YAMAHA KODIAK 700 2018 Owners Manual

10-2
10
Bore × stroke:
103.0 × 85.0 mm (4.06 × 3.35 in)
Compression ratio: 10.1 : 1
Starting system:
Electric starter
Lubrication system: Wet sumpEngine oil:Recommended brand:
YAMALUBE
Type: SAE 0W-30, 10W-30, 10W-40, 15W-40, 20W-40 or 20W-
50
Recommended engine oil grade: API service SG type or higher, JASO standard MA Engine oil quantity:
Without oil filter cartridge replacement:
2.00 L (2.11 US qt, 1.76 Imp.qt)
With oil filter cartridge replacement: 2.10 L (2.22 US qt, 1.85 Imp.qt)
Final gear oil:Type:
Yamaha Friction Modified Plus Shaft Drive Oil (Part No.: ACC-SHFTL-PL-32)
Quantity:
0.52 L (0.55 US qt, 0.46 Imp.qt)Differential gear oil:Type:Yamaha Friction Modified Plus Shaft Drive Oil (Part No.: ACC-SHFTL-PL-32) or SAE 80 API GL-4 Hypoid gear oil
Quantity: 0.22 L (0.23 US qt, 0.19 Imp.qt)Coolant quantity:Coolant reservoir (up to the maximum level mark):0.25 L (0.26 US qt, 0.22 Imp.qt)
Radiator (including all routes): 1.76 L (1.86 US qt, 1.55 Imp.qt)Air filter:Air filter element:Wet elementFuel:Recommended fuel:
Regular unleaded gasoline only
Fuel tank capacity: 18.0 L (4.75 US gal, 3.96 Imp.gal)
0 10 30 50 70 90 110 130 ˚F
–20 –10 0 10 20 30 40 50 ˚CSAE 0W-30
SAE 10W-30
SAE 10W-40
SAE 15W-40
SAE 20W-40SAE 20W-50
UB1662E0.book Page 2 Monday, April 17, 2017 11:39 AM

10-3
10
Fuel reserve amount:4.0 L (1.06 US gal, 0.88 Imp.gal)Fuel injection:Throttle body:
ID mark: B161 00Spark plug (s):Manufacturer/model:NGK/CPR7EA-9
Spark plug gap: 0.8–0.9 mm (0.031–0.035 in)Clutch:Clutch type:Wet, centrifugal automaticTransmission:Secondary reduction system:
Shaft drive
Secondary reduction ratio: 43/21 × 24/18 × 33/9 (10.011)
Transmission type: V-belt automatic
Operation:
Left hand operation
Reverse gear: 23/14 × 28/23 (2.000)
Low range: 31/16 (1.938)
High range:
27/25 (1.080)
Chassis:Frame type:Steel tube frame
Caster angle:
4.53 °
Trail: 26.0 mm (1.02 in)Front tire:Type:
Tubeless
Size: AT25 x 8-12
Manufacturer/model: CHENG SHIN/C828 (YFM70KDXJ_AUS/NZL,
YFM70KPXJ_AUS/NZL)
MAXXIS/MU19 (YFM70KDHJ,
YFM70KDXJ_EUR/FRA/GBR, YFM70KPAJ,
YFM70KPHJ, YFM70KPSJ,
YFM70KPXJ_EUR/FRA/GBR)Rear tire:Type:Tubeless
Size:
AT25 x 10-12
Manufacturer/model: CHENG SHIN/C828 (YFM70KDXJ_AUS/NZL,
YFM70KPXJ_AUS/NZL)
MAXXIS/MU20 (YFM70KDHJ,
YFM70KDXJ_EUR/FRA/GBR, YFM70KPAJ,
YFM70KPHJ, YFM70KPSJ,
YFM70KPXJ_EUR/FRA/GBR)
UB1662E0.book Page 3 Monday, April 17, 2017 11:39 AM

