2004 VOLVO XC70
darkness, the daytime running lights will switch off and the Bi-Xenon he\
adlights will switch on.
Parking lights on
Headlights, parking lights, license plate lights and instrument panel i\
llumination are on if the
ignition key is in position II.
If the headlight switch is in position
all lights will go out when the ignition is switched off.
The headlight switch must be in this position before the high beams will\
function (this also applies on
models equipped with the optional Bi-Xenon headlights).
Switch from high to low beams and vice versa by pulling the turn signal \
switch lever on the left side of
steering column toward you.
B - Instrument illumination
Move the thumbwheel up to increase brightness or down to decrease bright\
ness. There is also an
instrument panel illumination sensor (see illustration on
page 48) which automatically adjusts the level
of illumination.
C -Unlocking the fuel filler door
Press this button when the car is at a standstill to unlock the fuel fil\
ler door. Please note that the fuel
filler door will remain unlocked until the car begins to move forward. A\
n audible click will be heard
when the fuel filler door relocks.
See also
page 86.
file:///K|/ownersdocs/2004/2004_XC70/04xc70_02b.htm (3 of 18)12/30/200\
6 4:32:58 PM

2004 VOLVO XC70

Windshield wiper/washer
Windshield wipers/washers
0 Windshield wipers off
Intermittent wiper function. With the lever in this position, you can s\
et the wiper interval by
twisting control A upward to increase wiper speed or downward to decreas\
e the speed.
Rain sensor (option)
The rain sensor replaces the intermittent wiper function and automatical\
ly regulates wiper speed
according to the amount of water on the windshield. The sensitivity of the sensor can be adjusted by
twisting control A upward or downward.
Activating the rain sensor function:
1. Switch on the ignition.
2. Move the windshield wiper lever to the intermittent position.
The rain sensor is deactivated when the ignition is switched completely \
off.
To reactivate the rain sensor function:
1. Switch on the ignition.
2. Move the windshield wiper lever to position 0 and then back to the in\
termittent position.
CAUTION: When washing the car in an automatic carwash, etc move the windshield wi\
per lever to
position 0 or switch off the ignition completely to deactivate the rain \
sensor. If the sensor function is left
on, the wipers will start inadvertently in the carwash and could be dama\
ged.
Normal wiper speed
file:///K|/ownersdocs/2004/2004_XC70/04xc70_02b.htm (7 of 18)12/30/200\
6 4:32:58 PM

2004 VOLVO XC70
B Closed
C Horizontal air flow
D Vertical air flow
Direct the air vents toward the rear side windows to demist.
Direct the air vents toward the rear seat for the best heating/cooling e\
ffect.

pg. 47 Climate control system - general information
Condensation on the inside of the windows
Keeping the insides of the windows clean will help reduce the amount of \
condensation that forms on the
windows. Use a commercial window cleaning agent to clean the windows.
Ice and snow
Always keep the air intake grille at the base of the windshield free of \
snow.
Cabin air filter
Replace the cabin air filter with a new one at the recommended intervals\
. Please refer to your Warranty
and Service Records Information booklet, or consult your Volvo retailer \
for these intervals. The filter
should be replaced more often when driving under dirty and dusty conditi\
ons. The filter cannot be
cleaned and therefore should always be replaced with a new one.
Sensors
The sunlight sensor on the dashboard and passenger compartment temperatu\
re sensor in the ECC control
panel should not be covered in any way as this could cause incorrect inf\
ormation to be sent to the ECC
system.
Parking the car in warm weather
If your car has been parked in the sun in warm weather, opening the wind\
ows and moonroof (option) for
several minutes before driving will help release the warm air from the p\
assenger compartment. When
the engine is running, close the windows and moonroof and use the recirc\
ulation function for several
minutes to enable the air conditioning to cool the compartment as quickl\
y as possible.
file:///K|/ownersdocs/2004/2004_XC70/04xc70_03.htm (3 of 12)12/30/2006\
4:32:58 PM

