3-6
3
gerous loss of lights or engine power. Also, the
battery tends to discharge more quickly if elec-
trical accessories are added.
WARNING
EWB00073Avoid Carbon Monoxide Poisoning
All engine exhaust contains carbon monoxide,
a deadly gas. Breathing carbon monoxide can
cause headaches, dizziness, drowsiness, nau-
sea, confusion, and eventually death.
Carbon Monoxide is a colorless, odorless,
tasteless gas which may be present even if you
do not see or smell any engine exhaust. Deadly
levels of carbon monoxide can collect rapidly
and you can quickly be overcome and unable
to save yourself. Also, deadly levels of carbon
monoxide can linger for hours or days in en-
closed or poorly ventilated areas. If you experi-
ence any symptoms of carbon monoxide
poisoning, leave the area immediately, get
fresh air, and SEEK MEDICAL TREATMENT.
Do not run engine indoors. Even if you try to
ventilate engine exhaust with fans or open
windows and doors, carbon monoxide can
rapidly reach dangerous levels.
Do not run engine in poorly ventilated or par-
tially enclosed areas such as barns, garages,
or carports.
Do not run engine outdoors where engine
exhaust can be drawn into a building through
openings such as windows and doors.
UBDE60E0.book Page 6 Monday, April 22, 2019 4:12 PM
Page 32 of 182
4-1
4
EBU17681
DESCRIPTION
EBU17691Left view
EBU17701Right view
1. Radiator cap
2. Battery
3. Fuses
4. Air filter case
5. Spark arrester
6. Engine oil dipstick
7. Oil filter cartridge
8. Coolant reservoir
5
1
2,3
4
6
7
8
1. Rear storage compartment
2. Fuel tank cap
3. Tool kit
4. Center storage compartment
5. Spark plug
6. Winch (equipped models)
7. Front shock absorber
8. Brake pedal
9. V-belt case drain plug
10.Rear shock absorber
5
6
1
7
10
2
3
489
UBDE60E0.book Page 1 Monday, April 22, 2019 4:12 PM
Page 33 of 182
4-2
4
EBU17715Controls and instruments1. Drive select lever
2. Rear brake lever
3. Handlebar switches
4. Horn switch
5. Rear brake fluid reservoir
6. Winch switch (equipped models)
7. Multi-function display
8. Front brake fluid reservoir
9. On-Command 4WD switches
10.Throttle lever
11.Front brake lever
12.Front storage compartment
13.Main switch
14.Auxiliary DC jack1
6
234 7 89
1110 12 14
13
5
UBDE60E0.book Page 2 Monday, April 22, 2019 4:12 PM
Page 34 of 182
5-1
5
EBU17739
INSTRUMENT AND CONTROL FUNCTIONS
EBU29913Main switch“” (on)
All electrical systems are supplied with power. The
engine can be started. The key cannot be re-
moved.
“ ” (off)
All electrical systems are off. The key can be re-
moved.1. Main switch
1
UBDE60E0.book Page 1 Monday, April 22, 2019 4:12 PM
Page 35 of 182
5-2
5
EBU26699Indicator lights and warning lights
EBU17992Low-range indicator light “ ”
This indicator light comes on when the transmis-
sion is in the low-range position.EBU17982High-range indicator light “ ”
This indicator light comes on when the transmis-
sion is in the high-range position.EBU17861Neutral indicator light “ ”
This indicator light comes on when the transmis-
sion is in the neutral position.EBU17831Reverse indicator light “ ”
This indicator light comes on when the transmis-
sion is in the reverse position.EBU38080Park indicator light “ ”
This indicator light comes on when the transmis-
sion is in the park position.EBU27982High beam indicator light “ ”
This indicator light comes on when the high beam
of the headlight is switched on.
1. Differential gear lock indicator light “ ”
2. Low-range indicator light “L”
3. High-range indicator light “H”
4. Neutral indicator light “N”
5. Reverse indicator light “R”
6. Park indicator light “ ”
7. Four-wheel drive icon “ ”
8. Differential gear lock icon “ ”
9. Electric Power Steering warning light “EPS”
10.High beam indicator light “ ”
11.Battery voltage warning light “ ”
12.Coolant temperature warning light “ ”
13.Engine trouble warning light “ ”1
7,8
23456
910111213
UBDE60E0.book Page 2 Monday, April 22, 2019 4:12 PM
Page 36 of 182
5-3
5
EBU38261Battery voltage warning light “ ”
This warning light comes on if the detected battery
voltage is less than 10 volts, or greater than 18
volts.EBU38091Coolant temperature warning light “ ”
This warning light comes on in red when the en-
gine is overheating. If the red light comes on, stop
the vehicle as soon as it is safe to do so and allow
the engine to idle for about 10 minutes. If the
warning light does not go off, stop the engine and
allow it to cool. (See page 9-65.)TIPThe coolant temperature warning light can be
checked by turning the key to “ ” (on). The
warning light should come on in purple briefly and
then go off. If the warning light does not come on
initially when the key is turned to “ ” (on), or if
the warning light remains on, have a Yamaha deal-
er check the vehicle.
NOTICEECB02040The engine may overheat if the vehicle is
overloaded. If this happens, reduce the load
to specification.
