YAMAHA GRIZZLY 450 2016 Owners Manual

10-1
10
EBU25962
SPECIFICATIONS
Dimensions:Overall length:1993 mm (78.5 in)
Overall width: 1093 mm (43.0 in)
Overall height:
1120 mm (44.1 in)
Seat height: 840 mm (33.1 in)
Wheelbase: 1233 mm (48.5 in)
Ground clearance:
245 mm (9.6 in)
Minimum turning radius: 3000 mm (118 in)Weight:Curb weight:
276.0 kg (607 lb) (YFM45GDXG)
282.0 kg (620 lb) (YFM45GPHG, YFM45GPXG)Noise and vibration level:Noise level (77/311/EEC):78.3 dB(A) (YFM45GDXG_EUR/FRA/GBR,
YFM45GPHG, YFM45GPXG_EUR/FRA/GBR)
Uncertainty of measurement: 3.0 dB(A) (YFM45GDXG_EUR/FRA/GBR, YFM45GPHG,
YFM45GPXG_EUR/FRA/GBR) Vibration on seat (EN1032, ISO5008):
0.6 m/s² (YFM45GDXG_EUR/FRA/GBR)
1.0 m/s² (YFM45GPHG, YFM45GPXG_EUR/FRA/GBR)
Uncertainty of measurement:
0.3 m/s² (YFM45GDXG_EUR/FRA/GBR, YFM45GPHG,
YFM45GPXG_EUR/FRA/GBR)
Vibration on handle (EN1032, ISO5008):
2.9 m/s² (YFM45GDXG_EUR/FRA/GBR)
Will not exceed 2.5 m/s² (YFM45GPHG,
YFM45GPXG_EUR/FRA/GBR)
Uncertainty of measurement: 0.5 m/s² (YFM45GDXG_EUR/FRA/GBR)
0.6 m/s² (YFM45GPHG, YFM45GPXG_EUR/FRA/GBR)
Engine:Engine type:
Liquid cooled 4-stroke, SOHC
Cylinder arrangement: Single cylinder
Displacement: 421 cm³
Bore × stroke:
84.5 × 75.0 mm (3.33 × 2.95 in)
Compression ratio: 10.0 : 1
Starting system: Electric starter
Lubrication system:
Wet sump
U2LC62E0.book Page 1 Monday, May 11, 2015 2:28 PM

10-2
10
Engine oil:Recommended brand:YAMALUBE
Type:
SAE 5W-30, 10W-30, 10W-40, 15W-40, 20W-40 or 20W-
50
Recommended engine oil grade: API service SG type or higher, JASO standard MA
Engine oil quantity: Without oil filter cartridge replacement:
2.30 L (2.43 US qt, 2.02 Imp.qt)
With oil filter cartridge replacement: 2.40 L (2.54 US qt, 2.11 Imp.qt)Final gear oil:Type:
Yamaha Friction Modified Shaft Drive Gear Oil
Quantity: 0.38 L (0.40 US qt, 0.33 Imp.qt)
Differential gear oil:Type:Yamaha Friction Modified Shaft Drive Gear Oil or SAE 80
API GL-4 Hypoid gear oil
Quantity: 0.23 L (0.24 US qt, 0.20 Imp.qt)Coolant quantity:Coolant reservoir (up to the maximum level mark):0.25 L (0.26 US qt, 0.22 Imp.qt)
Radiator (including all routes): 1.32 L (1.40 US qt, 1.16 Imp.qt)Air filter:Air filter element:Wet elementFuel:Recommended fuel:
Regular unleaded gasoline only
Fuel tank capacity: 15.0 L (4.0 US gal, 3.30 Imp.gal)
Fuel reserve amount: 4.5 L (1.19 US gal, 0.99 Imp.gal)Carburetor:Type × quantity:
BSR33 x 1Spark plug (s):Manufacturer/model:
NGK/DR8EA
Spark plug gap: 0.6–0.7 mm (0.024–0.028 in)
0 10 30 50 70 90 110 130 F
–20 –10 0 10 20 30 40 50 CSAE 5W-30
SAE 10W-30
SAE 10W-40
SAE 15W-40
SAE 20W-40SAE 20W-50
U2LC62E0.book Page 2 Monday, May 11, 2015 2:28 PM