10-4
10
Loading:Maximum loading limit:240.0 kg (530 lb)
(Total weight of rider, cargo, accessories, and tongue)Tire air pressure (measured on cold tires):Recommended:
Front:35.0 kPa (0.350 kgf/cm², 5.0 psi)
Rear:
30.0 kPa (0.300 kgf/cm², 4.4 psi)
Minimum: Front:
32.0 kPa (0.320 kgf/cm², 4.6 psi)
Rear: 27.0 kPa (0.270 kgf/cm², 4.0 psi)Front wheel:Rim size:
12 x 6.0ATRear wheel:Rim size:12 x 7.5ATFront brake:Type:Hydraulic disc brake
Operation: Right hand operation
Specified brake fluid:
DOT 4Rear brake:Type:Mechanical wet multiple disc brake Operation:
Left hand and right foot operation
Front suspension:Type:
Double wishbone
Spring/shock absorber type: Coil spring/oil damper
Wheel travel: 180 mm (7.1 in)Rear suspension:Type:Double wishbone
Spring/shock absorber type: Coil spring/oil damper
Wheel travel:
230 mm (9.1 in)Electrical system:Ignition system:TCI
Charging system:
AC magnetoBattery:Model:YTX20L-BS
Voltage, capacity:
12 V, 18.0 AhHeadlight(s):Bulb type:Krypton bulb
UB1662E0.book Page 4 Monday, April 17, 2017 11:39 AM

10-5
10
Handlebar-mounted light:Bulb type:Halogen bulb (YFM70KPAJ, YFM70KPHJ, YFM70KPSJ,
YFM70KPXJ)Bulb voltage, wattage × quantity:Headlight:
12 V, 30.0/30.0 W × 2
Handlebar-mounted light: 12 V, 35.0/36.5 W × 1 (YFM70KPAJ, YFM70KPHJ,
YFM70KPSJ, YFM70KPXJ)
Tail/brake light: 12 V, 5.0/21.0 W × 1
Meter lighting: EL (Electroluminescent) (YFM70KPAJ, YFM70KPHJ,
YFM70KPSJ, YFM70KPXJ)
Neutral indicator light: LED
Fuel level warning light:
LED (YFM70KDHJ, YFM70KDXJ)
Reverse indicator light: LED
Coolant temperature warning light: LED
EPS warning light:
LED (YFM70KPAJ, YFM70KPHJ, YFM70KPSJ,
YFM70KPXJ)
Park indicator light:
LED
Four-wheel-drive indicator light: 12 V, 1.7 W × 1 (YFM70KDHJ, YFM70KDXJ)
Engine trouble warning light: LED High-range indicator light:
LED (YFM70KPAJ, YFM70KPHJ, YFM70KPSJ,
YFM70KPXJ)
Low-range indicator light: LED (YFM70KPAJ, YFM70KPHJ, YFM70KPSJ,
YFM70KPXJ)
Differential gear lock indicator light: LED (YFM70KPAJ, YFM70KPHJ, YFM70KPSJ,
YFM70KPXJ)
Fuses:Main fuse:40.0 A
Fuel injection system fuse:
15.0 A
EPS fuse: 40.0 A (YFM70KPAJ, YFM70KPHJ, YFM70KPSJ,
YFM70KPXJ)
Headlight fuse: 10.0 A (YFM70KDHJ, YFM70KDXJ)
15.0 A (YFM70KPAJ, YFM70KPHJ, YFM70KPSJ,
YFM70KPXJ)
Signaling system fuse:
10.0 A
Ignition fuse: 10.0 A
Auxiliary DC jack fuse: 10.0 A
Four-wheel-drive motor fuse:
10.0 A (YFM70KPAJ, YFM70KPHJ, YFM70KPSJ,
YFM70KPXJ)
Radiator fan motor fuse:
20.0 A
UB1662E0.book Page 5 Monday, April 17, 2017 11:39 AM

