YAMAHA GRIZZLY 700 2015 Owners Manual

9-3
9
6. Cover the muffler outlet with a plastic bag to
prevent moisture from entering it.
7. Remove the battery and fully charge it. Store it in a cool, dry place and charge it once a
month. Do not store the battery in an exces-
sively cold or warm place [less than 0 °C (30
°F) or more than 30 °C (90 °F)]. For more infor-
mation on storing the battery, see page 8-55.
TIPMake any necessary repairs before storing the
ATV. UB3860E0.book Page 3 Monday, July 14, 2014 10:34 AM

10-1
10
EBU25962
SPECIFICATIONS
Dimensions:Overall length:2065 mm (81.3 in)
Overall width: 1180 mm (46.5 in)
Overall height:
1240 mm (48.8 in)
Seat height: 905 mm (35.6 in)
Wheelbase: 1250 mm (49.2 in)
Ground clearance:
275 mm (10.8 in)
Minimum turning radius: 3200 mm (126 in)Weight:Curb weight:
294.0 kg (648 lb)Noise and vibration level:Noise level (77/311/EEC):YFM700FWAD 79.0 dB(A)@3125 r/min
YFM700PF 79.0 dB(A)@3125 r/min (EUR)(FRA)(GBR)
YFM700PHF 79.0 dB(A)@3125 r/min
YFM700PSF 79.0 dB(A)@3125 r/min (EUR)(FRA)(GBR) Vibration on seat (EN1032, ISO5008):
YFM700FWAD Will not exceed 0.5 m/s²
YFM700PF Will not exceed 0.5 m/s² (EUR)(FRA)(GBR)
YFM700PHF Will not exceed 0.5 m/s²
YFM700PSF Will not exceed 0.5 m/s² (EUR)(FRA)(GBR)
Vibration on handle (EN1032, ISO5008): YFM700FWAD Will not exceed 2.5 m/s²
YFM700PF Will not exceed 2.5 m/s² (EUR)(FRA)(GBR)
YFM700PHF Will not exceed 2.5 m/s²
YFM700PSF Will not exceed 2.5 m/s² (EUR)(FRA)(GBR)
Engine:Engine type:
Liquid cooled 4-stroke, SOHC
Cylinder arrangement: Single cylinder
Displacement: 686 cm³
Bore × stroke:
102.0 × 84.0 mm (4.02 × 3.31 in)
Compression ratio: 10.0 : 1
Starting system: Electric starter
Lubrication system:
Wet sumpEngine oil:Recommended brand:YAMALUBE
UB3860E0.book Page 1 Monday, July 14, 2014 10:34 AM

10-2
10
Type:SAE 5W-30, 10W-30, 10W-40, 15W-40, 20W-40 or 20W-
50
Recommended engine oil grade: API service SG type or higher, JASO standard MA
Engine oil quantity: Without oil filter cartridge replacement:2.00 L (2.11 US qt, 1.76 Imp.qt)
With oil filter cartridge replacement: 2.10 L (2.22 US qt, 1.85 Imp.qt)Final gear oil:Type:SAE 80 API GL-4 Hypoid gear oil
Quantity: 0.20 L (0.21 US qt, 0.18 Imp.qt)Differential gear oil:Type:SAE 80 API GL-4 Hypoid gear oil Quantity:
0.22 L (0.23 US qt, 0.19 Imp.qt)
Coolant quantity:Coolant reservoir (up to the maximum level mark):
0.24 L (0.25 US qt, 0.21 Imp.qt)
Radiator (including all routes): 1.99 L (2.10 US qt, 1.75 Imp.qt)Air filter:Air filter element:
Wet elementFuel:Recommended fuel:Regular unleaded gasoline only
Fuel tank capacity:
20.0 L (5.28 US gal, 4.40 Imp.gal)
Fuel reserve amount: 4.5 L (1.19 US gal, 0.99 Imp.gal)Fuel injection:Throttle body:
ID mark:2BG1 00Spark plug (s):Manufacturer/model:NGK/CPR7EA-9
Spark plug gap: 0.8–0.9 mm (0.031–0.035 in)Clutch:Clutch type:Wet, centrifugal automatic
0 10 30 50 70 90 110 130 F
–20 –10 0 10 20 30 40 50 CSAE 5W-30
SAE 10W-30
SAE 10W-40
SAE 15W-40
SAE 20W-40SAE 20W-50
UB3860E0.book Page 2 Monday, July 14, 2014 10:34 AM

