2004 VOLVO XC70
driving in your Volvo, an automobile designed with your safety and comfo\
rt in mind. To help ensure
your satisfaction with this vehicle, we encourage you to familiarize you\
rself with the equipment
descriptions, operating instructions and maintenance requirements/recomm\
endations in this manual. We
also urge you and your passengers to wear seat belts at all times in thi\
s or any other automobile. And, of
course, please do not operate a vehicle if you may be affected by alcoho\
l, medication or any impairment
that could hinder your ability to drive.
Your Volvo is designed to meet all applicable safety and emission standa\
rds, as evidenced by the
certification labels attached to the driver's door opening and on the le\
ft wheel housing in the engine
compartment. For further information please contact your retailer, or:
In the USA: In Canada:
Volvo Cars of North America Volvo Cars of Canada Ltd.
Customer Relations 175 Gordon Baker Road
P.O. Box 914 North York, Ontario M2H 2N7
Rockleigh, New Jersey 07647-0914 800-663-8255
800-458-1552

We also invite you to visit our Home Page on the Internet at:
http://www.volvocars.com

Contents

Contents
Chapter 1 - Safety
Chapter 2 - Instruments, switches and controls
Chapter 3 - Climate control system
Chapter 4 - Interior
Chapter 5 - Keys, Locks, Alarm
Chapter 6 - Starting and driving
Chapter 7 - Wheels and tires
file:///K|/ownersdocs/2004/2004_XC70/04xc70_00.htm (2 of 6)12/30/2006 \
4:32:53 PM

2004 VOLVO XC70
Chapter 8 - Maintenance/Servicing
Chapter 9 - Specifications
Chapter 10 - Audio systems
HomeLink® Universal Transceiver (option)
Index
Back Cover
General information

Shiftlock
When your car is parked, the gear selector is locked in the (P)ark pos\
ition. To release the selector from
this position, turn the ignition key to position II (or start the engin\
e), depress the brake pedal, press the
button on the front of the gear selector knob and move the selector from\
(P)ark.
Keylock
This means that when you switch off the ignition, the gear selector must\
be in the (P)ark position before
the key can be removed from the ignition switch.
Anti-lock Brake System (ABS)
The ABS system in your car performs a self-diagnostic test when the vehi\
cle first reaches the speed of
approximately 12 mph (20 km/h). The brake pedal will pulsate several t\
imes and a sound may be audible
from the ABS control module. This is normal.
Fuel filler door
Press the button on the light switch panel (see
page 34) when the car is at a standstill to unlock the fuel
filler door. Please note that the fuel filler door will remain unlocked \
until the car begins to move
forward. An audible click will be heard when the fuel filler door relock\
s.
Fuel filler cap
After refueling, close the fuel filler cap by turning it clockwise until\
it clicks into place. If this cap is not
closed tightly or if the engine is running when the car is refueled, the\
Malfunction Indicator Lamp
file:///K|/ownersdocs/2004/2004_XC70/04xc70_00.htm (3 of 6)12/30/2006 \
4:32:53 PM

2004 VOLVO XC70
darkness, the daytime running lights will switch off and the Bi-Xenon he\
adlights will switch on.
Parking lights on
Headlights, parking lights, license plate lights and instrument panel i\
llumination are on if the
ignition key is in position II.
If the headlight switch is in position
all lights will go out when the ignition is switched off.
The headlight switch must be in this position before the high beams will\
function (this also applies on
models equipped with the optional Bi-Xenon headlights).
Switch from high to low beams and vice versa by pulling the turn signal \
switch lever on the left side of
steering column toward you.
B - Instrument illumination
Move the thumbwheel up to increase brightness or down to decrease bright\
ness. There is also an
instrument panel illumination sensor (see illustration on
page 48) which automatically adjusts the level
of illumination.
C -Unlocking the fuel filler door
Press this button when the car is at a standstill to unlock the fuel fil\
ler door. Please note that the fuel
filler door will remain unlocked until the car begins to move forward. A\
n audible click will be heard
when the fuel filler door relocks.
See also
page 86.
file:///K|/ownersdocs/2004/2004_XC70/04xc70_02b.htm (3 of 18)12/30/200\
6 4:32:58 PM