10-6
10
EBU30402For Europe only
The figures quoted are emission levels and are not
necessarily safe working levels. Whilst there is a
correlation between the emission and exposure
levels, this cannot be used reliably to determine
whether or not further precautions are required.
Factors that influence the actual level of exposure
of work-force include the characteristics of the
work room, the other sources of noise, etc. i.e. the
number of machines and other adjacent process-
es, and the length of time for which an operator is
exposed to the noise. Also the permissible expo-
sure level can vary from country. This information,
however, will enable the user of the machine to
make a better evaluation of the hazard and risk.UB1662E0.book Page 6 Monday, April 17, 2017 11:39 AM

11-1
11
EBU26001
CONSUMER INFORMATION
EBU28202Identification numbersRecord the vehicle identification number and
model label information in the spaces provided
below for assistance when ordering spare parts
from a Yamaha dealer or for reference in case the
ATV is stolen.
VEHICLE IDENTIFICATION NUMBER:
MODEL LABEL INFORMATION:EBU26031Vehicle identification number
The vehicle identification number is stamped into
the frame.
TIPThe vehicle identification number is used to iden-
tify your ATV. EBU26051Model label
The model label is affixed at the location in the il-
lustration. Record the information on this label in
the space provided. This information will be need-
ed when ordering spare parts from a Yamaha
dealer.1. Vehicle identification number (front left side)
UB1662E0.book Page 1 Monday, April 17, 2017 11:39 AM

11-2
11
1. Model label
1
UB1662E0.book Page 2 Monday, April 17, 2017 11:39 AM

12-1
12
INDEX
AAccessories and loading ................................................ 6-5
Accessories, DC jack ...................................................4-24
Air filter element, cleaning ............................................ 8-37
Axle boots .................................................................... 8-48BBattery .......................................................................... 8-53
Brake fluid, changing ...................................................8-44
Brake fluid level, checking ........................................... 8-43
Brake lever free play, checking the front ..................... 8-45
Brake lever, front .......................................................... 4-15
Brake levers, checking and lubricating ........................ 8-49
Brake light switches ..................................................... 8-48
Brake pads and friction plates, checking ..................... 8-42
Brake pedal and rear brake lever ................................. 4-16
Brake pedal, checking and lubricating ........................ 8-50
Brakes .......................................................................... 8-42
Brakes, front and rear .................................................... 5-3CCables, checking and lubricating ................................. 8-49
Carrier, front ................................................................. 4-21
Carrier, rear .................................................................. 4-22
Chassis fasteners ........................................................... 5-6
Cleaning ......................................................................... 9-1
Coolant ................................................................. 5-3, 8-29
Coolant temperature warning light ................................. 4-3DDifferential gear lock, indicators (YFM70KPXJ / YFM70KPAJ / YFM70KPHJ / YFM70KPSJ) ................ 4-5 Differential gear oil ............................................... 5-3, 8-27
Drive lever 2WD/4WD (YFM70K
DXJ / YFM70KDHJ) ... 4-13
Drive select lever .......................................................... 4-16
Drive select lever and driving in reverse ........................ 6-2
EEngine break-in .............................................................. 6-4
Engine oil ....................................................................... 5-3
Engine oil and oil filter cartridge .................................. 8-20
Engine stop switch ......................................................... 4-9
Engine trouble warning light .......................................... 4-3
EPS warning light (for EPS model) ................................. 4-4FFinal gear oil ......................................................... 5-3, 8-24
Four-wheel drive icon (YFM70KPXJ / YFM70KPAJ / YFM70KPHJ / YFM70KPSJ) ........................................ 4-5
Four-wheel drive indica tor light (YFM70KDXJ /
YFM70KDHJ) ............................................................... 4-4
Four-wheel drive switch (On-Command 4WD)
(YFM70KPXJ / YFM70KPAJ / YFM70KPHJ /
YFM70KPSJ) ............................................................. 4-11
Fuel ...................................................................... 4-17, 5-3
Fuel level warning light (YFM70KDXJ / YFM70KDHJ) ............................................................... 4-3
Fuel tank cap ............................................................... 4-17
Fuses, replacing ........................................................... 8-57HHandlebar switches ....................................................... 4-8
Headlight beam, adjusting ........................................... 8-62
Headlight bulb, replacing ............................................. 8-59
UB1662E0.book Page 1 Monday, April 17, 2017 11:39 AM

