The gear selector must be in the D (Drive) position.
Kickdown
Automatic shift to a lower gear (kickdown) is achieved by depressing t\
he accelerator pedal fully and
briskly. An upshift will occur when approaching the top speed for a part\
icular gear or by releasing the
accelerator pedal slightly.
Kickdown can be used for maximum acceleration or when passing at highway\
speeds.
Kickdown does not function when the transmission is in the manual shift \
(Geartronic) mode.
W - Winter/Wet driving mode - enhanced vehicle traction
Please refer to the information on
page 131.
Sport mode (R-models only)
R-models are equipped with a (S)port button that can be used to engage\
/disengage the Sport shifting
mode. An indicator light in the button will go on when Sport mode is eng\
aged.
With Sport mode engaged, the transmission will shift up at higher rpm in\
first and second gears, and will
also shift down at higher rpm for more immediate engine response during \
acceleration and deceleration.
pg. 134 Starting and driving
All Wheel Drive (option)
All Wheel Drive (AWD) - general information
Your Volvo can be equipped with permanent All Wheel Drive, which means t\
hat power is distributed
automatically between the front and rear wheels. Under normal driving co\
nditions, most engine's power
is directed to the front wheels. However, if there is any tendency for t\
he front wheels to spin, an
electronically controlled coupling distributes power to the wheels that \
have the best traction.
Tire dimensions
file:///K|/ownersdocs/2007/2007_XC70/07xc70_06.htm (19 of 41)12/30/200\
6 5:51:38 PM

2007 Volvo XC70
This mode is recommended for long-distance driving, or when driving in s\
lippery conditions. The
indicator light in the button will be off when this mode is selected.
If Comfort mode was selected when the engine was switched off, this mode\
will still be active when the
engine is restarted.
Sport
In this mode, shock absorption is stiffer to reduce the vehicle's body s\
way during cornering and to
provide more immediate steering response. The indicator light in the but\
ton will come on to indicate that
Sport mode has been selected.
If this setting was selected when the engine was switched off, Sport mod\
e will still be active when the
engine is restarted.
Advanced sport (V70 R only)
In this mode, movement of the shock absorbers is minimal, response from \
pressure on the throttle pedal
is more direct, and body sway in curves or when cornering is sharply red\
uced.
If Advanced sport mode was selected when the engine was switched off, Sport mode will be active
when the engine is restarted.
pg. 136 Starting and driving
Brake system
BRAKE Brake circuit malfunction
The brake system is a hydraulic system consisting of two master cylinder\
s and two separate brake
circuits. If a problem should occur in one of these circuits, it is stil\
l possible to stop the vehicle with the
other brake circuit.
If the brake pedal must be depressed farther than normal and requires gr\
eater foot pressure, the stopping
distance will be longer.
A warning light in the instrument panel will light up to warn the driver\
that a fault has occurred.
If this light comes on while driving or braking, stop immediately and ch\
eck the brake fluid level in the
file:///K|/ownersdocs/2007/2007_XC70/07xc70_06.htm (21 of 41)12/30/200\
6 5:51:38 PM

2007 Volvo XC70
- If the indicator light remains on, drive to an authorized Volvo worksh\
op as soon as possible to have the
system checked.
The Stability Control indicator light glows steadily
If "STC/DSTC SPIN CONTROL OFF" is displayed in the text window at the sa\
me time, this is a
reminder that spin control has been disabled by the driver.
The warning symbol
The warning symbol glows steadily yellow
NOTE: The system has been temporarily switched off due to high brake temperat\
ure. "TRACTION
CONTROL TEMPORARILY OFF" will be displayed. The system will automaticall\
y switch on again
when the brakes have cooled.
pg. 141 Starting and driving
Stability system
WARNING!
The stability system is intended to help improve driving safety. It supp\
lements, but can never replace,
the driver's judgement and responsibility when operating the vehicle. Sp\
eed and driving style should
always be adapted to traffic and road conditions.
pg. 142 Starting and driving
Towing
file:///K|/ownersdocs/2007/2007_XC70/07xc70_06.htm (27 of 41)12/30/200\
6 5:51:38 PM

