l Current speed in mph (Canadian models only)
NOTE: Warning messages from the car's monitoring systems will override the tri\
p computer function. If a
warning message is displayed in the text window while you are using the \
trip computer, you must
acknowledge the message by pressing button A. Press button A again to re\
turn to the trip computer function.
Trip computer controls and functions
The four* trip computer functions can be accessed by twisting control B \
one step at a time in either direction.
Twisting a fifth time** returns you to the original function.
The trip computer can be reset (current data will be erased from system\
memory) by pressing RESET (button
C).
1. Driving distance on current fuel reserve
This function shows the approximate distance that can be driven on the f\
uel remaining in the tank. This
calculation is based on average fuel consumption during the last 12 mile\
s (20 km) of driving and the amount
of fuel remaining in the tank when the reading was taken. When the drivi\
ng distance on current fuel reserve is
less than 12 miles (20 km), "----" will be displayed in the text windo\
w.
2. Average fuel consumption
This value indicates fuel consumption since the last time the trip compu\
ter was reset (by pressing RESET,
button C). When the engine is switched off, information on fuel consump\
tion is stored and remains in system
memory until the RESET (button C) is pressed again.
3. Current fuel consumption
This value indicates the current fuel consumption, based on readings tak\
en once per second. When the car is
not moving, "----" will be displayed.
4. Average speed
This value indicates average speed since the last time the trip computer\
was reset (by pressing RESET, button
C). When the engine is switched off, information on average speed is st\
ored and remains in system memory
until the RESET (button C) is pressed again.
5. Current speed in miles per hour (Canadian models only)
This function provides the driver with an instantaneous conversion of th\
e car's current speed from km/h to
mph.
NOTE: Trip computer readings may vary slightly depending on the circumference \
of the tires on the car.
*Five functions on Canadian models
**A sixth time on Canadian models
file:///K|/ownersdocs/2004/2004_XC70/04xc70_02a.htm (13 of 14)12/30/20\
06 4:32:56 PM

2004 VOLVO XC70



Contents | Top of Page
file:///K|/ownersdocs/2004/2004_XC70/04xc70_02a.htm (14 of 14)12/30/20\
06 4:32:56 PM

2004 VOLVO XC70

pg. 33 Cruise control
Cruise control
The cruise control panel is located on the left side of the steering whe\
el hub.
Engaging cruise control/setting speed
l Press the CRUISE button
l Press + or - to set the current speed
l Increase or decrease speed as desired
NOTE: Cruise control will not function at speeds below 22 mph (35 km/h).
Braking
Cruise control is automatically disengaged when the brake pedal is depre\
ssed. The currently set speed is
stored in memory. Quickly pressing resume (
) will return the car to the previously set speed.
Acceleration
Momentary acceleration, such as when passing another car, does not affec\
t cruise control operation. The
car will automatically return to the previously set speed when you relea\
se the accelerator pedal.
When the cruise control is already engaged, the car's speed can be incre\
ased or decreased by holding
down + or - until the car reaches the desired speed. One short press on \
either symbol corresponds to a
speed change of approximately 1 mph (1.6 km/h).

file:///K|/ownersdocs/2004/2004_XC70/04xc70_02b.htm (1 of 18)12/30/200\
6 4:32:58 PM

2004 VOLVO XC70
Disengaging cruise control
Cruise control can be disengaged by:
l Pressing the CRUISE button.
l Putting the gear selector in (N)eutral.
NOTE: Cruise control is automatically disengaged if the engine is switched off\
, if the gear selector is
placed in (N)eutral, if the car's speed drops to under 70% of the curr\
ently set speed or if the wheels start
to spin.
Temporarily disengaging cruise control
l Press 0 to temporarily disengage cruise control. Press "resume" () to return to the previously set
speed.
l Press the brake pedal. Press "resume" () to return to the previously set speed.
WARNING!
Cruise control should not be used in heavy traffic or when driving on we\
t or slippery roads. Cruise
control may not maintain set speed on steep downgrades.

pg. 34 Light switch panel
A - Headlights, parking lights
O All lights off
Models with daytime running lights: Low beam headlights will automatically come on if the ignition
key is in position II. Front and rear parking lights and license plate l\
ights will also be on.
Volvo recommends the use of daytime running lights. If, however, you wou\
ld prefer to have these lights
turned off (USA only), please consult your Volvo retailer. Please note\
that the use of daytime running
lights is mandatory in Canada.
NOTE: Bi-Xenon headlights (option): Turn the headlight switch to position 0\
to activate a daylight
sensor, which automatically switches the low beams on or off, depending \
on ambient light conditions.
When driving in daylight, the headlights will switch off and the daytime\
running lights will come on. In
file:///K|/ownersdocs/2004/2004_XC70/04xc70_02b.htm (2 of 18)12/30/200\
6 4:32:58 PM

2004 VOLVO XC70
darkness, the daytime running lights will switch off and the Bi-Xenon he\
adlights will switch on.
Parking lights on
Headlights, parking lights, license plate lights and instrument panel i\
llumination are on if the
ignition key is in position II.
If the headlight switch is in position
all lights will go out when the ignition is switched off.
The headlight switch must be in this position before the high beams will\
function (this also applies on
models equipped with the optional Bi-Xenon headlights).
Switch from high to low beams and vice versa by pulling the turn signal \
switch lever on the left side of
steering column toward you.
B - Instrument illumination
Move the thumbwheel up to increase brightness or down to decrease bright\
ness. There is also an
instrument panel illumination sensor (see illustration on
page 48) which automatically adjusts the level
of illumination.
C -Unlocking the fuel filler door
Press this button when the car is at a standstill to unlock the fuel fil\
ler door. Please note that the fuel
filler door will remain unlocked until the car begins to move forward. A\
n audible click will be heard
when the fuel filler door relocks.
See also
page 86.
file:///K|/ownersdocs/2004/2004_XC70/04xc70_02b.htm (3 of 18)12/30/200\
6 4:32:58 PM

