YAMAHA CYGNUS 125 2012 Owner's Manual
Manufacturer: YAMAHA, Model Year: 2012, Model line: CYGNUS 125, Model: YAMAHA CYGNUS 125 2012Pages: 80, PDF Size: 0.97 MB
Page 21 of 80
1
2
3
4
5
6
7
8
9
3-5
EAU1044E
INSTRUMENT AND CONTROL FUNCTIONS
interval will be at every 3000 km
(1800 mi) thereafter.
●
If the oil change tripmeter in-
dicates “-----”, have a Yamaha
dealer check the multi-function
display, as it may be faulty.
Clock
To set the clock:
1. Push the “SELECT” button and
“RESET” button together for at
least two seconds.
2. When the hour digits start flash-
ing, push the “SELECT” button to
set the hours.
3. Push the “RESET” button, and
the first minute digit will start
fl ashing.
4. Push the “SELECT” button to set
the fi rst minute digit.
5. Push the “RESET” button and
the second minute digit will start
fl ashing.
6. Push the “SELECT” button to set
the second minute digit.
7. Push the “RESET” button and
then release it to start the clock.Fuel meter
The fuel meter indicates the amount
of fuel in the fuel tank. The display
segments of the fuel meter disappear
towards “E” (Empty) as the fuel level
decreases. When “
” starts flashing,
refuel as soon as possible. When the
key is turned to “ON”, all of the display
segments of the fuel meter will appear
for a few seconds, and then shown
actual fuel level.
EAU12349
Handlebar switchesLeftZAUM00**
3 1
2
1. Dimmer switch “%/&”
2. Turn signal switch “4/6”
3. Horn switch “*”RightZAUM00**
1
1. Start switch “,”
4P9-F8199-E5_CS.indd 3-54P9-F8199-E5_CS.indd 3-5
2011/09/06 14:18:392011/09/06 14:18:39
Process BlackProcess Black
Page 22 of 80
1
2
3
4
5
6
7
8
9
3-6
EAU1044E
INSTRUMENT AND CONTROL FUNCTIONS
EAU12400
Dimmer switch “&/%”
Set this switch to “&” for the high
beam and to “%” for the low beam.
EAU12460
Turn signal switch “4/6”
To signal a right-hand turn, push this
switch to “6”. To signal a left-hand
turn, push this switch to “4”. When
released, the switch returns to the
center position. To cancel the turn
signal lights, push the switch in after it
has returned to the center position.
EAU12500
Horn switch “*”
Press this switch to sound the horn.
EAU12721
Start switch “,”
With the sidestand up, push this
switch while applying the front or rear
brake to crank the engine with the
starter. See page 5-1 for starting in-
structions prior to starting the engine.
EAU12900
Front brake leverZAUM00**
1
1. Front brake leverThe front brake lever is located on
the right handlebar grip. To apply the
front brake, pull this lever toward the
handlebar grip.
EAU12950
Rear brake leverZAUM00**
1
1. Rear brake leverThe rear brake lever is located on the
left handlebar grip. To apply the rear
brake, pull this lever toward the han-
dlebar grip.
4P9-F8199-E5_CS.indd 3-64P9-F8199-E5_CS.indd 3-6
2011/09/06 14:18:392011/09/06 14:18:39
Process BlackProcess Black
Page 23 of 80
1
2
3
4
5
6
7
8
9
3-7
EAU1044E
INSTRUMENT AND CONTROL FUNCTIONS
EAU13074
Fuel tank capTo open the fuel tank cap
Open the fuel tank cap lock cover,
insert the key into the lock, and then
turn it 1/4 turn clockwise. The lock will
be released and the fuel tank cap can
be opened.ZAUM00**
1
1. Fuel tank cap lock coverTo close the fuel tank cap
1. Push the fuel tank cap into posi-
tion with the key inserted in the
lock.
2. Turn the key counterclockwise to
the original position, remove it,
and then close the lock cover.
TIPThe fuel tank cap cannot be closed
unless the key is in the lock. In addi-
tion, the key cannot be removed if the
cap is not properly closed and locked.
EWA11091
WARNING
Make sure that the fuel tank cap
is properly closed after lling fuel.
Leaking fuel is a re hazard.
EAU13221
FuelZAUM00**
1
2
1. Fuel tank fi ller tube
2. Fuel levelMake sure there is suffi cient gasoline
in the tank.
EWA10881
WARNING
Gasoline and gasoline vapors are
extremely ammable. To avoid res
and explosions and to reduce the
risk of injury when refueling, follow
these instructions.
1. Before refueling, turn off the en-
gine and be sure that no one is
sitting on the vehicle. Never re-
fuel while smoking, or while in the
4P9-F8199-E5_CS.indd 3-74P9-F8199-E5_CS.indd 3-7
2011/09/06 14:18:392011/09/06 14:18:39
Process BlackProcess Black
Page 24 of 80
1
2
3
4
5
6
7
8
9
3-8
EAU1044E
INSTRUMENT AND CONTROL FUNCTIONS
vicinity of sparks, open fl ames, or
other sources of ignition such as
the pilot lights of water heaters
and clothes dryers.