2004 VOLVO XC70
NOTE: If the fuel filler door does not unlock after the button has been press\
ed, drive the car at a speed
of at least 5 mph (8 km/h), stop the car, and press the button again. \


pg. 35 Light switch panel, Steering wheel adjustment/lock
D - Front fog lights (option)
The front fog lights will function only in combination with the low beam\
headlights.
An LED in the switch indicates when the front fog lights are on.
E - Rear fog light
The rear fog light is considerably brighter than the normal tail lights \
and should be used only when
conditions such as fog, rain, snow, smoke or dust reduce visibility for \
other vehicles to less than 500 ft
(150 meters).
An LED in the switch indicates when the rear fog light is on.
The rear fog light will only function in combination with the high/low b\
eam headlights.
By design, there is one rear fog light only, located in the driver's sid\
e tail light cluster.
Rear fog light in the instrument panel
This light indicates that the rear fog light is on.

Pull down the lever (A) to adjust height (B), or reach (C)
Steering wheel adjustment
file:///K|/ownersdocs/2004/2004_XC70/04xc70_02b.htm (4 of 18)12/30/200\
6 4:32:58 PM

2004 VOLVO XC70
Electrically operated sideview mirrors
The mirror control switches are located on the driver's door armrest.
Driver's side: Press the L switch (an LED in the switch will light up) to activate th\
e adjustment control
and then use this control to adjust the driver's door mirror.
Passenger's door: Press the R switch (an LED in the switch will light up) and then use t\
he adjustment
control to adjust the passenger's door mirror.
After you have adjusted the mirror(s), press the L or R switch again (\
the LED will go out) to deactivate
the adjustment control.
Remote central locking and sideview mirror memory
If you lock the car and later unlock it with the same remote control and open the driver's door, the
sideview mirrors will automatically move to the position they were in wh\
en you left the car. This feature
will work in the same way with all of the remote control transmitters (\
up to 3) that you use with your
car.
This feature will not function if you lock your car with the key. WARNING!
The mirrors should always be adjusted prior to driving. Objects seen in \
the wide-angle sideview
mirror are closer than they appear to be.


pg. 42 Power moonroof (option)

file:///K|/ownersdocs/2004/2004_XC70/04xc70_02b.htm (15 of 18)12/30/20\
06 4:32:58 PM

2004 VOLVO XC70
Electrically operated front seats (option)
From the time the driver's door is unlocked, the driver's seat can be ad\
justed with the ignition off during
a 10 minute period, if the door remains opened. If the door is closed, the seat can be adjusted for 40
seconds.
1 - Power seat control panel
2 - Lumbar support
Turn the control for softer or firmer lumbar support.
Move the seat as far rearward as possible for easiest access to the lumb\
ar support control.
Electrically operated seats with memory function (option)*
Power seat control panel
A Front edge of seat (raise/lower)
B Forward - rearward
C Rear edge of seat (raise/lower)
D Backrest tilt
file:///K|/ownersdocs/2004/2004_XC70/04xc70_04a.htm (2 of 11)12/30/200\
6 4:32:59 PM

2004 VOLVO XC70

pg. 57 Front seats
Electrically operated seats - general information
Adjusting the front seats:
Passengers's seat: The passenger's seat can only be adjusted if the ignition key is in posi\
tion I or II.
Driver's seat: The driver's seat can be adjusted if the ignition key is in position I o\
r II (see
page 36).
However, it can also be adjusted:
l Within 40 seconds after the ignition has been switched off (even if the\
key has been removed from the
ignition switch).
l Within 40 seconds after the driver's door has been unlocked with the key\
or remote control and
opened. The key does not have to be in the ignition switch during this p\
eriod.
Remote keyless entry system and driver's seat
The remote control transmitter also controls the electrically operated d\
river's seat in the following way:
l Adjust the seat to your preferences.
l When you leave your car, lock it using the remote control.
l The next time you unlock the driver's door with the same remote control(the one you used to lock the
doors with) and open the driver's door, the driver's seat will automatically move to the position in which
you left it.
The seat will move to this position even if someone else has adjusted it\
since you last unlocked the car
with the same remote control.
NOTE:
l This feature will work in the same way with all of the remote control tr\
ansmitters (up to 3) that you
use with your car.
l This feature will not function if you lock your car with the key.
file:///K|/ownersdocs/2004/2004_XC70/04xc70_04a.htm (4 of 11)12/30/200\
6 4:32:59 PM