10-3
10
Clutch:Clutch type:Wet, centrifugal automaticTransmission:Secondary reduction system:Shaft drive
Secondary reduction ratio: 39/24 × 24/18 × 33/9 (7.944)
Transmission type:
V-belt automatic
Operation: Left hand operation
Reverse gear: 29/17 (1.706)
Low range:
45/16 (2.813)
High range: 38/23 (1.652)Chassis:Frame type:
Steel tube frame
Caster angle: 2.50 °
Trail: 8.5 mm (0.4 in)Front tire:Type:Tubeless
Size: AT25 x 8-12 Manufacturer/model:
CHENG SHIN/C-828 (YFM45GDXG_AUS/NZL,
YFM45GPXG_AUS/NZL)
MAXXIS/MU13 (YFM45GDXG_EUR/FRA/GBR,
YFM45GPHG, YFM45GPXG_EUR/FRA/GBR)
Rear tire:Type:
Tubeless
Size: AT25 x 10-12
Manufacturer/model: CHENG SHIN/C-828 (YFM45GDXG_AUS/NZL,
YFM45GPXG_AUS/NZL)
MAXXIS/MU14 (YFM45GDXG_EUR/FRA/GBR,
YFM45GPHG, YFM45GPXG_EUR/FRA/GBR)Loading:Maximum loading limit:210.0 kg (463 lb)
(Total weight of rider, cargo, accessories, and tongue)Tire air pressure (measured on cold tires):Recommended:Front:25.0 kPa (0.250 kgf/cm², 3.6 psi)
Rear: 25.0 kPa (0.250 kgf/cm², 3.6 psi)
Minimum:
Front:22.0 kPa (0.220 kgf/cm², 3.2 psi)
Rear:
22.0 kPa (0.220 kgf/cm², 3.2 psi)
U2LC62E0.book Page 3 Monday, May 11, 2015 2:28 PM

10-4
10
Front wheel:Wheel type:Panel wheel
Rim size:
12 x 6.0ATRear wheel:Wheel type:Panel wheel
Rim size:
12 x 7.5ATFront brake:Type:Disc brake
Operation:
Right hand operation
Specified brake fluid: DOT 4Rear brake:Type:
Wet multiple disc brake
Operation: Left hand and right foot operationFront suspension:Type:
Double wishbone
Spring/shock absorber type: Coil spring/oil damper
Wheel travel: 160 mm (6.3 in)
Rear suspension:Type:Double wishbone
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel: 180 mm (7.1 in)Electrical system:Ignition system:
DC CDI
Charging system: AC magnetoBattery:Model:
YTX20L-BS
Voltage, capacity: 12 V, 18.0 AhHeadlight:Bulb type:
Krypton bulbBulb voltage, wattage × quantity:Headlight:
12 V, 30.0/30.0 W × 2
Tail/brake light:
12 V, 5.0/21.0 W × 1
Meter lighting: EL (Electroluminescent)
Neutral indicator light: LED
Reverse indicator light:
LED
U2LC62E0.book Page 4 Monday, May 11, 2015 2:28 PM

