224)
Air quality (p. 202)
Air distribution (p. 205)
Climate system controls (p. 212)
Climate zones
The vehicle is divided into climate zones to makeit possible to set different temperatures for dif-ferent parts of the passenger compartment.
2-zone climate system
Climate zones with 2-zone climate system.
In 2-zone climate systems, the passenger com-partment temperature can be set separately forthe left and right sides of the vehicle.

Related information
Climate (p. 200)
Climate control sensors
The climate system has a number of sensors tohelp regulate the climate settings in the vehicle.
Location of the sensors
Humidity sensor - in the rearview mirror con-sole.
Ambient temperature sensor - in the right-side door mirror.
Sunlight sensors - on the upper side of thedashboard.
Passenger compartment temperature sensor- near the buttons in the center console.

NOTE
Do not cover or block the sensors with cloth-ing or other objects.

CLIMATE CONTROL
}}
* Option/accessory.201
On vehicles equipped with the Interior Air QualitySystem*, there is also an air quality sensor in theclimate system's air intake.

Related information
Climate (p. 200)
Interior Air Quality System* (p. 204)
Perceived temperature
The climate control system regulates the climatein the passenger compartment based on per-ceived temperature, not actual temperature.
The selected passenger compartment tempera-ture is based on the physical perception of thecurrent ambient temperature, airflow speed,humidity, sunlight in the passenger compartment,etc.
The system has a sunlight sensor that detectswhich side of the vehicle the sunlight is shiningon and adjusts the temperature accordingly. Thismeans that the temperature of the air coming outof the vents may be different for the left and rightsides, even if the temperature setting is the samefor both sides.

Related information
Climate (p. 200)
Climate control system voice
commands1
Voice commands can be used for the climatecontrol system to e.g. change temperature, acti-vate seat heating* or change blower speed.
Tap and say one of the following commands:
"Climate" - starts a command dialog for cli-mate controls and provides examples ofcommands that can be used.
"Set temperature to X degrees" - setsdesired temperature.
"Raise temperature"/"Lowertemperature" - raises/lowers the set tem-perature.
"Sync temperature" - synchronizes thetemperature for all climate zones in the vehi-cle with the temperature set for the driver'sside.
"Air on feet"/"Air on body" - opens thedesired air vent.
"Air on feet off"/"Air on body off" - closesthe desired air vent.
"Set fan to max"/"Turn off fan" - changesblower speed to Max/Off.
"Raise fan speed"/"Lower fan speed" -raises/lowers the set blower speed.
1Certain markets only.

||
CLIMATE CONTROL
* Option/accessory.202
"Turn on auto" - activates automatic climatecontrol.
"Air condition on"/"Air condition off" -activates/deactivates air conditioning.
"Recirculation on"/"Recirculation off" -activates/deactivates air recirculation.
"Turn on defroster "/"Turn off defroster"- activates/deactivates window and door mir-ror defrosting.
"Turn on max defroster"/"Turn off maxdefroster" - activates/deactivates maxdefroster.
"Turn on electric defroster"/"Turn offelectric defroster" - activates/deactivatesheated windshield*.
"Turn on rear defroster"/"Turn off reardefroster" - Activates/deactivates heatedrear window and door mirrors.
"Turn steering wheel heat on"/"Turnsteering wheel heat off" - activates/deac-tivates heated steering wheel*.
"Raise steering wheel heat"/"Lowersteering wheel heat" - raises/lowers thelevel of steering wheel heating*.
"Turn on seat heat"/"Turn off seat heat"- activates/deactivates seat heating*.
"Raise seat heat"/"Lower seat heat" -raises/lowers the level of seat heating*.
"Turn on seat ventilation"/"Turn off seatventilation" - activates/deactivates seatventilation*.
"Raise seat ventilation"/"Lower seatventilation" - raises/lowers the level of seatventilation*.

Related information
Climate (p. 200)
Voice control (p. 145)
Using voice commands (p. 146)
Voice control settings (p. 148)
Air quality
The materials used in the passenger compart-ment and air filtering system have been selectedto ensure a high level of air quality in the passen-ger compartment.
Materials used in the passenger
compartment
The materials in the passenger compartment aredesigned to be pleasant and comfortable, evenfor people with asthma or allergies.
The materials have been developed and tested tominimize dust in the passenger compartment andmake it easier to keep clean.
The mats in both the passenger compartmentand cargo compartment can be easily removedfor cleaning.
Use Volvo-recommended cleaning agents andcar care products to clean the interior.

Air filtering systems
In addition to the passenger compartment filter,the Clean Zone Interior Package* and Interior AirQuality System* also help maintain high air qual-ity in the passenger compartment.

Related information
Climate (p. 200)
Clean Zone* (p. 203)
Clean Zone Interior Package* (p. 204)

CLIMATE CONTROL
* Option/accessory.203
Interior Air Quality System* (p. 204)
Passenger compartment air filter (p. 205)
Clean Zone*
The Clean Zone function monitors the condi-tions affecting good air quality in the passengercompartment and indicates whether they are ful-filled or not.
The indicator is shown in the center display'sClimate view.
The indicator is shown in the climate barwhen Climate view is not open.
If the conditions are not met, the text CleanZone will be shown in white. When all the condi-tions are met, the text will change to blue.
Clean Zone monitors whether:
All doors and tailgate are closed.
All side windows and panoramic roof* areclosed.
The Interior Air Quality System* is activated.
The blower is activated.
Air recirculation is deactivated.