12-2
12
High-range indicator light (YFM70KPXJ / YFM70KPAJ / YFM70KPHJ / YFM70KPSJ) ................ 4-2
Horn switch .................................................................. 4-10IIdentification numbers ................................................. 11-1
Indicator lights and warning lights ................................. 4-1
Instruments, lights and switches ................................... 5-6LLabel locations ............................................................... 1-1
Light switch .................................................................. 4-10
Low-range indicator light (YFM70KPXJ / YFM70KPAJ / YFM70KPHJ / YFM70KPSJ) ................ 4-2MMain switch .................................................................... 4-1
Maintenance and lubrication chart ................................ 8-5
Maintenance chart, emission control system ................ 8-3
Model label .................................................................. 11-1
Multi-function display (YFM70KPXJ / YFM70KPAJ / YFM70KPHJ / YFM70KPSJ) ....................................... 4-5NNeutral indicator light ..................................................... 4-2OOn-Command drive switch “4WD/LOCK” (YFM70KPXJ / YFM70KPAJ / YFM70KPHJ /
YFM70KPSJ) ............................................................. 4-12
Override switch (YFM70KPXJ / YFM70KPAJ / YFM70KPHJ / YFM70KPSJ) ..................................... 4-10
Owner’s manual and tool kit .......................................... 8-2PPanels, removing and installing ..................................... 8-9
Park indicator light ......................................................... 4-2 Parking ........................................................................... 6-4
Parking on a slope ......................................................... 6-5
Part locations ................................................................. 3-1
RRear brake, adjusting the lever, pedal free play .......... 8-45
Rear knuckle pivots, lubricating .................................. 8-52
Reverse indicator light ................................................... 4-2
Riding your ATV ............................................................. 7-1SSafety information .......................................................... 2-1
Seat .............................................................................. 4-19
Shock absorber assemblies, adjusting the front and
rear (YFM70KPXJ / YFM70KPAJ / YFM70KPHJ /
YFM70KPSJ) ............................................................. 4-22
Spark arrester, cleaning ............................................... 8-39
Spark plug, checking ................................................... 8-17
Specifications .............................................................. 10-1
Speed limiter ................................................................ 4-15
Stabilizer bushes, checking .......... ............................... 8-51
Starting the engine ........................................................ 6-1
Start switch .................................................................. 4-10
Steering shaft, lubricating ............................................ 8-52
Storage .......................................................................... 9-2
Storage compartment .................................................. 4-20TTail/brake light bulb, replacing .................................... 8-63
Throttle lever ......................................................... 4-14, 5-4
Throttle lever free play, adjusting ................................ 8-41
Tires ............................................................................... 5-4
Trailer hitch (YFM70KPXJ / YFM70KPAJ / YFM70KPHJ / YFM70KPSJ) ..................................... 4-23
Troubleshooting ........................................................... 8-65
UB1662E0.book Page 2 Monday, April 17, 2017 11:39 AM

12-3
12
Troubleshooting charts ................................................ 8-66VValve clearance ............................................................ 8-42
V-belt case drain plug .................................................. 8-40
Vehicle identification number ....................................... 11-1WWheel hub bearings, checking ..................................... 8-51
Wheel, installing ........................................................... 8-64
Wheel, removing .......................................................... 8-64UB1662E0.book Page 3 Monday, April 17, 2017 11:39 AM