2004 VOLVO XC70
NOTE: If the fuel filler door does not unlock after the button has been press\
ed, drive the car at a speed
of at least 5 mph (8 km/h), stop the car, and press the button again. \


pg. 35 Light switch panel, Steering wheel adjustment/lock
D - Front fog lights (option)
The front fog lights will function only in combination with the low beam\
headlights.
An LED in the switch indicates when the front fog lights are on.
E - Rear fog light
The rear fog light is considerably brighter than the normal tail lights \
and should be used only when
conditions such as fog, rain, snow, smoke or dust reduce visibility for \
other vehicles to less than 500 ft
(150 meters).
An LED in the switch indicates when the rear fog light is on.
The rear fog light will only function in combination with the high/low b\
eam headlights.
By design, there is one rear fog light only, located in the driver's sid\
e tail light cluster.
Rear fog light in the instrument panel
This light indicates that the rear fog light is on.

Pull down the lever (A) to adjust height (B), or reach (C)
Steering wheel adjustment
file:///K|/ownersdocs/2004/2004_XC70/04xc70_02b.htm (4 of 18)12/30/200\
6 4:32:58 PM

2004 VOLVO XC70
Both the height and the reach of the steering wheel can be adjusted to a\
comfortable position for the
driver. Pull down the lever on the left of the steering column. Adjust t\
he steering wheel to a suitable
position and press the lever back into place to lock the steering wheel \
in the new position. Check that the
steering wheel is locked in the new position. WARNING!
Never adjust the steering wheel while
driving.
Steering wheel lock
The steering wheel lock might be under tension when the car is parked.
Turn the steering wheel slightly to free the ignition key.
In order to help reduce car theft, make sure the steering wheel lock is \
engaged before leaving the
car. WARNING!
Never switch off the ignition (turn the ignition key to position 0) or\
remove the key from the ignition
switch while the car is in motion. This could cause the steering wheel t\
o lock, which would make the
car impossible to steer.


pg. 36 Ignition switch, Turn signals
file:///K|/ownersdocs/2004/2004_XC70/04xc70_02b.htm (5 of 18)12/30/200\
6 4:32:58 PM

2004 VOLVO XC70
A chime will sound if the key is left in the ignition and the driver's d\
oor is opened.
* The gear selector must be in the (P)ark position.
** Please be aware that leaving the key in this position will increase b\
attery drain.
Turn signals
1 Lane change position. In maneuvers such as lane changing, the driver can flash the turn signal\
s by
moving the turn signal lever to the first stop and holding it there. The\
lever will return to the neutral
position when released.
2 Signal lever engaged for normal turns.
3 High beam/low beam switch (headlights on).
Move the lever towards the steering wheel and release it.
Headlight flasher (headlights off).
Move the lever towards the steering wheel. The headlight high beam will \
be on until the lever is
released.
NOTE: If the turn signal indicator flashes faster than normal, check for a bur\
ned-out turn signal bulb.

pg. 37 Windshield/tailgate wipers/washers

file:///K|/ownersdocs/2004/2004_XC70/04xc70_02b.htm (6 of 18)12/30/200\
6 4:32:58 PM

2004 VOLVO XC70

Windshield wiper/washer
Windshield wipers/washers
0 Windshield wipers off
Intermittent wiper function. With the lever in this position, you can s\
et the wiper interval by
twisting control A upward to increase wiper speed or downward to decreas\
e the speed.
Rain sensor (option)
The rain sensor replaces the intermittent wiper function and automatical\
ly regulates wiper speed
according to the amount of water on the windshield. The sensitivity of the sensor can be adjusted by
twisting control A upward or downward.
Activating the rain sensor function:
1. Switch on the ignition.
2. Move the windshield wiper lever to the intermittent position.
The rain sensor is deactivated when the ignition is switched completely \
off.
To reactivate the rain sensor function:
1. Switch on the ignition.
2. Move the windshield wiper lever to position 0 and then back to the in\
termittent position.
CAUTION: When washing the car in an automatic carwash, etc move the windshield wi\
per lever to
position 0 or switch off the ignition completely to deactivate the rain \
sensor. If the sensor function is left
on, the wipers will start inadvertently in the carwash and could be dama\
ged.
Normal wiper speed
file:///K|/ownersdocs/2004/2004_XC70/04xc70_02b.htm (7 of 18)12/30/200\
6 4:32:58 PM

2004 VOLVO XC70
High wiper speed
3 Windshield wiper/washer, headlight wiper/washer (certain models). Pull\
the lever toward you and
release it. The wipers will make 2-3 sweeps across the windshield and he\
adlights (certain models) after
the lever is released.
"Single sweep" position: Move the lever slightly upward from the 0 position for one sweep of
the wipers. The lever returns automatically to 0 when released.


Tailgate wiper/washer
Tailgate washer/wiper
A - Intermittent wiping
B - normal wiping
To operate the tailgate washer: Move the lever forward to start the tailgate washer.
Tailgate wiper and reverse gear
If the front wipers are on and the car is put into reverse gear, then th\
e tailgate wiper will go into
intermittent wiping function*.
If the tailgate wiper is already in normal wiping function, the normal w\
iping function will continue.
* Consult your Volvo retailer if you would like to have this function de\
activated.

pg. 38 Warning flashers, Heated mirrors/rear window, Heated front seats
file:///K|/ownersdocs/2004/2004_XC70/04xc70_02b.htm (8 of 18)12/30/200\
6 4:32:58 PM