2. Do not overfi ll the fuel tank. When
refueling, be sure to insert the
pump nozzle into the fuel tank fi ll-
er hole. Stop fi lling when the fuel
reaches the bottom of the filler
tube. Because fuel expands when
it heats up, heat from the engine
or the sun can cause fuel to spill
out of the fuel tank.
3. Wipe up any spilled fuel im-
mediately.
NOTICE:
Immedi-
ately wipe off spilled fuel with a
clean, dry, soft cloth, since fuel
may deteriorate painted sur-
faces or plastic parts.[ECA10071]
4. Be sure to securely close the fuel
tank cap.
EWA15151
WARNING
Gasoline is poisonous and can
cause injury or death. Handle
gasoline with care. Never siphon
gasoline by mouth. If you should
swallow some gasoline or inhale a
lot of gasoline vapor, or get some
gasoline in your eyes, see your
doctor immediately. If gasoline
spills on your skin, wash with soap
and water. If gasoline spills on your
clothing, change your clothes.
EAU33520
Recommended fuel:
REGULAR UNLEADED GASO-
LINE ONLY
Fuel tank capacity:
7.4 L (1.96 US gal) (1.63 Imp.gal)
ECA11400
NOTICEUse only unleaded gasoline. The
use of leaded gasoline will cause
severe damage to internal engine
parts, such as the valves and pis-
ton rings, as well as to the exhaust
system.
Your Yamaha engine has been de-
signed to use regular unleaded gaso-
line with a research octane number of
91 or higher. If knocking (or pinging)
occurs, use a gasoline of a different
brand or premium unleaded fuel. Use of unleaded fuel will extend spark plug
life and reduce maintenance costs.
4P9-F8199-E5_CS.indd 3-84P9-F8199-E5_CS.indd 3-8
2011/09/06 14:18:392011/09/06 14:18:39
Process BlackProcess Black
Page 25 of 80
1
2
3
4
5
6
7
8
9
3-9
EAU1044E
INSTRUMENT AND CONTROL FUNCTIONS
EAU13445
Catalytic convertersThis vehicle is equipped with catalytic
converters in the exhaust system.
EWA10862
WARNING
The exhaust system is hot after op-
eration. To prevent a re hazard or
burns:● Do not park the vehicle near
possible fire hazards such as
grass or other materials that
easily burn.● Park the vehicle in a place
where pedestrians or children
are not likely to touch the hot
exhaust system.● Make sure that the exhaust
system has cooled down be-
fore doing any maintenance
work.● Do not allow the engine to idle
more than a few minutes. Long
idling can cause a build-up of
heat.
ECA10701
NOTICEUse only unleaded gasoline. The
use of leaded gasoline will cause
unrepairable damage to the cata-
lytic converter.
EAU13680
KickstarterZAUM00**
1
1. Kickstarter To start the engine, fold out the kick-
starter lever, move it down lightly with
your foot until the gears engage, and
then push it down smoothly but force-
fully.
4P9-F8199-E5_CS.indd 3-94P9-F8199-E5_CS.indd 3-9
2011/09/06 14:18:402011/09/06 14:18:40
Process BlackProcess Black
Page 26 of 80
1
2
3
4
5
6
7
8
9
3-10
EAU1044E
INSTRUMENT AND CONTROL FUNCTIONS
EAUT1503
SeatTo open the seat
1. Place the scooter on the center-
stand.
2. Insert the key into the main
switch, and then turn it coun-
terclockwise to the first “OPEN”
position. If the main switch is in
the “LOCK” position, turn the key
counterclockwise to the second
“OPEN” position.ZAUM00**TIPDo not push inward when turning the
key from “OFF” to “OPEN” or from
“LOCK” to “OPEN”.
3. Fold the seat up.
To close the seat
1. Fold the seat down, and then
push it down to lock it in place.
2. Remove the key from the main
switch if the scooter will be left
unattended.TIPMake sure that the seat is properly se-
cured before riding.
EAUT1713
Storage compartmentsFront storage compartmentZAUM00**
1
1. Front storage compartment
EWA11191
WARNING
● Do not exceed the load limit of
1.5 kg (3.3 lb) for the front stor-
age compartment.● Do not exceed the maximum
load of 157 kg (346 lb) for the
vehicle.
4P9-F8199-E5_CS.indd 3-104P9-F8199-E5_CS.indd 3-10
2011/09/06 14:18:402011/09/06 14:18:40
Process BlackProcess Black
Page 27 of 80
1
2
3
4
5
6
7
8
9
3-11
EAU1044E
INSTRUMENT AND CONTROL FUNCTIONS
Rear storage compartmentZAUM00**
1
1. Rear storage compartmentThe rear storage compartment is
located under the seat. (See page
3-10.)
ECAT1031
NOTICEKeep the following points in mind
when using the rear storage com-
partment.● Since the rear storage com-
partment accumulates heat
when exposed to the sun and/
or the engine heat, do not store
anything susceptible to heat,
consumables or flammable
items inside it.