10-5
10
Coolant temperature warning light:LED
Park indicator light: LED
On-Command four-wheel-drive/differential gear lock
indicator: LCD
High-range indicator light:
LED
Low-range indicator light: LED
Differential gear lock indicator light: LED
EPS warning light:
12 V, 1.7 W (YFM45GPHG, YFM45GPXG)Fuses:Main fuse:30.0 A
EPS fuse:
40.0 A (YFM45GPHG, YFM45GPXG)
Headlight fuse: 15.0 A
Signaling system fuse: 10.0 A
Ignition fuse:
10.0 A
Auxiliary DC jack fuse: 10.0 A
Backup fuse: 10.0 A (YFM45GDXG)
5.0 A (YFM45GPHG, YFM45GPXG) Four-wheel-drive motor fuse:
10.0 A
EBU30402For Europe only
The figures quoted are emission levels and are not
necessarily safe working levels. Whilst there is a
correlation between the emission and exposure
levels, this cannot be used reliably to determine
whether or not further precautions are required.
Factors that influence the actual level of exposure
of work-force include the characteristics of the
work room, the other sources of noise, etc. i.e. the
number of machines and other adjacent process-
es, and the length of time for which an operator is
exposed to the noise. Also the permissible expo-
sure level can vary from country. This information,
however, will enable the user of the machine to
make a better evaluation of the hazard and risk.
U2LC62E0.book Page 5 Monday, May 11, 2015 2:28 PM

11-1
11
EBU26001
CONSUMER INFORMATION
EBU28202Identification numbersRecord the vehicle identification number and
model label information in the spaces provided
below for assistance when ordering spare parts
from a Yamaha dealer or for reference in case the
ATV is stolen.
VEHICLE IDENTIFICATION NUMBER:
MODEL LABEL INFORMATION:EBU26031Vehicle identification number
The vehicle identification number is stamped into
the frame.
TIPThe vehicle identification number is used to iden-
tify your ATV. EBU26051Model label
The model label is affixed at the location in the il-
lustration. Record the information on this label in
the space provided. This information will be need-
ed when ordering spare parts from a Yamaha
dealer.1. Vehicle identification number (front left side)
U2LC62E0.book Page 1 Monday, May 11, 2015 2:28 PM

11-2
11
1. Model labelU2LC62E0.book Page 2 Monday, May 11, 2015 2:28 PM

12-1
12
INDEX
AAccessories and loading ................................................ 6-6
Accessories, auxiliary jack ........................................... 4-24
Air filter element, cleaning ............................................ 8-30
Axle boots .................................................................... 8-46BBattery .......................................................................... 8-52
Brake fluid, changing ...................................................8-40
Brake fluid level, checking ........................................... 8-39
Brake lever free play, checking the front ..................... 8-40
Brake lever, front .......................................................... 4-14
Brake levers, checking and lubricating ........................ 8-48
Brake light switches ..................................................... 8-47
Brake pads and friction plates, checking ..................... 8-38
Brake pedal and rear brake lever ................................. 4-14
Brake pedal, checking and lubricating ........................ 8-49
Brakes .......................................................................... 8-38
Brakes, front and rear .................................................... 5-3CCables, checking and lubricating ................................. 8-48
Carburetor, adjusting ...................................................8-35
Carrier, front ................................................................. 4-22
Carrier, rear .................................................................. 4-22
Chassis fasteners ........................................................... 5-7
Cleaning ......................................................................... 9-1
Coolant ................................................................. 5-3, 8-26
Coolant temperature warning light ................................. 4-3DDifferential gear oil ............................................... 5-3, 8-24Drive select lever .......................................................... 4-15
Drive select lever and driving in reverse ........................ 6-3
Drive select lever safety system cable, adjusting ........ 8-38
Drive shaft universal joint, lubricating .......................... 8-50
EEngine break-in .............................................................. 6-5
Engine, cold start ........................................................... 6-1
Engine idling speed ...................................................... 8-35
Engine oil ....................................................................... 5-3
Engine oil and oil filter cartridge .................................. 8-16
Engine, starting a warm ................................................. 6-3
Engine stop switch ......................................................... 4-7
EPS warning light (for EPS model) ................................. 4-3FFinal gear oil ......................................................... 5-3, 8-21
Four-wheel-drive/differential gear lock indicator ........... 4-4
Fuel ...................................................................... 4-15, 5-3
Fuel cock ...................................................................... 4-17
Fuel gauge ..................................................................... 4-6
Fuel tank cap ............................................................... 4-15
Fuses, replacing ........................................................... 8-55HHandlebar switches ....................................................... 4-7
Headlight beam, adjusting ........................................... 8-59
Headlight bulb, replacing ............................................. 8-57
High-range indicator light .............................................. 4-2
Horn switch .................................................................... 4-7IIdentification numbers ................................................. 11-1
U2LC62E0.book Page 1 Monday, May 11, 2015 2:28 PM

