PERIODIC MAINTENANCE AND MINOR REPAIR
6 8Refill with the same type of brake
fluid. Mixing fluids may result in a
harmful chemical reaction and
lead to poor braking perfor-
mance.
8Be careful that water or dust
does not enter the brake fluid
reservoir when refilling. Water
will significantly lower the boiling
point of the fluid and may result
in vapor lock, and dirt may clog
the ABS hydraulic unit valves.
8Brake fluid may deteriorate paint-
ed surfaces or plastic parts.
Always clean up spilled fluid
immediately.
8As the brake pads wear, it is nor-
mal for the brake fluid level to
gradually go down. However, if
the brake fluid level goes down
suddenly, have a Yamaha dealer
check the cause.
EAU02962
Checking and lubricating the
cables
Cables, checking and lubricatingThe operation of all control cables
and the condition of the cables
should be checked before each ride,
and the cables and cable ends
should be lubricated if necessary. If
a cable is damaged or does not move
smoothly, have a Yamaha dealer
check or replace it.
EW000112
w
Damage to the outer sheath may
interfere with proper cable opera-
tion and will cause the inner cable
to rust. Replace a damaged cable
as soon as possible to prevent
unsafe conditions.
EAU03976
Changing the brake fluidBrake fluid, changingHave a Yamaha dealer change the
brake fluid at the intervals specified in
the NOTE after the periodic mainte-
nance and lubrication chart. In addi-
tion, have the oil seals of the master
cylinders and calipers as well as the
brake hoses replaced at the intervals
listed below or whenever they are
damaged or leaking.
8Oil seals: Replace every two
years.
8Brake hoses: Replace every four
years.Recommended lubricant:
Engine oil
5SJ-28199-E1 7/11/02 11:03 AM Page 79

6-31
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU04034
Checking and lubricating the
throttle grip and cable
Throttle grip and cable, checking and lubricatingThe operation of the throttle grip
should be checked before each ride.
In addition, the cable should be lubri-
cated or replaced at the intervals
specified in the periodic maintenance
chart.
EAU03371
Checking and lubricating the
centerstand and sidestand
Centerstand and sidestand, checking and lubricatingThe operation of the centerstand and
sidestand should be checked before
each ride, and the pivots and metal-
to-metal contact surfaces should be
lubricated if necessary.
EW000114
w
If the centerstand or sidestand
does not move up and down
smoothly, have a Yamaha dealer
check or repair it.
EAU03118
Lubricating the front and
rear brake levers
Brake levers, lubricatingThe pivoting points of the front and
rear brake levers must be lubricated
at the intervals specified in the peri-
odic maintenance and lubrication
chart.
Recommended lubricant:
Lithium-soap-based grease
(all-purpose grease)
Sidestand
5SJ-28199-E1 7/11/02 11:03 AM Page 80

6-32
PERIODIC MAINTENANCE AND MINOR REPAIR
6
To check the operation
1. Place the scooter on a level sur-
face and hold it in an upright
position.
2. While applying the front brake,
push down hard on the handle-
bars several times to check if the
front fork compresses and
rebounds smoothly.
EC000098
cC
If any damage is found or the front
fork does not operate smoothly,
have a Yamaha dealer check or
repair it.
EAU02939
Checking the front forkFront fork, checkingThe condition and operation of the
front fork must be checked as follows
at the intervals specified in the peri-
odic maintenance and lubrication
chart.
To check the condition
EW000115
w
Securely support the scooter so
that there is no danger of it falling
over.
Check the inner tubes for scratches,
damage and excessive oil leakage.
Centerstand
Recommended lubricant:
Lithium-soap-based grease
(all-purpose grease)
5SJ-28199-E1 7/11/02 11:03 AM Page 81

6-33
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU00794
Checking the steeringSteering, checkingWorn or loose steering bearings may
cause danger. Therefore, the opera-
tion of the steering must be checked
as follows at the intervals specified in
the periodic maintenance and lubrica-
tion chart.
1. Place a stand under the engine
to raise the front wheel off the
ground.
EW000115
w
Securely support the scooter so
that there is no danger of it falling
over.
EAU01144
Checking the wheel bearingsWheel bearings, checkingThe front and rear wheel bearings
must be checked at the intervals
specified in the periodic maintenance
and lubrication chart. If there is play
in the wheel hub or if the wheel does
not turn smoothly, have a Yamaha
dealer check the wheel bearings.
2. Hold the lower ends of the front
fork legs and try to move them
forward and backward. If any
free play can be felt, have a
Yamaha dealer check or repair
the steering.
5SJ-28199-E1 7/11/02 11:03 AM Page 82

6-34
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU04417
Removing the battery coverBattery cover removalThe battery cover needs to be
removed to access the battery, the
fuse box and the coolant reservoir
cap.
EAU01271
BatteryBatteryThis scooter is equipped with a
sealed-type (MF) battery, which does
not require any maintenance. There
is no need to check the electrolyte or
to add distilled water.
To charge the battery
Have a Yamaha dealer charge the
battery as soon as possible if it
seems to have discharged. Keep in
mind that the battery tends to dis-
charge more quickly if the scooter is
equipped with optional electrical
accessories.
1
1. Battery
To remove the battery cover, pull up
the right footboard mat as shown,
and then remove the screws and the
battery cover.
2
3
1
1. Right footboard mat
2. Screw (×2)
3. Battery cover
5SJ-28199-E1 7/11/02 11:03 AM Page 83

