change language VOLVO XC90 TWIN ENGINE 2018 Owners Manual

OWNER'S INFORMATION
}}
17

CAUTION
The driver is always responsible for operatingthe vehicle in a safe manner and adhering toall applicable laws and regulations. It is alsoimportant that the vehicle is operated, main-tained and serviced according to Volvo's rec-ommendations provided in the owner's infor-mation.
If the information in the center display differsfrom the printed information, the printed infor-mation always takes precedence.

NOTE
Changing languages in the center displaycould mean that certain owner's informationwill not comply with national or local laws andregulations. Do not change to a language thatyou do not fully understand, as this couldmake it difficult to navigate back through themenu.

Related information
•Owner's Manual in the center display(p. 17)
•Owner's manual in mobile devices (p. 20)
•Volvo Cars support site (p. 20)
•Using the Owner's Manual (p. 21)
Owner's Manual in the centerdisplay
A digital version of the Owner's Manual is availa-
ble in the vehicle's center display2.The digital Owner's Manual can be accessedfrom Top view and in certain cases, the contex-tual Owner's Manual can also be accessed fromTop view.
NOTE
The digital Owner's Manual is not availableduring driving.

OWNER'S MANUAL
The Owner's Manual is accessed from Top view.
To open the Owner's Manual, pull down Top viewin the center display and tap Owner's manual.
The information in the Owner's Manual can beaccessed directly via the Owner's Manual startpage or via its Top menu.
Contextual Owner's Manual
The contextual Owner's Manual is accessed from Topview.
When a contextual Owner's Manual is available, itwill be shown to the right of Owner's manual inTop view.
Tap the contextual Owner's Manual to open anarticle in the Owner's Manual related to the infor-mation displayed on the screen. For example, tapNavigation Manual to open an article related tonavigation.
Certain apps in the vehicle only. For third-partyapps that have been downloaded, it is not possi-ble to e.g. access app-specific articles.
2Available in most markets.

DISPLAYS AND VOICE CONTROL
* Option/accessory.
86 Instrument panel settings
Display settings for the instrument panel can be
set in the instrument panel's app menu and in
the center display's Settings menu.
Settings in instrument panel's app
menu
The app menu can be used to set what informa-
tion will be displayed in the instrument panel:
• trip computer
• media player
• phone
• navigation system*.
Center display settings
Selecting type of information
1. Tap Settings in the center display's Top
view.
2.
Tap My Car Displays Driver Display
Information .
3.

Select a background:
• Show no information in the
background
• Show information for current playing
media
• Show navigation even if no route is
set.
Select theme
1.
Tap Settings in the center display's Top
view.
2.
Tap My Car Displays Display
Themes
3. Select a theme (appearance) for the instru- ment panel:
• Glass
• Minimalistic
• Performance
• Chrome Rings.
Select language
1.
Tap Settings in the center display's Top
view.
2.
Tap System System Languages and
Units System Language
to select lan-
guage.
> A change made here will affect the lan- guage in all displays.
The settings are personal and saved automati-
cally in the active driver profile.
Related information
• Instrument panel (p. 84)
• Handling the App menu in the instrument
panel (p. 104)
• Changing settings in the center display
(p. 134) Fuel gauge
The fuel gauge in the instrument panel shows
the fuel level in the tank. The beige area in the fuel gauge indicates the
amount of fuel left in the tank.
When the fuel level is low and it is time to refuel,
the fuel pump symbol will illuminate with an
amber-colored light. The trip computer also indi-
cates the approximate distance driven on the fuel
remaining in the tank.
Related information
•
Instrument panel (p. 84)
• Hybrid gauge (p. 88)
• Refueling (p. 463)
• Fuel tank volume (p. 664)