2007 Volvo XC70
assembly.
- Slide the ball holder into the hitch assembly.
- Align the hole in the ball holder with the one in the hitch assembly. \
- Slide the locking bolt through the hitch assembly/ball holder.
- Insert the cotter pin in the hole at the end of the locking bolt.
Removing the ball holder
- Remove the cotter pin from the locking bolt and slide the locking bolt\
out of the ball holder/hitch
assembly.
- Pull the ball holder out of the hitch assembly.
A cover for the hitch assembly can be purchased from your Volvo retailer\
.
pg. 148 Starting and driving
Load carriers (accessory)
Load carriers
Load carriers are available as Volvo accessories. Observe the following \
points when in use:
l To avoid damaging your vehicle and to achieve maximum safety when drivin\
g, we recommend using
the load carriers that Volvo has developed especially for your vehicle. \
l Volvo-approved removable roof racks are designed to carry the maximum al\
lowable roof load for this
vehicle: 220 lbs (100 kg). For Non-Volvo roof racks, check the manufac\
turer's weight limits for the rack.
l Never exceed the rack manufacturer's weigh limits and never exceed the m\
aximum rated roof load of
220 lbs (100 kg).
l Avoid single-point loads. Distribute loads evenly.
l Place heavier cargo at the bottom of the load.
l Secure the cargo correctly with appropriate tie-down equipment.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_06.htm (34 of 41)12/30/200\
6 5:51:38 PM

2007 Volvo XC70
l Check periodically that the load carriers and load are properly secured.\

l Remember that the vehicle's center of gravity and handling change when y\
ou carry a load on the roof.
l The vehicle's wind resistance and fuel consumption will increase with th\
e size of the load.
l Drive smoothly. Avoid rapid starts, fast cornering and hard braking.
Attaching load carriers
The attachment brackets for the load carriers are located under the roof\
molding.
- Make sure that the load carriers are placed in the right direction. Se\
e the mark on the decal under the
cover.
- Press the guide lugs into the holes (1).
- Carefully lower the opposite side of the load carrier to the roof.
- Loosen the tightening wheel slightly. Slide the hook on the load carri\
er attachment into the attachment
bracket under the roof molding.
- Turn the tightening wheel to secure the load carrier in the attachment\
bracket.
pg. 149 Starting and driving
Load carriers (accessory)
- Repeat this procedure for the other load carrier attachments.
- Check that the hooks on all four load carrier attachments are securely\
tightened in the respective
attachment brackets on the roof of the vehicle.
- Press down the covers.
Check periodically that the load carriers and load are properly secured.\

pg. 150 Starting and driving
file:///K|/ownersdocs/2007/2007_XC70/07xc70_06.htm (35 of 41)12/30/200\
6 5:51:38 PM

2007 Volvo XC70
Load carriers (accessory)
Attaching load carriers (models with rails)
Positioning the load carriers
Make sure that the wing-shaped load carriers are installed on the roof r\
ails with the rounded edge
forward (see the inset illustration above). The load carriers are iden\
tical and can be placed anywhere
along the roof rails.
Tightening the load carriers
Make sure that the load carrier is pressed firmly out against the roof r\
ail. Screw the load carrier in place.
Use the supplied torque wrench and tighten to the mark on the wrench (c\
orresponding to 6 Nm). See the
illustration above.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_06.htm (36 of 41)12/30/200\
6 5:51:38 PM