10-3
10
Transmission:Primary reduction system:V-belt
Secondary reduction system:
Shaft drive
Secondary reduction ratio: 41/21 × 24/18 × 33/9 (9.544)
Transmission type: V-belt automatic
Operation:
Left hand operation
Reverse gear: 23/14 × 28/23 (2.000)
Low range: 31/16 (1.938)
High range:
31/27 (1.148)Chassis:Frame type:Steel tube frame
Caster angle:
4.5 °
Trail: 26.0 mm (1.02 in)Front tire:Type:
Tubeless
Size: AT25 x 8-12 Manufacturer/model:
YFM700FWAD MAXXIS/MU19A
YFM700PF CHENG SHIN/C828 (AUS)(NZL)
YFM700PF MAXXIS/MU19A (EUR)(FRA)(GBR)
YFM700PHF MAXXIS/MU19A
YFM700PLF CHENG SHIN/C828
YFM700PSF CHENG SHIN/C828 (AUS)(NZL)
YFM700PSF MAXXIS/MU19A (EUR)(FRA)(GBR)
Rear tire:Type:
Tubeless
Size: AT25 x 10-12
Manufacturer/model: YFM700FWAD MAXXIS/MU20A
YFM700PF CHENG SHIN/C828 (AUS)(NZL)
YFM700PF MAXXIS/MU20A (EUR)(FRA)(GBR)
YFM700PHF MAXXIS/MU20A
YFM700PLF CHENG SHIN/C828
YFM700PSF CHENG SHIN/C828 (AUS)(NZL)
YFM700PSF MAXXIS/MU20A (EUR)(FRA)(GBR)Loading:Maximum loading limit:220.0 kg (485 lb)
(Total weight of rider, cargo, accessories, and tongue)Tire air pressure (measured on cold tires):Recommended:Front: 35.0 kPa (0.350 kgf/cm², 5.0 psi)
Rear: 30.0 kPa (0.300 kgf/cm², 4.4 psi)
UB3860E0.book Page 3 Monday, July 14, 2014 10:34 AM

10-4
10
Minimum:Front:
32.0 kPa (0.320 kgf/cm², 4.6 psi)
Rear: 27.0 kPa (0.270 kgf/cm², 4.0 psi)Front wheel:Wheel type:
Panel wheel
Rim size: 12 x 6.0ATRear wheel:Wheel type:
Panel wheel
Rim size: 12 x 7.5ATFront brake:Type:
Disc brake
Operation: Right hand operation
Specified brake fluid: DOT 4Rear brake:Type:Disc brake
Operation: Left hand and right foot operation
Specified brake fluid:
DOT 4
Front suspension:Type:Double wishbone
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel: 193 mm (7.6 in)Rear suspension:Type:
Double wishbone
Spring/shock absorber type: Coil spring/oil damper
Wheel travel: 232 mm (9.1 in)Electrical system:Ignition system:TCI
Charging system: AC magnetoBattery:Model:YTX20L-BS
Voltage, capacity: 12 V, 18.0 AhHeadlight:Bulb type:Halogen bulbBulb voltage, wattage × quantity:Headlight:
12 V, 35.0/35.0 W × 2
UB3860E0.book Page 4 Monday, July 14, 2014 10:34 AM

10-5
10
Tail/brake light:12 V, 5.0/21.0 W × 1
Meter lighting: EL (Electroluminescent)
Neutral indicator light:
LED
Reverse indicator light: LED
Coolant temperature warning light: LED
EPS warning light:
LED
Park indicator light: LED
On-Command four-wheel-drive/differential gear lock
indicator: LCD
Engine trouble warning light: LED
High-range indicator light:
LED
Low-range indicator light: LED
Differential gear lock indicator light: LEDFuses:Main fuse:40.0 A
Fuel injection system fuse: 15.0 A
EPS fuse:
40.0 A Headlight fuse:
10.0 A
Signaling system fuse: 5.0 A
Ignition fuse:
10.0 A
Auxiliary DC jack fuse: 10.0 A
Four-wheel-drive motor fuse: 10.0 A
Radiator fan motor fuse:
20.0 A
EBU30402For Europe only
The figures quoted are emission levels and are not
necessarily safe working levels. Whilst there is a
correlation between the emission and exposure
levels, this cannot be used reliably to determine
whether or not further precautions are required.
Factors that influence the actual level of exposure
of work-force include the characteristics of the
work room, the other sources of noise, etc. i.e. the
number of machines and other adjacent process-
es, and the length of time for which an operator is
exposed to the noise. Also the permissible expo-
UB3860E0.book Page 5 Monday, July 14, 2014 10:34 AM

