SPECIFICATIONS
8-1
8
Dimensions:Overall length:1876 mm (73.9 in)
Overall width:
706 mm (27.8 in)
Overall height: 1154 mm (45.4 in)
Seat height: 817 mm (32.2 in)
Wheelbase:
1274 mm (50.2 in)
Ground clearance: 118 mm (4.65 in)
Minimum turning radius: 2000 mm (78.7 in)Weight:Curb weight:97 kg (214 lb)Engine:Engine type:
Liquid cooled 4-stroke, SOHC
Cylinder arrangement: Single cylinder
Displacement: 49 cm³
Bore × stroke:
38.0 × 43.5 mm (1.50 × 1.71 in)
Compression ratio: 12.00 : 1
Starting system: Electric starter and kickstarter
Lubrication system:
Wet sump
Engine oil:Type:SAE 10W-30, 10W-40, 20W-40 or 20W-50
Recommended engine oil grade: API service SG type or higher, JASO
standard MA
Engine oil quantity:
Periodic oil change:0.78 L (0.82 US qt, 0.69 Imp.qt)Final transmission oil:Type:SAE 10W-30 type SE motor oil
Quantity: 0.10 L (0.11 US qt, 0.09 Imp.qt)Cooling system:Coolant reservoir capacity (up to the
maximum level mark):
0.26 L (0.27 US qt, 0.23 Imp.qt)
Radiator capacity (including all routes): 0.52 L (0.55 US qt, 0.46 Imp.qt)
Air filter:Air filter element:Oil-coated paper elementFuel:Recommended fuel:Premium unleaded gasoline (Gasohol (E10)
acceptable)
Fuel tank capacity: 6.0 L (1.59 US gal, 1.32 Imp.gal)
Fuel reserve amount: 1.0 L (0.26 US gal, 0.22 Imp.gal)Fuel injection:Throttle body:ID mark:
3B31 00Spark plug(s):Manufacturer/model: NGK/CR7E
Spark plug gap:
0.7–0.8 mm (0.028–0.031 in)Clutch:Clutch type:Dry, centrifugal automaticTransmission:Primary reduction ratio:1
Final drive: Gear
Secondary reduction ratio:
52/13 × 44/12 (14.666)
Transmission type: V-belt automatic
Operation: Centrifugal automatic type
–20 –10 0 1020 30 40 50 C
10 30 50 70 90 110
0 130 F
SAE 20W-50SAE 20W-40
SAE 10W-40
SAE 10W-30
U1GBE0E0.book Page 1 Monday, July 15, 2013 11:45 AM
Page 72 of 78
SPECIFICATIONS
8-2
8
Chassis:Frame type:
Underbone
Caster angle:
27.00 °
Trail:
172 mm (6.8 in)Front tire:Type:
Tubeless
Size:
120/70-13 53P(Michelin)
53L(SAVA,Metzeler)
Manufacturer/model:
MICHELIN/POWER PURE SC
Manufacturer/model:
SAVA/ MC 16
Manufacturer/model:
METZELER/ ME 7 TEENRear tire:Type:
Tubeless
Size:
130/60-13 53P(Michelin)
53L(SAVA,Metzeler)
Manufacturer/model:
MICHELIN/POWER PURE SC
Manufacturer/model:
SAVA/ MC 16
Manufacturer/model:
METZELER/ ME 7 TEENLoading:Maximum load:
182 kg (401 lb)(Total weight of rider, passenger, cargo
and accessories)
Tire air pressure (measured on cold
tires):Loading condition:
0–90 kg (0–198 lb)
Front:
150 kPa (1.50 kgf/cm², 22 psi)
Rear:
150 kPa (1.50 kgf/cm², 22 psi)
Loading condition:
90–182 kg (198–401 lb)
Front:
160 kPa (1.60 kgf/cm², 23 psi)
Rear:
170 kPa (1.70 kgf/cm², 25 psi)Front wheel:Wheel type:
Cast wheel
Rim size:
13xMT3.00Rear wheel:Wheel type:
Cast wheel
Rim size:
13xMT3.50Front brake:Type:
Single disc brake
Operation:
Right hand operation
Specified brake fluid:
DOT 4
Rear brake:Type:
Single disc brake
Operation:
Left hand operation
Specified brake fluid:
DOT 4Front suspension:Type:
Telescopic fork
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel:
80.0 mm (3.15 in)Rear suspension:Type:
Unit swing
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel:
70.0 mm (2.76 in)Electrical system:Ignition system:
TCI
Charging system:
AC magnetoBattery:Model:
CB5L-B(GS)
Voltage, capacity:
12 V, 5.0 AhHeadlight:Bulb type:
Halogen bulb
U1GBE0E0.book Page 2 Wednesday, June 26, 2013 4:04 PM
Page 73 of 78
SPECIFICATIONS
8-3
8
Bulb voltage, wattage × quantity:Headlight:
12 V, 35.0 W/35.0 W × 1
Tail/brake light:
12 V, 5.0 W/21.0 W × 1
Front turn signal light:
12 V, 10.0 W × 2
Rear turn signal light:
12 V, 10.0 W × 2
Auxiliary light:
12 V, 5.0 W × 1 (CHE)
License plate light:
12 V, 5.0 W × 1 (GBR, CYP, IRL, CHE)
Meter lighting:
LED
High beam indicator light:
LED
Turn signal indicator light:
LED
Fuel level warning light:
LED
Coolant temperature warning light:
LED
Engine trouble warning light:
LEDFuses:Main fuse:
15.0 A
U1GBE0E0.book Page 3 Wednesday, June 26, 2013 4:04 PM
Page 74 of 78
CONSUMER INFORMATION
9-1
9
EAU48613
Identification numbersRecord the vehicle identification num-
ber and model label information in the
spaces provided below for assistance
when ordering spare parts from a
Yamaha dealer or for reference in case
the vehicle is stolen.