NOTE
Clean Zone does not indicate that the airquality is good, but only that the conditions forgood air quality have been met.

Related information
Air quality (p. 202)
Clean Zone Interior Package* (p. 204)
Interior Air Quality System* (p. 204)
Passenger compartment air filter (p. 205)

CLIMATE CONTROL
* Option/accessory.204
Clean Zone Interior Package*
Clean Zone Interior Package (CZIP) is a seriesof modifications that filters even more allergy andasthma-inducing substances from the passengercompartment.
CZIP includes the following:
An enhanced function that starts the blowerwhen the vehicle is unlocked using theremote key. The blower will then fill the pas-senger compartment with fresh air. The func-tion starts when required and switches offautomatically after a period of time or whenone of the passenger compartment doors isopened. The amount of time the blower runsgradually decreases due to reduced need upuntil the vehicle is 4 years old.
The fully automatic Interior Air QualitySystem (IAQS).

Related information
Air quality (p. 202)
Clean Zone* (p. 203)
Interior Air Quality System* (p. 204)
Passenger compartment air filter (p. 205)
Interior Air Quality System*
Interior Air Quality System (IAQS) is a fully auto-matic air quality system that removes gases andparticles to reduce odors and contaminants inthe passenger compartment.
IAQS is part of the Clean Zone Interior Package(CZIP) and removes air contaminants such asparticles, hydrocarbons, nitric oxides and ground-level ozone.
If the system's air quality sensors detect contami-nants in the outside air, the air intake closes andair recirculation is activated.
NOTE
To ensure optimal air quality in the passengercompartment, the air quality sensor shouldalways be engaged.
Recirculation is limited in cold weather to pre-vent fogging.
In the event of fogging, use the defrosterfunctions for the windshield, side windowsand rear window.

Related information
Activating and deactivating the air qualitysensor* (p. 205)
Air quality (p. 202)
Clean Zone* (p. 203)
Clean Zone Interior Package* (p. 204)
Passenger compartment air filter (p. 205)

CLIMATE CONTROL
}}
* Option/accessory.205
Activating and deactivating the air
quality sensor*
The air quality sensor is part of the fully automa-ted Interior Air Quality System (IAQS).
The air quality sensor can be switched on or off.
1.Tap Settings in the Top view in the centerdisplay.
2.Tap Climate.
3.Select Air Quality Sensor to activate/deac-tivate the air quality sensor.

Related information
Interior Air Quality System* (p. 204)
Passenger compartment air filter
All air entering the passenger compartmentthrough the climate control system intake is fil-tered.
Replacing the passenger compartment
filter
To maintain the high performance of the climatecontrol system, the filter must be replaced regu-larly. Follow Volvo's service schedule for recom-mended replacement intervals. When driving inareas with a lot of smog, dust, etc., the filter mayneed to be changed more frequently.

NOTE
There are two types of passenger compart-ment filters. Make sure that the correct filteris installed.

Related information
Air quality (p. 202)
Clean Zone* (p. 203)
Clean Zone Interior Package* (p. 204)
Interior Air Quality System* (p. 204)
Air distribution
The climate system distributes incoming airthrough a number of vents in the passengercompartment.
Automatic and manual air distribution
When the auto-climate feature is on, air distribu-tion is regulated automatically. Air distribution canalso be controlled manually.

Adjustable air vents
Certain air vents in the vehicle are adjustable,which means they can be opened/closed and thedirection of the air flow from the vent can beadjusted.
Location of adjustable air vents in the passenger com-partment.
Four vents on the dashboard and one oneach of the pillars between the front and reardoors.

||
CLIMATE CONTROL
206

Related information
Climate (p. 200)
Adjusting air distribution (p. 206)
Opening, closing and directing air vents(p. 207)
Air distribution options (p. 209)
Adjusting air distribution
Air distribution can be adjusted manually if nee-ded.
Air distribution buttons in Climate view.
Air distribution - windshield defrost vents
Air distribution - dashboard and center con-sole air vents
Air distribution - floor air vents
1.Open Climate view in the center display.
2.Tap one or more air distribution buttons toopen/close the airflow for that vent.
> The air distribution changes and the but-tons will light up or go out.
Related information
Air distribution (p. 205)
Opening, closing and directing air vents(p. 207)
Air distribution options (p. 209)

CLIMATE CONTROL
}}
207
Opening, closing and directing airvents
Some of the air vents in the passenger compart-ment can be individually opened, closed anddirected.
Misting can be eliminated by directing the outerair vents towards the door windows.
Direct the outer air vents into the passengercompartment to maintain a comfortable tempera-ture in warm weather.

Opening and closing the air vents
Front seat air vents:
Air vent knob2.
–Turn the knob to open/close the airflow fromthe vent.
When the mark on the knob is vertical, theairflow is strongest.
Rear seat air vents:
Air vent thumb wheel2.
–Turn the thumb wheel to open/close the air-flow from the vent.
The more white lines that are visible, thestronger the airflow.
2The illustration is generic - air vent design varies depending on its location.

||
CLIMATE CONTROL
208

Directing air flow
Airflow control2.
–Move the control from side to side or up anddown to direct airflow from the vent.

Related information
Air distribution (p. 205)
Adjusting air distribution (p. 206)
Air distribution options (p. 209)
2The illustration is generic - air vent design varies depending on its location.
