YAMAHA MAJESTY 250 2003 Owner's Manual

3-4
INSTRUMENT AND CONTROL FUNCTIONS
3
EAU04581
SpeedometerSpeedometerThe speedometer shows the riding
speed.
When the key is turned to “ON”, the
speedometer needle will move to
160 km/h and back to zero in order to
test the electrical circuit.
1
1. Speedometer
ECA00134
cC
8 8
Do not operate the engine
above 8,500 r/min.
8 8
This scooter is equipped with
an engine speed limiter, which
prevents the engine speed
from exceeding approximately
9,000 r/min.
EAU04582
TachometerTachometerThe electric tachometer allows the
rider to monitor the engine speed and
keep it within the ideal power range.
When the key is turned to “ON”, the
tachometer needle will move to the
10,000 r/min and back to zero r/min
in order to test the electrical circuit.
1
1. Tachometer
5SJ-28199-E1 7/11/02 11:03 AM Page 19

EAU00110
Fuel gaugeFuel gaugeThe fuel gauge indicates the amount
of fuel in the fuel tank. The needle
moves towards “E” (Empty) as the
fuel level decreases. When the nee-
dle reaches “E”, approximately 2 L of
fuel remain in the fuel tank. If this
occurs, refuel as soon as possible.
NOTE:
Do not allow the fuel tank to empty
itself completely.
INSTRUMENT AND CONTROL FUNCTIONS
3
1
1. Fuel gauge
EAU03124
Coolant temperature gaugeCoolant temperature gaugeThis gauge indicates the coolant tem-
perature when the main switch is on.
The engine operating temperature
will vary with changes in weather and
engine load. If the needle points to
the red mark, stop your scooter and
let the engine cool. (See page 6-44
for details.)
EC000002
cC
Do not operate the engine if it is
overheated.
1
2
1. Coolant temperature gauge
2. Red mark
EAU04906
Multi-function displayDisplay, multi-functionThe multi-function display is
equipped with the following:
8a tripmeter (which shows the dis-
tance traveled since it was last
set to zero)
8a fuel tripmeter (which shows the
distance traveled when the fuel
level reaches approximately
2.0 L)
8an odometer (which shows the
total distance traveled)
8a clock
8an outside temperature display
1
2
3
1. Tripmeter
2. Odometer, fuel tripmeter
3. Clock, outside temperature and voltage
display
3-5
5SJ-28199-E1 7/11/02 11:03 AM Page 20

3-6
INSTRUMENT AND CONTROL FUNCTIONS
3
8a voltage display (which shows
the battery voltage)
NOTE:
8When the key is turned to “ON”,
all segments of the display come
on for a few seconds. During this
time, the multi-function display is
performing a self-test.
8Be sure to turn the key to “ON”
before using the “SELECT” and
“RESET” buttons.
NOTE:
8The tripmeter reset mode auto-
matically cancels after five sec-
onds. To return to the reset
mode, push the “SELECT” but-
ton again until “Trip” begins
flashing.
8To cancel the tripmeter reset
mode, push the “SELECT” but-
ton.
8If the tripmeter indicates “––––”,
have a Yamaha dealer check or
repair the multi-function display
as it may be faulty.
Tripmeter “Trip”
To reset the tripmeter:
1. Push the “SELECT” button until
the voltage display appears, then
push the “SELECT” button one
more time and “Trip” starts flash-
ing.
2. Push the “RESET” button for at
least one second to reset the
tripmeter to zero.
12
1.“SELECT” button
2.“RESET” button
5SJ-28199-E1 7/11/02 11:03 AM Page 21

3-7
Odometer “Odo”
The odometer has two functions.
8It shows the total distance trav-
eled.
8It automatically changes to the
fuel tripmeter mode “Trip F”
when the fuel level reaches
approximately 2.0 L. (See “Fuel
tripmeter” for details.)
NOTE:
If the odometer indicates “––––––”,
have a Yamaha dealer check or
repair the multi-function display as it
may be faulty.
INSTRUMENT AND CONTROL FUNCTIONS
3
Fuel tripmeter “Trip F”
When the fuel level reaches approxi-
mately 2.0 L, the odometer display
automatically changes to the fuel trip-
meter mode “Trip F” and starts count-
ing the distance traveled from that
point. After refueling and traveling
5 km, the odometer display returns to
“Odo”.To return to the odometer mode
before refueling, push the “SELECT”
button until “Trip F” begins flashing
(“Trip F” will only flash for five sec-
onds). While “Trip F” is flashing, push
the “RESET” button for at least one
second and the display will return to
the odometer mode. From that time,
both “Trip” and “Odo” are displayed
until you refuel and travel 5 km.
NOTE:
The display cannot be changed back
to “Trip F” after pushing the “RESET”
button.
5SJ-28199-E1 7/11/02 11:03 AM Page 22

