low beam YAMAHA GRIZZLY 125 2005 Owners Manual

PERIODIC MAINTENANCE AND
ADJUSTMENT .........................................8-1
Owner’s manual and tool kit .................8-3
Periodic maintenance/Lubrication ........8-7
Engine oil ............................................8-13
Final transmission oil ..........................8-21
Spark plug inspection .........................8-27
Engine air filter element and V-belt
case air filter element cleaning .........8-31
Idle speed adjustment ........................8-43
Valve clearance adjustment ...............8-45
Throttle lever adjustment ....................8-45
Front and rear brake shoe
inspection .........................................8-47
Front brake lever free play
adjustment ........................................8-49
Rear brake adjustment .......................8-59
Drive chain slack check ......................8-61
Drive chain slack adjustment ..............8-63Lubricating and drive chain ................8-67
Draining the V-belt compartment ........8-69
Cable inspection and lubrication ........8-71
Brake lever lubrication ........................8-73
Knuckle shaft, lower arms and
steering shaft lubrication ..................8-73
Wheel removal ...................................8-75
Wheel installation ...............................8-75
Battery ................................................8-77
Replenishing a battery fluid ................8-81
Fuse replacement ...............................8-85
Replacing the headlight bulb ..............8-87
Tail/brake light bulb replacement .......8-91
Headlight beam adjustment ................8-93
Troubleshooting ..................................8-95
Troubleshooting chart .........................8-998
1C5-9-61-01 9/4/04 8:48 PM Page 14

4-7
NOTE:
If the starter switch is pushed with the main
switch “ON” and the engine stop switch “OFF”,
the starter motor will be activated but the engine
will not start. To start the engine, be sure to
position the engine stop switch at “RUN”.
EBU14770
Light switch “LIGHTS”
Set the switch to the “LO” position to turn on the
low beam and the taillight.
Set the switch to the “HI” position to turn on the
high beam and the taillight.
Set the switch to the “OFF” position to turn off all
of the lights.
1C5-9-61-04 22/3/04 3:08 PM Page 8

8-93
EBU10890
Headlight beam adjustment
cC
It is advisable to have a Yamaha dealer make
this adjustment.
To raise the beam, turn the adjusting screw in
direction a.
To lower the beam, turn the adjusting screw in
direction b.a
b
1
1. Adjusting screw1. Vis de réglage1. Tornillo de ajuste
1C5-9-61-08 9/4/04 9:30 AM Page 8-94