2004 VOLVO XC70
Nylon cargo net (option on XC70)
The Volvo XC70 can be equipped with a cargo net made of strong nylon fab\
ric that can be installed with
the rear seat backrests in the upright position or folded down.
The upper and lower rods of the cargo net are hinged. If the cargo net i\
s folded, fold the rods until they
are straight and lock in position.
l Insert the end of the upper rod in the bracket A, near the ceiling liner\
in the cargo area if the rear seat
backrests are up or in the brackets above the rear passenger doors if th\
e backrests are folded down.
l Insert the opposite side of the rod in the upper bracket on the opposite\
side.
l Attach the lower straps to the eyelets on opposite sides of the rear car\
go area (if the rear seat backrest
is upright), or to the eyelets near the base of the rear seat, D (if the backrest sections are folded down and
the upper rod has been attached to the forward brackets). Adjust the st\
raps to pull the net taut.
file:///K|/ownersdocs/2004/2004_XC70/04xc70_04b.htm (14 of 21)12/30/20\
06 4:33:00 PM

2004 VOLVO XC70
Auxiliary seat (option)
If all the seats are occupied, a rear-facing auxiliary seat in the cargo\
area can be used. This seat is
designed for two children, each weighing between 50 - 88 lbs. (23 - 40 \
kg) with a total seat capacity of
176 lbs. (80 kg) and up to 55 inches (140 cm) in height.
Raising
Remove the cargo area cover, if installed, from the car. Raise the backr\
est section forward until it locks
in place.
Flip the seat cushion over.
Lowering
Flip the seat cushion back into storage position.
Pull the release handle and lower the backrest to storage position. WARNING!
l If your car is equipped with an auxiliary seat (option or accessory), \
the tailgate must be fitted with
a lock cylinder. Unlocking from the outside can then be carried out in t\
he usual way (key in driver's
door and/or remote control) and also by using the key in the tailgate. \
l Both rear seat backrests must be up when the auxiliary seat is being use\
d. Do not use a booster
cushion or child seat in conjunction with the auxiliary seat.
l The luggage net should be retracted and the child safety lock in the tai\
lgate should be open to allow
access to the cargo area.
NOTE: If you have locked the car with the remote control and if you then after\
wards use a key in the
tailgate's lock cylinder (certain models) to unlock the tailgate only,\
the alarm will sound. See
page 80 for
information on turning off a sounding alarm.
file:///K|/ownersdocs/2004/2004_XC70/04xc70_04b.htm (18 of 21)12/30/20\
06 4:33:00 PM

2004 VOLVO XC70
The courtesy light stays on for 10 minutes if one of the doors is left open after the car is unlocked.
The courtesy light switches off if:
l The engine is started.
l The car is locked from the outside with the key or remote control.
The interior courtesy light can be switched on or off at any time by pre\
ssing the center button in the
panel above the rearview mirror. When switched on with the engine off, t\
he light will stay on for 10
minutes. When switched on with the engine running, the light will stay o\
n indefinitely. The light may be
switched off at any time by pressing the center button a second time.
The courtesy light timer periods can be changed. Consult your Volvo reta\
iler.
Overriding the Interior Courtesy Lights
Normally if a car door is left open with the engine turned off, the inte\
rior courtesy light will stay on for
10 minutes.
If a car door is left open or the interior courtesy lights are turned on\
while the engine is left running, the
interior courtesy lights will stay on indefinitely.
At times, you may wish to be assured that the courtesy lights will stay \
off regardless of door or tailgate
position.
To switch off the interior and tailgate courtesy lights indefinitely, pr\
ess and hold the center button in the
panel above the rearview mirror for 3 seconds. The courtesy lights will \
go off and remain off until the
center button is pressed again.

file:///K|/ownersdocs/2004/2004_XC70/04xc70_04b.htm (20 of 21)12/30/20\
06 4:33:01 PM
