||MAINTENANCE AND SERVICE
* Option/accessory.
628 Function
AA Door module in right-side rear door 20
Fuses in the trunk/cargo compart-
ment
10Control module for Internet-con-
nected vehicle; Control module for
Volvo On Call
5Door module in left-side rear door 20
Audio control module (amplifier)
(certain models only)
40Climate system blower module
(rear)*
40Multi-band antenna module 5
Front seat massage function*
5–
–Rear window wiper
15Fuel pump control module
15Relay windings for distribution box
in engine compartment; Relay
windings for transmission oil pump
5–
– Function
AA Driver's seat heating
15 Front passenger's seat heating 15
Coolant pump
10 –
– Door module in left-side front door 20
Active chassis control module*
20 –
– Sensus control module
10 –
– –
– Door module in right-side front
door
20 Display for rear seat convenience
functions
C
; On-board diagnostics
(OBD II) in tunnel console between
rear seats C
; Extra movement sen-
sor C 5
C Function
AA TV* (certain markets only)
5 Primary fuse for fuses 53 and 58 15
A
Ampere
B Not Excellence
C Excellence
Related information
• Fuses and fuseboxes (p. 620)
• Replacing fuses (p. 621)

MAINTENANCE AND SERVICE
}}
* Option/accessory. 631
Positions
•Fuses 13-17 and 21-36 are "Micro" fuses.
• Fuses 1-12, 18-20 and 37 are "MCase"
fuses and should only be replaced by a work-
shop 19
. Function
AA Heated rear window
30Power rear seat
B
20B Pneumatic suspension* compres-
sor 40Rear electric heater (right-hand
side)
30Electrical outlets in the tunnel
console between the rear seats
B30
B Rear electric heater (left-hand
side)
30Power rear seat (right-hand side)
B
20B Control module for reduction of
nitrous oxides (diesel)
30Power tailgate*
25Power front passenger seat*
20 Function
AA Towbar* control module
40 Seat belt tensioner module (right
side)
40 Internal relay windings
5 Control module for reduction of
nitrous oxides (diesel)
15 Foot movement detection module
for opening the power tailgate*
5 USB hub/accessory port
– Module for electrically folding
third-row seats*
20 Towbar* control module
25 Power driver seat*
20 Seat belt tensioner module (left
side)
40 Park Assist Camera*
5 –
– –
– –
– Function
AA Feed when ignition is on
10 Control module for airbags and
seat belt tensioners
5 Cooler
B
; Heated/cooled cup
holder (rear) B 10
B Heated rear seat (left side)*
15 –
– Blind Spot Information (BLIS)*;
Exterior reverse signal control
module 5 –
– Modules for seat belt tensioners 5
Emissions system actuator (gaso-
line, certain engine variants)
5 –
– –
– Heated rear seat (right side)*
15 –
– A
Ampere
B Excellence 19