2004 VOLVO XC70
Blower control
Turn the control clockwise to increase or counterclockwise to decrease t\
he blower speed. Pressing the
AUTO switch will automatically regulate blower speed and override manual\
adjustment.
NOTE: Turning the blower control counterclockwise as far as possible (an oran\
ge LED next to the
control will light up) will turn both the blower and the air conditioni\
ng off.

pg. 51 Electronic Climate Control (ECC) with Interior Air Quality syst\
em (option)
Interior Air Quality system (option)
Some cars are equipped with a Multifilter and Air quality sensor. The fi\
lter separates gases and particles,
thereby reducing the amounts of odors and contaminants entering the car.\
The Air quality sensor detects
increased levels of contaminants in the outside air. When the Air qualit\
y sensor detects contaminated
outside air, the air intake closes and the air inside the passenger comp\
artment is recirculated, i.e. no
outside air enters the car. The filter also cleans recirculated passenge\
r compartment air. When the Air
quality sensor is activated, the LED AUT comes on in

Operation:
Press to activate the Air quality sensor (normal setting).
Or select one of three functions by pressing
.
file:///K|/ownersdocs/2004/2004_XC70/04xc70_03.htm (8 of 12)12/30/2006\
4:32:59 PM

2004 VOLVO XC70
1. Press : the LED AUT comes on. The Air quality sensor is now activated.
2. Press
: no LED is lighted. Recirculation not activated.
3. Press
: the LED MAN comes on. Recirculation is now activated.
You can switch between these three functions by repeatedly pressing

Keep the following in mind:
l Make it a rule to have the Air quality sensor activated at all times.
l Recirculation is limited in cold climates to avoid misting up.
l If misting occurs, you should deactivate the Air quality sensor.
l If the windows mist up, you can also use the windshield and side window \
defroster functions. See
page 49.
l The filter should be changed at the intervals listed in the Warranty and\
Service Records Information
booklet. However, if the car is used in a severely contaminated environm\
ent, it may be necessary to
change the filter more frequently.
pg. 52 Manual climate control with air conditioning, A/C


pg. 53 Manual climate control with air conditioning, A/C
file:///K|/ownersdocs/2004/2004_XC70/04xc70_03.htm (9 of 12)12/30/2006\
4:32:59 PM

2004 VOLVO XC70
NOTE: Please be aware that if the tailgate is unlocked using the tailgate unlo\
ck button, opened, and
closed again, it will remain unlocked and the alarm will not be rearmed. Press the lock button on the
remote control to relock the tailgate and rearm the alarm.

Central locking buttons
Central locking buttons
These buttons (located on the both front door armrests) can be used to\
lock/unlock all doors and the
tailgate and set the alarm.
The rear passenger doors can also be locked and unlocked with the indivi\
dual lock buttons on each door.

pg. 80 Alarm
Alarm
The alarm is automatically armed whenever you lock your car. When armed,\
the alarm continuously
monitors a number of points on the car. The following conditions will se\
t off the alarm:
l The hood is forced open.
l The tailgate is forced open.
l A door is forced open.
l The ignition switch is tampered with.
l If there is movement in the passenger compartment (if the car is equipp\
ed with the optional movement
sensor).
l The car is lifted or towed (if the car is equipped with the optional in\
clination sensor).
l The battery is disconnected (while the alarm is armed).
Arming the alarm
file:///K|/ownersdocs/2004/2004_XC70/04xc70_05.htm (7 of 11)12/30/2006\
4:33:01 PM