2007 Volvo XC70
pg. 157 Wheels and tires
General information
WARNING!
l The wheel and tire sizes for your Volvo are specified to meet stringent \
stability and handling
requirements. Unapproved wheel/tire size combinations can negatively aff\
ect your vehicle's stability
and handling. Approved tire sizes are shown in the Tire inflation pressu\
re tables on
pages 160 and
161.
l Any damage caused by installation of unapproved wheel/tire size combinat\
ions will not be covered
by your new vehicle warranty. Volvo assumes no responsibility for death,\
injury, or expenses that
may result from such installations.
New tires
Remember that tires are perishable goods. As of 2000, the manufacturing \
week and year will be
indicated with 4 digits (e.g. 1502 means that the tire illustrated was \
manufactured during week 15 of
2002).
Tire age
Tires degrade over time, even when they are not being used. It is recomm\
ended that tires generally be
replaced after 6 years of normal service. Heat caused by hot climates, f\
requent high loading conditions
or Ultra Violet (U.V) exposure can accelerate the aging process.
You should replace the spare tire when you replace the other road tires \
due to the aging of the spare.
A tire's age can be determined by the DOT stamp on the sidewall (see th\
e illustration above).
A tire with e.g., visible cracks or discoloration should be replaced imm\
ediately.
Improving tire economy:
l Maintain correct tire pressure. See the tire pressure table on pages 160 and 161.
l Drive smoothly: avoid fast starts, hard braking and tire screeching.
l Tire wear increases with speed.
l Correct front wheel alignment is very important.
l Unbalanced wheels impair tire economy and driving comfort.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_07.htm (3 of 24)12/30/2006\
5:51:40 PM

2007 Volvo XC70
NOTE: The placards shown indicate inflation pressure for the tires installed \
on the vehicle at the factory
only.
l Use a tire gauge to check the tire inflation pressure, including the spa\
re, at least once a month and
before long trips. You are strongly urged to buy a reliable tire pressur\
e gauge, as automatic service
station gauges may be inaccurate.
l Use the recommended cold inflation pressure for optimum tire performance\
and wear.
l Under-inflation or over-inflation may cause uneven treadwear patterns.
WARNING!
l Under-inflation is the most common cause of tire failure and may result \
in severe tire cracking,
tread separation, or "blowout," with unexpected loss of vehicle control \
and increased risk of injury.
l Under-inflated tires reduce the load carrying capacity of your vehicle. \
When weather temperature changes occur, tire inflation pressures also ch\
ange. A 10- degree temperature
drop causes a corresponding drop of 1 psi (7 kPa) in inflation pressur\
e. Check your tire pressures
frequently and adjust them to the proper pressure, which can be found on\
the vehicle's tire information
placard or certification label.
Checking tire pressure
A certain amount of air seepage from the tires occurs naturally and tire\
pressure fluctuates with seasonal
changes in temperature. Always check tire pressure regularly.
Cold tires
Inflation pressure should be checked when the tires are cold.
pg. 159 Wheels and tires
file:///K|/ownersdocs/2007/2007_XC70/07xc70_07.htm (5 of 24)12/30/2006\
5:51:40 PM