||DISPLAYS AND VOICE CONTROL
128 Row showing suggestions for words or char-
acters
9
. The suggested words change as
new letters are entered. Scroll through the
list of suggested words by tapping the right
or left arrows. Tap a suggestion to select it.
Please note that this function is not available
in all languages. When unavailable, this row
will not be shown on the keyboard. Available characters are adapted to the lan-
guage selected for the keyboard (see num-
ber 7 below). Tap a character to enter it.
Different buttons are displayed here depend-
ing on the context in which the keyboard is
used, e.g. @ to enter an email address or the
return key to start a new line. This button hides the keyboard. In cases
where this is not possible, the button will not
be displayed.
Used to enter uppercase letters. Tap once to
enter one uppercase letter and then con-
tinue with lowercase letters. Tap twice for
caps lock (all text will be entered in upper-
case letters). Tap again to return the key-
board to lowercase letters. In this mode, the
first letter after a period, exclamation point or
question mark will be automatically entered
in uppercase form. The first letter entered in
text fields will also be uppercase. In text
fields intended for names or addresses, each
word will be automatically started with an uppercase letter. In text fields intended for
passwords, website addresses or email
addresses, all letters will automatically be
lowercase unless uppercase is selected. Used to enter numbers. The number key-
board (2) will then be displayed. Tap
,
which is shown instead of in number
mode, to return to the keyboard with letters,
or to display the keyboard with special
characters. Used to change the keyboard language, e.g.
EN
. The available characters and word sug-
gestions (1) vary depending on the selected
language. In order to toggle between key-
board languages, the languages must first be
added under Settings. Space bar.
Delete. Tap to delete characters one at a
time. Press and hold to delete multiple char-
acters quickly.
Used to change to handwriting mode.
Tap the confirm button over the keyboard (not
shown in illustration) once to confirm the text that
has been entered. The button's appearance dif-
fers depending on the context.
Variants of letters or characters Variants of a letter or character, e.g. é or è, can
be entered by pressing and holding the letter or
character. A box containing possible variants of
the letter or character will appear. Tap the
desired variant. If no variant is selected, the origi-
nal letter/character will be used.
Related information
• Changing keyboard language in the center
display (p. 129)
• Entering characters, letters and words by
hand in the center display (p. 129)
• Handling the center display (p. 112)
• Handling text messages (p. 526) 9
For Asian languages.

DISPLAYS AND VOICE CONTROL
}}
129
Changing keyboard language in the
center display
In order to toggle between keyboard languages,
the languages must first be added under
Settings.
Adding or deleting languages in
Settings
The keyboard is automatically set to the same
language as the system language. The keyboard
language can be manually changed without
affecting the system language.
1. Tap Settings in Top view.
2.

Tap System System Languages and
Units Keyboard Layouts.
3.

Select one or more languages in the list.
> It is now possible to toggle between the selected languages using the keyboard.
If no language has been selected under
Settings, the keyboard will remain in the same language as the vehicle's system language.
Toggling between keyboard languagesIf more than one language has
been selected in Settings, the
button in the keyboard can be
used to switch between the dif-
ferent languages. To toggle between keyboard languages from the
list:
1.

Press and hold the button.
> A list will appear.
2. Select the desired language. If more than four languages have been selected under
Settings, you can scroll through the list
shown on the keyboard.
>

The keyboard and word suggestions will
be adapted to the selected language.
To change keyboard language without displaying
the list:
– Tap the button.
>

The keyboard layout will change to the
next language in the list without display-
ing the list.
Related information
• Changing system language (p. 132)
• Using the center display keyboard (p. 126) Entering characters, letters and
words by hand in the center display
Characters, letters and words can be entered in
the center display by handwriting them on the
touchscreen. Tap the button on the center
display's keyboard to switch
from the keyboard to handwrit-
ing mode. Space for entering characters/letters/
words/parts of words.
Text field displaying suggested characters or
words
10
as they are written on the screen
(1). Suggestions for characters/letters/words/
parts of words. You can scroll through the
list.

||DISPLAYS AND VOICE CONTROL
130 Space bar. Blank spaces can be created by
writing a dash (‒) in the field for handwritten
letters (1). See "Writing blank spaces in free-
text fields" below. Delete. Tap once to erase one character/
letter at a time. Wait a moment before tap-
ping again to erase the next character, letter
etc.
Return to the standard keyboard layout.
Switch off/on screen tap sounds.
Hide the keyboard. In cases where this is not
possible, the button will not be displayed.
Change language for text input.
Handwriting characters/letters/words
1. Write a character, a letter, a word or parts of
a word in the field for handwritten letters (1).
Write the word or part of the word vertically
or horizontally.
> A number of suggestions for characters,letters or words will be displayed (3). The
most likely will be shown at the top of the
list.
CAUTION Do not use sharp objects on the screen as
this could cause scratches.
2. The character/letter/word will be entered
automatically after a short pause if no other
action is taken.
>

The character/letter/word at the top of
the list will be used. Tap one of the other
characters/letters/words in the list to use
it instead.
Erasing/changing handwritten characters/
letters Erase text in the text field (2) by swiping over the hand-
writing field (1).
–
Characters/letters can be erased or changed
in several ways:
•Tap the desired letter or word in the list
(3).
• Tap the delete button (5) to erase the let-
ter and start again.
• Swipe horizontally from right to left 11
over
the handwriting field (1). Erase several let-
ters at once by swiping over the area sev-
eral times.
• Tap the X box in the text field (2) to erase
all written text. 10
Certain system languages only.
11 For Arabic keyboards, swipe in the other direction. Swiping from right t\
o left will create a blank space.