After restarting, make sure that the warning
light is out. Continuous use while this warn-
ing light is on may cause damage to the en-
gine. EBU30483Engine trouble warning light “ ”
This warning light comes on or flashes if a problem
is detected in the electrical circuit monitoring the
engine. When this occurs, the display will indicate
an error code (see page 5-10). Have a Yamaha
dealer check the self-diagnosis system.
The electrical circuit of the warning light can be
checked by turning the key to “ ” (on). The
warning light should come on for a few seconds,
and then go off.
If the warning light does not come on initially when
the key is turned to “ ” (on), or if the warning
light remains on, have a Yamaha dealer check the
vehicle.
UBDE60E0.book Page 3 Monday, April 22, 2019 4:12 PM
Page 37 of 182
5-4
5
EBU30511Electric Power Steering warning light “EPS”
This warning light comes on when the key is
turned to “ ” (on), and then goes off once the
engine is started. If the warning light remains on or
comes on after the engine is started, the EPS sys-
tem may not be working correctly. When this oc-
curs, have a Yamaha dealer check the EPS
system.
The electrical circuit of the warning light can be
checked by turning the key to “ ” (on). If the
warning light does not come on, have a Yamaha
dealer check the electrical circuit.TIPIf the engine is stopped using the engine stop
switch and the key is in the “ ” (on) position,
the EPS warning light comes on to indicate that
the power assistance for the steering is not
functioning.
If the steering load is too heavy (i.e., excessive
steering use when the ATV is traveling at a slow
speed), the power assist is reduced to protect
the EPS motor from overheating.
EBU38100Four-wheel drive icon “ ”, differential gear
lock icon “ ” and indicator light “ ”
The four-wheel drive icon “ ” comes on when the
drivetrain is set to “4WD” (four-wheel drive).
The differential gear lock icon “ ” and the differ-
ential gear lock indicator light “ ” come on
when the drivetrain is set to “4WD” with the differ-
ential gear locked.TIPDue to the synchronizing mechanism in the dif-
ferential gear case, the four-wheel drive icon
may not come on until the ATV starts moving.
When the On-Command differential gear lock
switch is set to “LOCK” or “4WD”, the “ ” icon
and the “ ” indicator light will flash until the
differential gear is completely locked or un-
locked. Turn the handlebar or start moving to
help the differential lock to engage or disen-
gage.
UBDE60E0.book Page 4 Monday, April 22, 2019 4:12 PM
Page 38 of 182
5-5
5
EBU38113Multi-function display The multi-function display is equipped with the
following:
speedometer
odometer
tripmeters
clock
hour meter
voltage display
coolant temperature display
fuel gauge
brightness control mode
error code display
Speedometer
The speedometer shows the vehicle’s traveling
speed. The speedometer can be set to “MPH” or
“km/h”. This also changes the odometer and trip-
meter units between miles and kilometers. To
change the display between “MPH” and “km/h”,
turn the key to “ ” (off), then while holding the
“SELECT” button pushed, turn the key to “ ”
(on).1. Speedometer
2. Odometer/Tripmeter A/Tripmeter B/Service tripmeter/Error code display
3. Clock/Hour meter/Voltage display/Coolant temperature display
4. Fuel gauge
5. “MODE” button
6. “SELECT” button
7. “RESET” button123
5
6
7
4
UBDE60E0.book Page 5 Monday, April 22, 2019 4:12 PM
Page 39 of 182
5-6
5
Odometer and tripmeters
The odometer shows the total distance traveled
by the vehicle.
The tripmeters show the distance traveled since
they were last reset. The tripmeters can be used to
record the distance traveled on a single trip, or to
estimate the distance that can be traveled with a
full tank of gas, etc. The service tripmeter shows
the distance traveled since it was reset at the last
maintenance. Push the “SELECT” button to switch between the
odometer “ODO”, the tripmeters “TRIP A” and
“TRIP B”, and the service tripmeter “ ” in the
following order:
ODO
→ TRIP A → TRIP B → → ODO
To reset a tripmeter, set the display to the tripme-
ter you want to reset, then push the “RESET” but-
ton for 2 seconds.
TIP The odometer will lock at 199999.
The tripmeters will reset and continue counting
after 9999.9 is reached.
1. Odometer/Tripmeter A/Tripmeter B/Service
tripmeter/Error code display
2. “SELECT” button
3. “RESET” button1
2
3
UBDE60E0.book Page 6 Monday, April 22, 2019 4:12 PM
Page 40 of 182
5-7
5Clock, hour meter, voltage display and coolant
temperature display
The clock displays time in 12-hour format. The
hour meter shows the total time the engine has
been running. The voltage display shows the bat-
tery voltage. The coolant temperature display
shows the temperature of the coolant.
Push the “MODE” button to switch between the
clock “CLOCK”, the hour meter “HOUR”, the volt-
age display “VOLT”, and the coolant temperature
display “ ” in the following order: CLOCK
→ HOUR → VOLT → → CLOCK
To set the clock
1. Set the display to the clock.
2. Push both the “SELECT” button and “RE- SET” button for 2 seconds. The hour digits
will start flashing.
3. Push the “RESET” button to set the hours.
4. Push the “SELECT” button, and the minute digits will start flashing.
5. Push the “RESET” button to set the minutes.
6. Push the “SELECT” button, and then release it to start the clock.
1. Clock/Hour meter/Voltage display/Coolant temperature display
2. “MODE” button
3. “SELECT” button
4. “RESET” button1
2
3
4
UBDE60E0.book Page 7 Monday, April 22, 2019 4:12 PM