3-8
INSTRUMENT AND CONTROL FUNCTIONS
3
Clock
To set the clock
1. Push the “SELECT” button until
the clock is displayed.
2. Push the “SELECT” button and
“RESET” button together for at
least two seconds.
4. Push the “SELECT” button, and
the minute digits will start flash-
ing.
5. Push the “RESET” button to set
the minutes.
6. Push the “SELECT” button and
then release it to start the clock.3. When the hour digits start flash-
ing, push the “RESET” button to
set the hours.
5SJ-28199-E1 7/11/02 11:03 AM Page 23

3-9
Outside temperature display
This display shows the outside tem-
perature from -10.0 °C to 50.0 °C in
0.5 °C increments.
INSTRUMENT AND CONTROL FUNCTIONS
3
8When the outside temperature
falls below -10.0 °C, “– – °C ” is
displayed.
8When the outside temperature
climbs above 50.0 °C, “50.0”
flashes.
NOTE:
8If “– – °C” is displayed or “50.0”
flashes while the outside temper-
ature is between -10.0 °C and
50.0 °C, there is a problem with
the electrical circuit. Have a
Yamaha dealer check or repair
the electric circuit.
8The accuracy of the temperature
reading may be affected when
riding slowly (approximately
under 20 km/h) or when stopped
at traffic signals, railroad cross-
ings, etc.
Voltage display
This display shows the battery volt-
age.
ECA00135
cC
If the voltage display indicates
“LO” or “HI”, there may be trouble
with the battery charging circuit or
the battery may be faulty. If “LO”
or “HI” appears in the display,
have a Yamaha dealer check or
repair the scooter.
5SJ-28199-E1 7/11/02 11:03 AM Page 24

3-10
INSTRUMENT AND CONTROL FUNCTIONS
3
EAU00109
Anti-theft alarm (optional)Anti-theft alarm (optional)This scooter can be equipped with an
optional anti-theft alarm by a Yamaha
dealer. Contact a Yamaha dealer for
more information.
EAU03889
Turn signal switch “4/6”Turn signal switchTo signal a right-hand turn, push this
switch to “6”. To signal a left-hand
turn, push this switch to “4”. When
released, the switch returns to the
center position. To cancel the turn
signal lights, push the switch in after
it has returned to the center position.
EAU00129
Horn switch “*”Horn switchPress this switch to sound the horn.EAU00118
Handlebar switches
Handlebar switchesEAU00120
Pass switch “PASS”Pass switchPress this switch to flash the head-
light.
EAU03888
Dimmer switch “&/%”Dimmer switchSet this switch to “&” for the high
beam and to “%” for the low beam.
1
2
3
4
1. Pass switch “PASS”
2. Dimmer switch “&/%”
3. Turn signal switch “4/6”
4. Horn switch “*”
5SJ-28199-E1 7/11/02 11:03 AM Page 25

3-11
EAU03890
Engine stop switch “#/$”Engine stop switchSet this switch to “#” before starting
the engine. Set this switch to “$” to
stop the engine in case of an emer-
gency, such as when the scooter
overturns or when the throttle cable is
stuck.
INSTRUMENT AND CONTROL FUNCTIONS
3
1
2
1. Engine stop switch “#/$”
2. Start switch “,”
EAU03801
Start switch “,”Start switchWith the sidestand up, push this
switch while applying the front or rear
brake to crank the engine with the
starter.
EC000005
cC
See page 5-1 for starting instruc-
tions prior to starting the engine.
EAU03882
Front brake leverBrake lever, frontThe front brake lever is located on
the right handlebar grip. To apply the
front brake, pull this lever toward the
handlebar grip.
1
1. Front brake lever
5SJ-28199-E1 7/11/02 11:03 AM Page 26

3-12
INSTRUMENT AND CONTROL FUNCTIONS
3
EAU00163
Rear brake leverBrake lever, rearThe rear brake lever is located on the
left handlebar grip. To apply the rear
brake, pull this lever toward the han-
dlebar grip.
1
1. Rear brake lever
5SJ-28199-E1 7/11/02 11:03 AM Page 27

3-13
EAU03631
ABSABSThe Yamaha ABS (Anti-lock Brake
System) features a dual electronic
control system, which acts on the
front and rear brakes independently.
The ABS securely controls wheel
lockup during emergency braking on
changing road surfaces and under
various weather conditions, thereby
maximizing tire adhesion and perfor-
mance while providing a smooth
braking action. The ABS is monitored
by an ECU (Electronic Control Unit),
which will have recourse to manual
braking if a malfunction occurs.
INSTRUMENT AND CONTROL FUNCTIONS
3
EW000020
w
8 8
The ABS performs best on
long braking distances.
8 8
On certain (rough or gravel)
roads, the braking distance
may be longer with than with-
out the ABS. Therefore, always
keep a sufficient distance to
the vehicle ahead to match the
riding speed.
NOTE:
8When the ABS is activated, the
brakes are operated in the usual
way. A pulsating action may be
felt at the brake levers, but this
does not indicate a malfunction.
8This ABS has a test mode which
allows the owner to experience
the pulsating at the brake levers
when the ABS is operating.
However, special tools are
required, so please consult your
Yamaha dealer when performing
this test.
5SJ-28199-E1 7/11/02 11:03 AM Page 28