DISPLAYS AND VOICE CONTROL
132Changing system units of
measurement
Unit settings are adjusted in the Settings menu
in the center display.
1. Tap Settings in the Top view in the center
display.
2.

Proceed to System System Languages
and Units Units of Measurement.
3.

Select one of the following measurement
standards:
• Metric - kilometers, liters and degrees
Celsius.
• Imperial - miles, gallons and degrees
Celsius.
• US - miles, gallons and degrees Fahren-
heit.
>

The units in the instrument panel, center
display and head-up display are changed.
Related information
• Center display overview (p. 109)
• Opening settings in the center display
(p. 132)
• Changing settings in the center display
(p. 134)
• Changing system language (p. 132) Changing system language
Language settings are adjusted in the
Settings
menu in the center display.
NOTE Changing languages in the center display
could mean that certain owner's information
will not comply with national or local laws and
regulations. Do not change to a language that
you do not fully understand, as this could
make it difficult to navigate back through the
menu.
1.
Tap Settings in the Top view in the center
display.
2.

Proceed to System System Languages
and Units .
3. Select System Language. A voice control
symbol indicates that the language can be
used for voice commands.
>

Languages in the instrument panel, center
display and head-up display are changed.
Related information
• Center display overview (p. 109)
• Opening settings in the center display
(p. 132)
• Changing settings in the center display
(p. 134)
• Changing system units of measurement
(p. 132) Opening settings in the center
display
The center display is used to manage
Settings
and to display information for many of the vehi-
cle's functions. Top view with Settings button.
1. Open Top view by tapping the tab or by drag-
ging/swiping from the top of the screen
downward.
2. Tap Settings to open the Settings menu.
3.

Tap one of the categories shown and tap
again to navigate to sub-categories and their
respective settings.
4. Tap Back to move backward in the Settings
menu.
Tap Close to close the Settings menu.

DISPLAYS AND VOICE CONTROL
}}
135
Resetting center display settings
All settings made in the center display's Settings
menu can be reset to default values.
Two types of resetThere are two ways to reset the settings in the
Settings menu:
• Factory Reset- erases all data and files and
resets all settings to factory default.
• Reset Personal Settings- erases personal
data and resets personalized settings to fac-
tory default.
Resetting settingsFollow these instructions to reset the settings.
NOTE Factory Reset is only possible when the
vehicle is stationary. 1.
Tap Settings in the Top view in the center
display.
2.

Proceed to System Factory Reset
.
3. Select the type of reset you would like to do. > A pop-up window will appear. 4.
Tap OK to confirm the reset.
For Reset Personal Settings, confirm the reset by tapping
Reset for the active
profile or Reset for all profiles.
>
The selected settings will be reset.
Related information
• Center display overview (p. 109)
• Opening settings in the center display
(p. 132)
• Changing settings in the center display
(p. 134)
• Table of settings in the center display
(p. 136) Setting types in the center display
Different types of settings are changed in differ-
ent ways. Refer to the table below for a descrip-
tion of the different types of settings.
Types of settings Type of
setting
Description
Trigger
function Starts an app or a separate view
for more advanced settings. Tap
the text to e.g. connect a
Bluetooth
®
device.
Radio but-
ton Select one of the possible set-
tings by tapping the desired radio
button to e.g. change the system
language.
Multi-
selection
button Select a level for a particular set-
ting by pressing the desired part
of the button, e.g. to select sensi-
tivity level for City Safety.
Checkbox

Tap the checkbox to activate/
deactivate a function, e.g. to
select automatic start for heated
seats.

DISPLAYS AND VOICE CONTROL
}}
* Option/accessory. 137Sub-categories
Gracenote®
Video
Communication
Sub-categories
Phone
Text Messages
Android Auto
*
Apple CarPlay*
Bluetooth Devices
Wi-Fi
Vehicle Wi-Fi Hotspot
Vehicle Modem Internet
Volvo On Call
Volvo Service Networks
ClimateThe Climate main category does not have any sub-categories.
System Sub-categories
Driver Profile
Date and Time
System Languages and Units
Privacy and data
Keyboard Layouts
Voice Control
*
Factory Reset
System Information
Related information
• Center display overview (p. 109)
• Changing settings in the center display
(p. 134)
• Resetting center display settings (p. 135) Driver profiles
Many of the vehicle's settings can be custom-
ized to the driver's personal preferences and
saved in one or more driver profiles. These personal settings are automatically saved
in the active driver profile. Each key can be linked
to one driver profile. When the linked key is used,
the vehicle is customized to the specific settings
of that driver profile.
Which settings are saved in driver
profiles?
The vehicle has settings that can be made either
personal or global. The personal settings are
saved in driver profiles.
Settings that can be saved in a driver profile
include, among other things, screens, mirrors,
front seats, navigation*, audio and media system,
language and voice control.
Some settings are global settings. These settings
can be changed but are not saved to a specific
driver profile. Changes to global settings affect all
profiles.

