Page 129 of 241

2004 VOLVO XC70
Towing cars with all wheel drive/front wheel drive
Volvo recommends the use of flat bed equipment. If wheel lift equipment \
must be used, please use
extreme caution to help avoid damage to the car. In this case, the car should be towed with the rear
wheels on the ground if at all possible.
If it is absolutely necessary to tow the vehicle with the front wheels o\
n the ground, please refer to the
towing information on the previous page.
CAUTION:
l The car must not be driven with wheels of different dimensions/specifica\
tions or with a spare tire
other than the one that came with the car. The use of different size whe\
els can seriously damage your
car's transmission.
l Sling-type equipment applied at the front will damage radiator and air c\
onditioning lines.
l It is equally important not to use sling-type equipment at the rear or a\
pply lifting equipment inside the
rear wheels; serious damage to the rear axle may result.
l If the car is being towed on a flat bed truck, the towing eyelets must n\
ot be used to secure the car on
the flat bed. Consult the tow truck operator.
WARNING!
l Do not use the towing eyelets to pull the car up onto a flat bed tow tru\
ck.
s
file:///K|/ownersdocs/2004/2004_XC70/04xc70_06b.htm (3 of 10)12/30/200\
6 4:33:02 PM
Page 139 of 241

2004 VOLVO XC70
spare tire other than the one that came with the car. The use of differe\
nt size wheels can seriously
damage your car's transmission or driveline.
pg. 111 Wheels and tires
Snow chains
Snow chains can be used on your Volvo with the following restrictions:
l Snow chains should be installed on front wheels only. Use only Volvo app\
roved snow chains.
l Special snow chains must be mounted on 215/55 R16. Consult your Volvo re\
tailer.
l If accessory, aftermarket or "custom" tires and wheels are installed and\
are of a size different than the
original tires and wheels, chains in some cases CANNOT be used. Sufficie\
nt clearances between chains
and brakes, suspension and body components must be maintained. Snow chai\
ns cannot be used on 17"
wheels*.
l Some strap-on type chains will interfere with brake components and there\
fore CANNOT be used.
l All Wheel Drive models:Snow chains should only be installed on the front wheels. Only chains
adapted for AWD models should be used.
Consult your Volvo retailer for additional snow chain information.
CAUTION:
l Check local regulations regarding the use of snow chains before installi\
ng.
l Always follow the chain manufacturer's installation instructions careful\
ly. Install chains as tightly as
possible and retighten periodically.
l Never exceed the chain manufacturer's specified maximum speed limit. In \
no case should you exceed
31 mph (50 km/h).
l Avoid bumps, holes or sharp turns when driving with snow chains.
l Vehicle handling can be adversely affected when driving with chains. Avo\
id fast maneuvering and
hard braking. Never allow the wheels to lock up during braking.
* V70R - Volvo offers specially designed chains that can be used on 225/\
45/R17 tires.
Snow tires, studded tires **
Tires for winter use:
Owners who live in or regularly travel through areas with sustained peri\
ods of snow or icy driving
file:///K|/ownersdocs/2004/2004_XC70/04xc70_07.htm (3 of 11)12/30/2006\
4:33:03 PM
Page 141 of 241

2004 VOLVO XC70
Checking and correcting tire pressure
l Check the tire pressure regularly.
l The tire pressure should be corrected only when the tires are cold.
l With warm tires, correct only when the pressure is too low. The tire tem\
perature rises after driving
just a few miles.
Vehicle loading
The tires on your Volvo will perform to specifications at all normal loa\
ds when inflated as
recommended on the tire information label located on the inside of the f\
uel filler door*. This label also
lists vehicle load limits. Do not load your car beyond the indicated lim\
its.
WARNING!
Improperly inflated tires will reduce tire life, adversely affect vehicl\
e handling and can possibly lead
to failure resulting in loss of vehicle control without prior warning.
Temporary Spare
The spare tire in your car is called a "Temporary Spare". It has the fol\
lowing designation: T125/80 R17
(XC70 - T135/90 R17, V70R - T115/85/R18 ).
At the recommended tire pressure shown on the inside of the fuel filler \
door, the tire may be used as a
temporary replacement for a front or rear tire.
In the event of damage to this tire, a new one can be purchased from you\
r Volvo retailer. WARNING!
Current legislation prohibits the use of the "Temporary Spare" tire othe\
r than as a temporary
replacement for a punctured tire. It must be replaced as soon as possibl\
e by a standard tire. Road
holding and handling may be affected with the "Temporary Spare" in use. \
Do not exceed 50 mph (80
km/h). Do not drive farther than 50 miles (80 km) on a temporary spar\
e tire.
CAUTION:
The car must not be driven with wheels of different dimensions or with a\
spare tire other than the one
that came with the car. The use of different size wheels can seriously d\
amage your car's transmission.
file:///K|/ownersdocs/2004/2004_XC70/04xc70_07.htm (5 of 11)12/30/2006\
4:33:03 PM
Page 142 of 241

2004 VOLVO XC70
NOTE: Certain models may be equipped with a full-size spare tire. When used, i\
t should be inflated to
the same pressure as the tire it is replacing.
*Please note that the tire information label indicates pressure for both\
comfort and fuel economy.
pg. 113 Wheels and tires
Uniform tire quality grading
ALL PASSENGER CAR TIRES MUST CONFORM TO FEDERAL SAFETY REQUIREMENTS
IN ADDITION TO THESE GRADES
Quality grades can be found, where applicable, on the tire sidewall betw\
een the tread shoulder and
maximum section width. For example:
Treadwear 200 Traction AA Temperature A
TREADWEAR
The treadwear grade is a comparative rating based on the wear rate of th\
e tire when tested under
controlled conditions on a specified government test course. For example\
, a tire graded 150 would wear
one and one half (1 1/2) times as well on the government course as a t\
ire graded 100. The relative
performance of tires depends upon the actual conditions of their use, ho\
wever, and many depart
significantly from the norm due to variation in driving habits, service \
practices and differences in road
characteristics and climate.
TRACTION
The traction grades, from highest to lowest, are AA, A, B, and C, as mea\
sured under controlled
conditions on specified government test surfaces of asphalt and concrete\
. A tire marked C may have
poor traction performance. WARNING!
The traction grade assigned to this tire is based on braking (straight-\
ahead) traction tests and is not a
measure of cornering (turning) traction.
file:///K|/ownersdocs/2004/2004_XC70/04xc70_07.htm (6 of 11)12/30/2006\
4:33:03 PM
Page 146 of 241

2004 VOLVO XC70
Jack for AWD models
CAUTION:
l The car must not be driven with wheels of different dimensions or with a\
spare tire other than the one
that came with the car. The use of different size wheels can seriously d\
amage your car's transmission.
l Correct tightening torque on wheel bolts must be observed. The wheel bol\
ts should never be greased
or lubricated. The extended, chromed wheel bolts must not be used with s\
teel rims, as they make it
impossible to fit the hub caps.
Correct tightening order for wheel bolts
Installing the wheel
l Clean the contact surfaces on the wheel and hub.
l Lift the wheel and place it on the hub. Make sure that you align the whe\
el with the guide stud on the
wheel hub prior to installation.
l Install the wheel bolts and tighten hand-tight. Using the lug wrench, ti\
ghten crosswise (see illustration
above) until all bolts are snug.
l Lower the vehicle to the ground and alternately tighten the bolts crossw\
ise to 100 ft. lbs. (136 Nm).
l Install the wheel cap (where applicable).