2004 VOLVO XC70
Temporarily turning off the inclination and movement alarm
sensor(s) - accessory
This button will only be found in cars equipped with the accessory incli\
nation and/or movement sensors.
FCC ID: MAYDA5823
This device complies with part 15 of the FCC rules. Operation is subject\
to the following conditions: (1)
This device may not cause harmful interference, and (2) this device mu\
st accept any interference
received, including interference that may cause undesired operation.
Canadian IC: 4405A-DA5823
Movement sensor DA5823 by Dynex
Operation is subject to the following conditions: (1) this device may \
not cause interference, and (2) this
device must accept any interference, including interference that may cau\
se undesired operation of the
device.
In certain situations it may be desirable to turn off the optional incli\
nation and movement alarm sensors
if, for example, you drive your car onto a ferry where the rocking of th\
e boat could trigger the alarm or if
a pet is left in the car with the doors locked.
To temporarily turn off the inclination and movement alarm sensors from \
the alarm system:
From the time the ignition key is turned from the Drive position (posit\
ion II) until you lock the car, you
file:///K|/ownersdocs/2004/2004_XC70/04xc70_05.htm (9 of 11)12/30/2006\
4:33:01 PM

2004 VOLVO XC70
can press the button in the center console. The LED in the switch will l\
ight up and a message will be
displayed in the text window to indicate that the sensors are disconnect\
ed.
The car can then be locked in the usual way to set the alarm.
NOTE:
l This function will not turn off the vehicle's standard alarm.
l The optional sensors are automatically reconnected to the alarm system t\
he next time the car is
unlocked and then locked again.
LED alarm status signals
The status of the alarm system is indicated by the red LED at the top of\
the dash:
l LED off - the alarm is not armed
l LED flashes once per second - the alarm is armed
l LED flashes rapidly before the ignition is switched on - the alarm has b\
een triggered
l Fault in the alarm system: If a fault has been detected in the alarm system, a message will be
displayed in the text window. Contact a Volvo retailer.
Automatic re-lock/re-arm system
If the car is unlocked with the remote, the car will re-lock and the ala\
rm will re-arm after 2 minutes
unless a door or the tailgate has been opened.

pg. 82 Child safety locks - rear doors

Child safety lock control in left rear

file:///K|/ownersdocs/2004/2004_XC70/04xc70_05.htm (10 of 11)12/30/200\
6 4:33:01 PM

2004 VOLVO XC70
pg. 119 Fuses in the engine compartment
Relays/fuses in the engine compartment
When replacing fuses, be sure to replace a blown fuse with a new one of \
the same color and amperage
(written on the fuse). Fuse amperage is also indicated on the inside o\
f the fuse box cover.

A - To open, press the plastic catches on the rear side of the fuse box \
cover and lift
Ordinary fuses
Location Amperage
1 Accessories 25A
2 Auxiliary lamps (option) 20A
-
4 Oxygen sensors 20A
5 Crankcase ventilation heater, solenoid valves 10A
6 Mass airflow sensor, engine control module, injectors 15A
7 Throttle module 10A
file:///K|/ownersdocs/2004/2004_XC70/04xc70_08a.htm (3 of 22)12/30/200\
6 4:33:05 PM

2004 VOLVO XC70
8 A/C compressor, accelerator pedal position sensor, E-box fan 10A
9 Horn 15A
10 Tailgate wiper 10A
11 Ignition coils 20A
12 Brake light switch 5A
13 Windshield wipers 25A
14 ABS/STC/DSTC 30A
15 -
16 Windshield washers, headlight wiper/washers (certain
models) 15A
17 Low beam, right 10A
18 Low beam, left 10A
19 ABS/STC/DSTC 30A
20 High beam, left 15A
21 High beam, right 15A
22 Starter motor 25A
23 Engine control module 5A
24 -


pg. 120 Fuses in the passenger compartment
Fuse box in the passenger compartment
This fuse box is located at the far left side of the instrument panel. E\
xtra fuses and the fuse removal tool
are also stored here. When replacing a blown fuse, be sure to replace it\
with a new one of the same color
and amperage (written on the fuse).
file:///K|/ownersdocs/2004/2004_XC70/04xc70_08a.htm (4 of 22)12/30/200\
6 4:33:05 PM