10-6
10
sure level can vary from country. This information,
however, will enable the user of the machine to
make a better evaluation of the hazard and risk.
UB3860E0.book Page 6 Monday, July 14, 2014 10:34 AM

11-1
11
EBU26001
CONSUMER INFORMATION
EBU28202Identification numbersRecord the vehicle identification number and
model label information in the spaces provided
below for assistance when ordering spare parts
from a Yamaha dealer or for reference in case the
ATV is stolen.
VEHICLE IDENTIFICATION NUMBER:
MODEL LABEL INFORMATION:EBU26031Vehicle identification number
The vehicle identification number is stamped into
the frame.
TIPThe vehicle identification number is used to iden-
tify your ATV. EBU26051Model label
The model label is affixed at the location in the il-
lustration. Record the information on this label in
the space provided. This information will be need-
ed when ordering spare parts from a Yamaha
dealer.1. Vehicle identification number (front left side)
UB3860E0.book Page 1 Monday, July 14, 2014 10:34 AM

11-2
11
1. Model labelUB3860E0.book Page 2 Monday, July 14, 2014 10:34 AM

12-1
12
INDEX
AAccessories and loading ................................................ 6-6
Accessories, auxiliary jack ........................................... 4-23
Air filter element, cleaning ............................................ 8-39
Axle boots .................................................................... 8-51BBattery .......................................................................... 8-55
Brake fluid, changing ...................................................8-48
Brake fluid level, checking ........................................... 8-47
Brake lever, front .......................................................... 4-14
Brake levers, checking and lubricating ........................ 8-52
Brake pads, checking the front and rear ..................... 8-46
Brake pedal and rear brake lever ................................. 4-14
Brake pedal, checking and lubricating ........................ 8-53
Brake pedal free play, adjusting .................................. 8-49
Brakes .......................................................................... 8-45
Brakes, front and rear .................................................... 5-3CCables, checking and lubricating ................................. 8-52
Carrier, front ................................................................. 4-21
Carrier, rear .................................................................. 4-21
Chassis fasteners ........................................................... 5-7
Cleaning ......................................................................... 9-1
Coolant ................................................................. 5-3, 8-31
Coolant temperature warning light ................................. 4-3DDifferential gear oil ............................................... 5-3, 8-29
Drive select lever .......................................................... 4-15
Drive select lever and driving in reverse ........................ 6-2Drive select lever safety system cable, adjusting ........ 8-45
EEngine break-in .............................................................. 6-4
Engine oil ....................................................................... 5-3
Engine oil and oil filter cartridge .................................. 8-22
Engine stop switch ......................................................... 4-8
Engine trouble warning light .......................................... 4-3
EPS warning light ........................................................... 4-3FFinal gear oil ......................................................... 5-3, 8-26
Four-wheel-drive/differential gear lock indicator ........... 4-4
Front and rear brake lever free play, checking ............ 8-48
Fuel ...................................................................... 4-16, 5-3
Fuel tank cap ............................................................... 4-15
Fuses, replacing ........................................................... 8-59HHandlebar switches ....................................................... 4-7
Headlight beam, adjusting ........................................... 8-62
Headlight bulb, replacing ............................................. 8-61
High-range indicator light .............................................. 4-2
Horn switch .................................................................... 4-8IIdentification numbers ................................................. 11-1
Indicator lights and warning lights ................................. 4-2
Instruments, lights and switches ................................... 5-7LLabel locations ............................................................... 1-1
Light switch .................................................................... 4-8
Low-range indicator light ............................................... 4-2