12-2
12
Indicator lights and warning lights ................................. 4-2
Instruments, lights and switches ................................... 5-7LLabel locations ............................................................... 1-1
Light switch .................................................................... 4-7
Low-range indicator light ............................................... 4-2MMain switch .................................................................... 4-1
Maintenance and lubrication chart ................................ 8-5
Maintenance chart, emission control system ................ 8-3
Model label .................................................................. 11-1
Multi-function display .................................................... 4-5NNeutral indicator light ..................................................... 4-2OOn-Command differential gear lock switch ................. 4-10
On-Command four-wheel-drive switch ......................... 4-9
Override switch .............................................................. 4-8
Owner’s manual and tool kit .......................................... 8-2PPanels, removing and installing ................................... 8-10
Park indicator light ......................................................... 4-3
Parking ........................................................................... 6-5
Parking on a slope ......................................................... 6-6
Part locations ................................................................. 3-1RRear brake, adjusting the lever, pedal free play and pedal height ............................................................... 8-41
Rear knuckle pivots, lubricating .................................. 8-51
Reverse indicator light ................................................... 4-3
Riding your ATV ............................................................. 7-1
SSafety information .......................................................... 2-1
Seat .............................................................................. 4-19
Shock absorber assemblies, adjusting the front and
rear ............................................................................ 4-22
Spark arrester, cleaning ............................................... 8-33
Spark plug, checking ................................................... 8-14
Specifications .............................................................. 10-1
Speed limiter ................................................................ 4-13
Stabilizer bushes, checking .......... ............................... 8-51
Starter (choke) ............................................................. 4-18
Start switch .................................................................... 4-7
Steering shaft, lubricating ............................................ 8-52
Storage .......................................................................... 9-2
Storage compartments ................................................ 4-20TTail/brake light bulb, replacing .................................... 8-60
Throttle lever ......................................................... 4-12, 5-4
Throttle lever free play, adjusting ................................ 8-37
Tires ............................................................................... 5-4
Troubleshooting ........................................................... 8-63
Troubleshooting charts ................................................ 8-64VValve clearance ............................................................ 8-37
V-belt case drain plug .................................................. 8-35
V-belt cooling duct check hose ................................... 8-34
Vehicle identification number ...................................... 11-1WWheel hub bearings, checking .................................... 8-49
Wheel, installing ........................................................... 8-62
Wheel, removing .......................................................... 8-61
U2LC62E0.book Page 2 Monday, May 11, 2015 2:28 PM

EBU26173
WARNING
ALWAYS
:
• use proper riding techniques to avoid
vehicle overturns on hills and rough
terrain and in turns.

seriously affect handling and control.
Improper ATV use can result in SEVERE INJURY or DEATH.
NEVER USE
WITH DRUGS
OR ALCOHOL
ALWAYS USE
AN APPROVED HELMET AND
PROTECTIVE GEAR NEVER USE
ON PAVED ROADS NEVER CARRY
PASSENGERS
NEVER
operate:


conditions.

another vehicle.

balance and steering and increase risk
of losing control.
LOCATE AND READ OWNER’S MANUAL. FOLLOW ALL INSTRUCTIONS AND WARNINGS.\
PRINTED IN USA
2016.02-0.3× 1 CR
(E)
U2LC6SE0.book Page 1 Thursday, January 21, 2016 9:59 AM