||DISPLAYS AND VOICE CONTROL
138
Global settings
Global settings and parameters do not change
when driver profiles are changed. They remain
the same regardless of which driver profile is cur-
rently active.
Keyboard layout is an example of a global setting.
If driver profile X is used to add additional key-
board languages, these languages will also be
available for driver profile Y. The settings for key-
board layout are not saved to a specific driver
profile - the settings are global.
Personal settings
If driver profile X has been used to e.g., set the
brightness for the center display, driver profile Y
will not be affected by this setting. It will only be
saved to driver profile X because brightness set-
ting is a personal setting.
Related information
•
Selecting a driver profile (p. 138)
• Changing a driver profile's name (p. 139)
• Resetting driver profile settings (p. 139)
• Linking a remote key to a driver profile
(p. 139)
• Table of settings in the center display
(p. 136) Selecting a driver profile
When the center display starts up, the selected
driver profile will be shown at the top of the
screen. The most recently used driver profile will
be active the next time the vehicle is unlocked. A
different driver profile can be selected once the
vehicle has been unlocked. However, if the
remote key has been linked to a driver profile,
this profile will be used instead.
There are two options for switching between
driver profiles.
Option 1:
1.

Tap the name of the driver profile shown at
the top of the center display when the dis-
play starts up.
> A list will appear, showing driver profiles that can be selected.
2. Select desired driver profile.
3. Tap Confirm.
>

The driver profile has now been selected
and the system will load the settings
stored in that profile.
Option 2:
1. Pull down Top view in the center display.
2. Tap Profile.
>

The same list as in option 1 will be dis-
played.
3. Select desired driver profile. 4.
Tap Confirm.
>

The driver profile has now been selected
and the system will load the settings
stored in that profile.
Related information
• Driver profiles (p. 137)
• Navigating in the center display's views
(p. 115)
• Changing a driver profile's name (p. 139)
• Linking a remote key to a driver profile
(p. 139)

DISPLAYS AND VOICE CONTROL
* Option/accessory.
148 Voice control for radio and media
18
Voice commands for the radio and media play-
ers are shown below. Tap and say one of the following commands:
• "Media" - initiates a dialog for media and
radio and displays examples of commands.
• "
Play [artist]" - plays music by the selected
artist.
• "
Play [song title]" - plays the selected
song.
• "
Play [song title] from [album]" - plays
the selected song from the selected album.
• "
Play [radio station]" - starts the selected
radio station.
• "
Tune to [frequency]" - tunes to the
selected radio frequency in the currently
active waveband. If no radio source is active,
the FM band will be started as default.
• "Tune to [frequency] [waveband]" - tunes
to the selected radio frequency on the
selected waveband.
• "
Radio" - starts FM radio.
• "
Radio FM" - starts FM radio.
• "SiriusXM" - starts SiriusXM radio*
• "
CD" - starts playback from CD*.
• "USB" - starts playback from USB. •
"
iPod" - starts playback from iPod.
• "
Bluetooth" - starts playback from a Blue-
tooth-connected media source.
• "
Similar music" - plays music from a USB-
connected device with music similar to that
currently playing.
Related information
• Voice control (p. 145)
• Using voice commands (p. 146)
• Voice control for cellular phones (p. 147)
• Climate control system voice commands
(p. 203)
• Voice control settings (p. 148) Voice control settings
19
Settings for the voice control system are made
here.
Settings System Voice Control
Settings can be personalized in the following
areas:
• Repeat Voice Command
• Gender
• Speech Rate
Sound settingsSelect sound settings under:
Settings Sound System Volumes
Voice Control
Language settingsThe voice control system is not available for all
languages. The languages available for voice
commands are indicated by the
icon in the
list of languages.
Changing the language here will also change the
language in the menus, messages and help texts.
Settings System System Languages
and Units System Language
18
Certain markets only.
19 Certain markets only.