● To avoid humidity from spread-
ing through the rear storage
compartment, wrap wet articles
in a plastic bag before storing
them in the compartment.● Since the rear storage com-
partment may get wet while the
scooter is being washed, wrap
any articles stored in the rear
compartment in a plastic bag.● Do not keep anything valuable
or breakable in the rear storage
compartment.
EWAT1051
WARNING
● Do not exceed the load limit of
5 kg (11 lb) for the rear storage
compartment.● Do not exceed the maximum
load of 157 kg (346 lb) for the
vehicle.
EAU15305
SidestandZAUM00**
1
1. SidestandThe sidestand is located on the left
side of the frame. Raise the sidestand
or lower it with your foot while holding
the vehicle upright.TIPThe built-in sidestand switch is part
of the ignition circuit cut-off system,
which cuts the ignition in certain situa-
tions. (See the following section for an
explanation of the ignition circuit cut-
off system.)
4P9-F8199-E5_CS.indd 3-114P9-F8199-E5_CS.indd 3-11
2011/09/06 14:18:402011/09/06 14:18:40
Process BlackProcess Black
Page 28 of 80
1
2
3
4
5
6
7
8
9
3-12
EAU1044E
INSTRUMENT AND CONTROL FUNCTIONS
EWA10241
WARNING
The vehicle must not be ridden with
the sidestand down, or if the sid-
estand cannot be properly moved
up (or does not stay up), otherwise
the sidestand could contact the
ground and distract the operator,
resulting in a possible loss of con-
trol. Yamaha’s ignition circuit cut-
off system has been designed to
assist the operator in fulfilling the
responsibility of raising the sides-
tand before starting off. Therefore,
check this system regularly and
have a Yamaha dealer repair it if it
does not function properly.
EAUT1095
Ignition circuit cut-off systemCheck the operation of the sidestand
switch according to the following pro-
cedure.Turn the key on.
Put the sidestand up.Push the start switch while applying
either of the brake levers. The engine will
start.Put the sidestand down.
If the engine stalls:
The sidestand switch is OK.
WARNING
● The vehicle must be placed on
the centerstand during this in-
spection.● If a malfunction is noted, have
a Yamaha dealer check the
system before riding.
4P9-F8199-E5_CS.indd 3-124P9-F8199-E5_CS.indd 3-12
2011/09/06 14:18:402011/09/06 14:18:40
Process BlackProcess Black
Page 29 of 80
1
2
3
4
5
6
7
8
9
4-1
EAU15582
FOR YOUR SAFETY - PRE-OPERATION CHECKS
EAU15582
FOR YOUR SAFETY - PRE-OPERATION CHECKS
EAU15596
Inspect your vehicle each time you use it to make sure the vehicle is in safe operating condition. Always follow the in-
spection and maintenance procedures and schedules described in the Owner’s Manual.
EWA11151
WARNING
Failure to inspect or maintain the vehicle properly increases the possibility of an accident or equipment dam-
age. Do not operate the vehicle if you nd any problem. If a problem cannot be corrected by the procedures pro-
vided in this manual, have the vehicle inspected by a Yamaha dealer.
4P9-F8199-E5_CS.indd 4-14P9-F8199-E5_CS.indd 4-1
2011/09/06 14:18:402011/09/06 14:18:40
Process BlackProcess Black
Page 30 of 80
1
2
3
4
5
6
7
8
9
4-2
EAU15582
FOR YOUR SAFETY - PRE-OPERATION CHECKSBefore using this vehicle, check the following points:
ITEM CHECKS PAGE
Fuel• Check fuel level in fuel tank.
• Refuel if necessary.
• Check fuel line for leakage.3-7
Engine oil• Check oil level in engine.
• If necessary, add recommended oil to specifi ed level.
• Check vehicle for oil leakage.6-10
Final transmission oil• Check vehicle for oil leakage. 6-12
Front brake• Check operation.
• If soft or spongy, have Yamaha dealer bleed hydraulic system.
• Check brake pads for wear.
• Replace if necessary.
• Check fl uid level in reservoir.
• If necessary, add recommended brake fl uid to specifi ed level.
• Check hydraulic system for leakage.6-18~6-20
Rear brake• Check operation.
• Lubricate cable if necessary.
• Check lever free play.
• Adjust if necessary.6-18, 6-19
Throttle grip• Make sure that operation is smooth.
• Check throttle grip free play.
• If necessary, have Yamaha dealer adjust throttle grip free play and lubricate
cable and grip housing.6-15, 6-21
Wheels and tires• Check for damage.
• Check tire condition and tread depth.
• Check air pressure.
• Correct if necessary.6-16, 6-17
Brake levers• Make sure that operation is smooth.
• Lubricate lever pivoting points if necessary.6-21
4P9-F8199-E5_CS.indd 4-24P9-F8199-E5_CS.indd 4-2
2011/09/06 14:18:402011/09/06 14:18:40
Process BlackProcess Black