2007 Volvo XC70
wording of this message is determined by the degree of inflation pressur\
e loss.
NOTE: If a fault occurs in TPMS, the tire pressure warning light will flash f\
or approximately 1 minute
and TIRE PRESS SYST SERVICE REQUIRED will be displayed.
Each tire, including the spare (if provided), should be checked monthl\
y when cold and inflated to the
inflation pressure recommended by the vehicle manufacturer on the vehicl\
e placard or tire inflation
pressure label. (If your vehicle has tires of a different size than the\
size indicated on the vehicle placard
or tire inflation pressure label, you should determine the proper tire i\
nflation pressure for those tires.)
As an added safety feature, your vehicle has been equipped with a tire p\
ressure monitoring system
(TPMS) that illuminates a low tire pressure telltale when one or more \
of your tires is significantly under-
inflated. Accordingly, when the low tire pressure telltale illuminates, \
you should stop and check your
tires as soon as possible, and inflate them to the proper pressure. Driv\
ing on a significantly under-
inflated tire causes the tire to overheat and can lead to tire failure. \
Under-inflation also reduces fuel
efficiency and tire tread life, and may affect the vehicle's handling an\
d stopping ability.
Please note that the TPMS is not a substitute for proper tire maintenanc\
e, and it is the driver's
responsibility to maintain correct tire pressure, even if under-inflatio\
n has not reached the level to trigger
illumination of the TPMS low tire pressure telltale.
Your vehicle has also been equipped with a TPMS malfunction indicator to\
indicate when the system is
not operating properly. The TPMS malfunction indicator is combined with \
the low tire pressure telltale.
When the system detects a malfunction, the telltale will flash for appro\
ximately one minute and then
remain continuously illuminated. This sequence will continue upon subseq\
uent vehicle start-ups as long
as the malfunction exists. When the malfunction indicator is illuminated\
, the system may not be able to
detect or signal low tire pressure as intended. TPMS malfunctions may oc\
cur for a variety of reasons,
including the installation of replacement or alternate tires or wheels o\
n the vehicle that prevent the
TPMS from functioning properly. Always check the TPMS malfunction tellta\
le after replacing one or
more tires or wheels on your vehicle to ensure that the replacement or a\
lternate tires and wheels allow
the TPMS to continue to function properly.
NOTE:
l TPMS indicates low tire pressure but does not replace normal tire mainte\
nance. For information on
correct tire pressure, please refer to the tables on
pages 160 and 161, or consult your Volvo retailer.
Erasing warning messages
When a low tire pressure warning message has been displayed, and the tir\
e pressure warning light has
come on:
pg. 163 Wheels and tires
file:///K|/ownersdocs/2007/2007_XC70/07xc70_07.htm (9 of 24)12/30/2006\
5:51:40 PM

2007 Volvo XC70
ALL PASSENGER VEHICLE TIRES MUST CONFORM TO FEDERAL SAFETY
REQUIREMENTS IN ADDITION TO THESE GRADES
Quality grades can be found, where applicable, on the tire sidewall betw\
een the tread shoulder
and maximum section width. For example:
Treadwear 200 Traction AA Temperature A
TREADWEAR
The treadwear grade is a comparative rating based on the wear rate of th\
e tire when tested under
controlled conditions on a specified government test course. For example\
, a tire graded 150 would wear
one and one half (1 1/2) times as well on the government course as a t\
ire graded 100. The relative
performance of tires depends upon the actual conditions of their use, ho\
wever, and many depart
significantly from the norm due to variation in driving habits, maintena\
nce practices and differences in
road characteristics and climate.
TRACTION
The traction grades, from highest to lowest, are AA, A, B, and C, as mea\
sured under controlled
conditions on specified government test surfaces of asphalt and concrete\
. A tire marked C may have
poor traction performance.
WARNING!
The traction grade assigned to this tire is based on braking (straight-\
ahead) traction tests and is not a
measure of cornering (turning) traction.
TEMPERATURE
The temperature grades are AA (the highest), A, B, and C, representing\
the tire's resistance to the
generation of heat and its ability to dissipate heat when tested under c\
ontrolled conditions on a specified
indoor laboratory test wheel. Sustained high temperature can cause the m\
aterial of the tire to degenerate
and reduce tire life, and excessive temperature can lead to sudden tire \
failure. The grade C corresponds
to a minimum level of performance that all passenger vehicle tires must \
meet under the Federal Motor
Safety Standard No. 109. Grades B and A represent higher levels of perfo\
rmance on the laboratory test
wheel than the minimum required by law.
WARNING!
The temperature grade for this tire is established for a tire that is pr\
operly inflated and not overloaded.
Excessive speed, under-inflation, or excessive loading, either separatel\
y or in combination, can cause
heat buildup and tire failure.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_07.htm (16 of 24)12/30/200\
6 5:51:40 PM
