PERIODIC MAINTENANCE AND
ADJUSTMENT .........................................8-1
Owner’s manual and tool kit .................8-3
Periodic maintenance/Lubrication ........8-7
Engine oil ............................................8-13
Transmission oil .................................8-21
Spark plug inspection .........................8-27
Engine and V-belt compartment
air filter element cleaning .................8-31
Idle speed adjustment ........................8-41
Valve clearance adjustment ...............8-43
Throttle lever adjustment ....................8-43
Front and rear brake shoe
inspection .........................................8-45
Front brake lever free play
adjustment ........................................8-47
Rear brake adjustment .......................8-55
Drive chain slack check ......................8-57
Drive chain slack adjustment ..............8-59Lubricating and drive chain ................8-63
Draining the V-belt compartment ........8-65
Cable inspection and lubrication ........8-67
Brake lever lubrication ........................8-69
Knuckle shaft, lower arms and
steering shaft lubrication ..................8-69
Wheel removal ...................................8-71
Wheel installation ...............................8-71
Battery ................................................8-73
Replenishing the battery fluid .............8-77
Fuse replacement ...............................8-81
Replacing the headlight bulb ..............8-83
Tail/brake light bulb replacement .......8-87
Headlight beam adjustment ................8-89
Troubleshooting ..................................8-91
Troubleshooting chart .........................8-958
5VJ-9-61-01 3/14/03 11:48 PM Page 14

6-29
8Accessories should be rigidly and securely
mounted. An accessory which can shift posi-
tion or come off while you are riding could
affect your ability to control the ATV.
8Do not mount an accessory where it could
interfere with your ability to control the ATV.
Examples include (but are not limited to) a
heavy or bulky object attached to the handle-
bars which could make steering difficult, an
accessory that limits your ability to move
around on the seat, or one that limits your
view.
8Use extra caution when riding an ATV with
accessories. The ATV may handle differently
than it does without accessories.
5VJ-9-61-06 3/17/03 4:51 PM Page 30

7-61
CROSSING A SLOPE
Traversing a sloping surface on your ATV
requires you to properly position your weight to
maintain proper balance. Be sure that you have
learned the basic riding skills on flat ground
before attempting to cross a sloping surface.
Avoid slopes with slippery surfaces or rough ter-
rain that may upset your balance.
As you travel across a slope, lean your body in
the uphill direction. It may be necessary to cor-
rect the steering when riding on loose surfaces
by pointing the front wheels slightly uphill. When
riding on slopes be sure not to make sharp turns
either up or down hill.
5VJ-9-61-07 3/14/03 11:53 PM Page 62

7-71
SLIDING AND SKIDDING
Care should be used when riding on loose or
slippery surfaces since the ATV may slide. If
unexpected and uncorrected, sliding could lead
to an accident. To reduce the tendency for the
front wheels to slide in loose or slippery condi-
tions, positioning your weight over the front
wheels will sometimes help.
If the rear wheels of your ATV start to slide side-
ways, control can usually be regained (if there is
room to do so) by steering in the direction of the
slide. Applying the brakes or accelerating is not
recommended until you have corrected the
slide.
5VJ-9-61-07 3/14/03 11:53 PM Page 72

8-8 * It is recommended that these items be serviced by a Yamaha dealer.
** Lithium-soap-based grease.
INITIAL EVERY
ITEM ROUTINE
13661
monthmonths months monthsyear
Brakes*• Check operation.
11111
• Adjust if necessary.
V-belt*• Check operation.
11
• Replace if damage or excessive wear.
Wheels*• Check balance/damage/runout.
1111
• Replace if necessary.
Wheel bearings*• Check bearing assembly for looseness/damage.
1111
• Replace if damaged.
• Check operation.
Steering system*• Replace if damaged.
11111
• Check toe-in.
• Adjust if necessary.
Knuckle shafts/
• Lubricate every 6 months.**111
steering shaft*
Fittings and fasteners*• Check all chassis fittings and fasteners.
11111
• Correct if necessary.
• Check specific gravity.
Battery*• Check breather hose for correct routing.11111
• Correct if necessary.
5VJ-9-61-08 3/17/03 4:52 PM Page 8-9

1. Grease nipple (×6)1. Graisseur (×6)1. Boquilla de engrase (×6)
8-69
EBU00725
Brake lever lubrication
Lubricate the pivoting parts of the brake levers.
EBU00728
Knuckle shaft, lower arms and steering shaft
lubrication
Lubricate the pivot points using a grease gun.11
1
1
Recommended lubricant:
Lithium-soap-based grease
(all-purpose grease)
Recommended lubricant:
Lithium-soap-based grease
5VJ-9-61-08 3/17/03 4:52 PM Page 8-70