VEHICLE IDENTIFICATION NUMBER:
MODEL LABEL INFORMATION:
EAU26411
Vehicle identification number
The vehicle identification number is
stamped into the frame.TIPThe vehicle identification number is
used to identify your vehicle and may
be used to register it with the licensing
authority in your area.
EAUM2811
Model label
The model label is affixed to the bot-
tom of the passenger seat. (See page
3-11.) Record the information on this
label in the space provided. This infor-
mation will be needed when ordering
spare parts from a Yamaha dealer.
1. Vehicle identification number1ZAUM0287
1. Model labelZAUM1077
1
U1GBE0E0.book Page 1 Wednesday, June 26, 2013 4:04 PM
Page 75 of 78
INDEX
AAcceleration and deceleration ................ 5-2
Air filter element and check hose,
replacing and cleaning ....................... 6-13
Auxiliary light bulb, replacing ............... 6-28BBattery .................................................. 6-23
Brake fluid, changing............................ 6-20
Brake fluid level, checking.................... 6-18
Brake lever, front .................................... 3-7
Brake lever, rear ..................................... 3-7
Brake levers, lubricating ....................... 6-21
Braking ................................................... 5-3CCables, checking and lubricating ......... 6-20
Care ........................................................ 7-1
Catalytic converter ............................... 3-10
Centerstand, checking and
lubricating........................................... 6-21
Coolant ................................................. 6-12
Coolant temperature warning light ......... 3-2
Cowling and panel, removing and
installing ............................................... 6-6DDimmer switch........................................ 3-7EEngine break-in ...................................... 5-4
Engine oil ................................................ 6-9
Engine trouble warning light ................... 3-3FFinal transmission oil ............................ 6-11
Front and rear brake lever free play,
checking ............................................. 6-17
Front and rear brake pads, checking ... 6-18Front fork, checking ............................. 6-22
Fuel ........................................................ 3-8
Fuel consumption, tips for reducing ...... 5-3
Fuel level warning light........................... 3-2
Fuel tank cap.......................................... 3-8
Fuse, replacing..................................... 6-25
HHandlebar switches ............................... 3-6
Headlight bulb, replacing ..................... 6-26
High beam indicator light ....................... 3-2
Horn switch ............................................ 3-7IIdentification numbers ........................... 9-1
Indicator lights and warning lights ......... 3-2KKickstarter ............................................ 3-10LLicense plate light ................................ 6-28MMain switch/steering lock ...................... 3-1
Maintenance and lubrication, periodic... 6-3
Maintenance, emission control
system ................................................. 6-2
Matte color, caution ............................... 7-1
Model label............................................. 9-1
Multi-function display............................. 3-3PParking ................................................... 5-4
Part locations ......................................... 2-1SSafe-riding points................................... 1-5
Safety information .................................. 1-1
Seats .................................................... 3-11
Spark plug, checking ............................. 6-7Specifications ......................................... 8-1
Starting a cold engine............................. 5-1
Starting off .............................................. 5-2
Start switch ............................................. 3-7
Steering, checking ................................ 6-23
Storage ................................................... 7-4
Storage compartment........................... 3-12
TTail/brake light bulb, replacing ............. 6-27
Throttle grip and cable, checking and
lubricating ........................................... 6-20
Throttle grip free play, checking ........... 6-14
Tires ...................................................... 6-15
Troubleshooting .................................... 6-29
Troubleshooting charts ......................... 6-30
Turn signal indicator light ....................... 3-2
Turn signal light bulb, replacing............ 6-27
Turn signal switch ................................... 3-7VValve clearance..................................... 6-14
Vehicle identification number ................. 9-1WWheel bearings, checking .................... 6-23
Wheels .................................................. 6-17
