width VOLVO XC70 2004 Owners Manual

2004 VOLVO XC70
2 0 0 4
VOLVO XC70
Chapter 7 - Wheels and tires


pg.109 Wheels and tires

General information, Wear indicator, Tire economy, Flat
spots 110
Snow chains, Snow tires/studded tires 111
Inflation pressure, Vehicle loading, Spare tire 112
Uniform tire quality grading 113
Changing wheels 114

pg. 110 Wheels and tires
General information
Your vehicle is equipped with tires according to the tire information la\
bel on the inside of the fuel
filler door.
The following is an example of a tire designation code: 225/55 R16
225 = tire width in mm.
55 = tire profile. This is the relationship (in percent) between the sect\
ion height and width of the tire.
R = radial tires.
16 = diameter in inches.
The tires have good road holding characteristics and offer good handling\
on dry and wet surfaces. It
should be noted however that the tires have been developed to give these\
features on snow/ice-free
surfaces. Certain models are equipped with "all-season" tires, which provide a som\
ewhat higher
degree of road holding on slippery surfaces than tires without the "all-\
season" rating. However,
for optimum road holding on icy or snow covered roads - we recommend suitable winter tires on all
file:///K|/ownersdocs/2004/2004_XC70/04xc70_07.htm (1 of 11)12/30/2006\
4:33:03 PM

2004 VOLVO XC70
NOTE: Certain models may be equipped with a full-size spare tire. When used, i\
t should be inflated to
the same pressure as the tire it is replacing.
*Please note that the tire information label indicates pressure for both\
comfort and fuel economy.

pg. 113 Wheels and tires
Uniform tire quality grading
ALL PASSENGER CAR TIRES MUST CONFORM TO FEDERAL SAFETY REQUIREMENTS
IN ADDITION TO THESE GRADES
Quality grades can be found, where applicable, on the tire sidewall betw\
een the tread shoulder and
maximum section width. For example:
Treadwear 200 Traction AA Temperature A
TREADWEAR
The treadwear grade is a comparative rating based on the wear rate of th\
e tire when tested under
controlled conditions on a specified government test course. For example\
, a tire graded 150 would wear
one and one half (1 1/2) times as well on the government course as a t\
ire graded 100. The relative
performance of tires depends upon the actual conditions of their use, ho\
wever, and many depart
significantly from the norm due to variation in driving habits, service \
practices and differences in road
characteristics and climate.
TRACTION
The traction grades, from highest to lowest, are AA, A, B, and C, as mea\
sured under controlled
conditions on specified government test surfaces of asphalt and concrete\
. A tire marked C may have
poor traction performance. WARNING!
The traction grade assigned to this tire is based on braking (straight-\
ahead) traction tests and is not a
measure of cornering (turning) traction.
file:///K|/ownersdocs/2004/2004_XC70/04xc70_07.htm (6 of 11)12/30/2006\
4:33:03 PM

2004 VOLVO XC70
pg. 145 Dimensions and weights
Dimensions
Length - 185.4 in. (471 cm), XC70 -186.2 (473 cm)
Width - 71 in. (180 cm), XC70 - 73.2 in. (186 cm)
Height - 57.7 in. (147 cm), V70 AWD - 58.7 in. (149 cm), XC70 - 61.5\
in. (156 cm)
Wheelbase - 108.5 in. (276 cm), XC70 - 108.8 in. (276 cm)
Track, front - 61.5 in. (156 cm), XC70 - 63.4 in. (161 cm)
Track, rear - 61.4 in. (156 cm), XC70 - 60.9 in. (155 cm)
Turning circle (between curbs) - 35.8-39 ft. (10.9-11.9 m)
Cargo capacity - 17.1 cu. ft. (0.48 m
3 )1
- 26.3 cu. ft. (0.74 m
3 )2
- 58.0 cu. ft. (1.64 m
3 )3
USA Canada
Max roof load 220 lbs 100 kg
Max trailer weight (w/o
brakes) 1650 lbs
750 kg
Max trailer weight*
- (with brakes, 2" ball) 3300
lbs 1500 kg
- (with brakes, 1 7/8" ball) 2000
lbs 900 kg
Max tongue weight * 165 lbs 75 kg
WARNING!
When adding accessories, equipment, luggage and other cargo to your vehi\
cle, the total loaded weight
capacity of the vehicle must not be exceeded.
1) Rear seat backrest up, load height - upper edge of backrest
2) Rear seat backrest folded down, load height - upper edge of front se\
at backrests/lower edge of rear
window
3) Rear seat backrest folded down, load height - head lining (ceiling)\

* When driving for prolonged periods at temperatures above 86° F (30\
° C), the maximum recommended
weight is 2000 lbs (900 kg).
**See also section "Trailer towing"