6-35
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EW000116
w
8 8
Electrolyte is poisonous and
dangerous since it contains
sulfuric acid, which causes
severe burns. Avoid any con-
tact with skin, eyes or clothing
and always shield your eyes
when working near batteries.
In case of contact, administer
the following FIRST AID.
9 9
EXTERNAL: Flush with
plenty of water.
9 9
INTERNAL: Drink large
quantities of water or milk
and immediately call a
physician.
9 9
EYES: Flush with water for
15 minutes and seek prompt
medical attention.To store the battery
1. If the scooter will not be used for
more than one month, remove
the battery, fully charge it, and
then place it in a cool, dry place.
2. If the battery will be stored for
more than two months, check it
at least once a month and fully
charge it if necessary.
3. Fully charge the battery before
installation. 8 8
Batteries produce explosive
hydrogen gas. Therefore, keep
sparks, flames, cigarettes,
etc., away from the battery and
provide sufficient ventilation
when charging it in an
enclosed space.
8 8
KEEP THIS AND ALL BATTER-
IES OUT OF THE REACH OF
CHILDREN.
5SJ-28199-E1 7/11/02 11:03 AM Page 84

6-36
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EC000102
cC
8
8
Always keep the battery
charged. Storing a discharged
battery can cause permanent
battery damage.
8 8
To charge a sealed-type (MF)
battery, a special (constant-
voltage) battery charger is
required. Using a conventional
battery charger will damage
the battery. If you do not have
access to a sealed-type (MF)
battery charger, have a
Yamaha dealer charge your
battery.
1. Turn the key to “OFF” and turn
off all electrical circuits.
2. Remove the blown fuse, and
then install a new fuse of the
specified amperage.
EC000103
cC
Do not use a fuse of a higher
amperage rating than recommend-
ed to avoid causing extensive
damage to the electrical system
and possibly a fire.
EAU04110*
Replacing the fusesFuses, replacingThe fuse boxes are located under the
battery cover. (See page 6-34 for bat-
tery cover removal and installation
procedures.)
If a fuse is blown, replace it as fol-
lows.
4
5
79
6
18
3
2
910
1. Main fuse
2. Backup fuse (clock)
3. ABS control unit fuse
4. Radiator fan fuse
5. Ignition fuse
6. Headlight fuse
7. Signaling system fuse
8. ABS motor fuse
9. Spare fuse (×5)
10. Spare main fuse
Specified fuses:
Main fuse: 30 A
Backup fuse (clock): 10 A
ABS control unit fuse: 10 A
Radiator fan fuse: 4 A
Ignition fuse: 7.5 A
Headlight fuse: 15 A
Signaling system fuse: 15 A
ABS motor fuse: 30 A
5SJ-28199-E1 7/11/02 11:03 AM Page 85

6-37
PERIODIC MAINTENANCE AND MINOR REPAIR
63. Turn the key to “ON” and turn on
the electrical circuit in question to
check if the device operates.
4. If the fuse immediately blows
again, have a Yamaha dealer
check the electrical system.
3. Disconnect the headlight cou-
pler, and then remove the bulb
cover.
1
2
1. Headlight coupler
2. Bulb cover
EAU04128
Replacing a headlight bulbHeadlight bulb, replacingThis scooter is equipped with quartz
bulb headlights. If a headlight bulb
burns out, replace it as follows.
1. Place the scooter on the center-
stand.
2. Remove panel A. (See page
6-11 for panel removal and
installation procedures.)
5SJ-28199-E1 7/11/02 11:03 AM Page 86

6-38
PERIODIC MAINTENANCE AND MINOR REPAIR
6 4. Unhook the headlight bulb hold-
er, and then remove the defec-
tive bulb.EW000119
w
Headlight bulbs get very hot.
Therefore, keep flammable prod-
ucts away from a lit headlight bulb,
and do not touch the bulb until it
has cooled down.
1
1. Headlight bulb holder
EC000105
cC
Do not touch the glass part of the
headlight bulb to keep it free from
oil, otherwise the transparency of
the glass, the luminosity of the
bulb, and the bulb life will be
adversely affected. Thoroughly
clean off any dirt and fingerprints
on the headlight bulb using a cloth
moistened with alcohol or thinner.
6. Install the headlight bulb cover,
and then connect the coupler.
a
a. Do not touch the glass part of the bulb.
5. Place a new headlight bulb into
position, and then secure it with
the bulb holder.
5SJ-28199-E1 7/11/02 11:03 AM Page 87

6-39
PERIODIC MAINTENANCE AND MINOR REPAIR
67. Install the panel.
8. Have a Yamaha dealer adjust
the headlight beam if necessary.
3. Remove the socket (together
with the turn signal light bulb) by
turning it counterclockwise.
4. Remove the defective bulb by
pushing it in and turning it coun-
terclockwise.
5. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
6. Install the socket (together with
the bulb) by turning it clockwise.
7. Install the panel.
1
1. Socket
EAU03111
Replacing a front turn signal
light bulb
Turn signal light bulb (front), replacing1. Place the scooter on the center-
stand.
2. Remove panel A. (See page
6-11 for panel removal and
installation procedures.)
