SCOOTER CARE AND STORAGE
EAU37834
Matte color cautionNOTICE
ECA15193
Some models are equipped with
matte colored finished parts. Be
sure to consult a Yamaha dealer for
advice on what products to use be-
fore cleaning the vehicle. Using a
brush, harsh chemical products or
cleaning compounds when cleaning
these parts will scratch or damage
their surface. Wax also should not
be applied to any matte colored fin-ished parts.
EAU26096
CareWhile the open design of a scooter re-
veals the attractiveness of the technol-
ogy, it also makes it more vulnerable.
Rust and corrosion can develop even if
high-quality components are used. A
rusty exhaust pipe may go unnoticed
on a car, however, it detracts from the
overall appearance of a scooter. Fre-
quent and proper care does not only
comply with the terms of the warranty,
but it will also keep your scooter looking
good, extend its life and optimize its
performance.
Before cleaning1. Cover the muffler outlet with a plastic bag after the engine has
cooled down.
2. Make sure that all caps and covers as well as all el ectrical couplers
and connectors, including the
spark plug cap, are tightly in-
stalled.
3. Remove extremely stubborn dirt, like oil burnt onto the crankcase,
with a degreasing agent and a
brush, but never apply such prod- ucts onto seals, gaskets and wheel
axles. Always rinse the dirt and de-
greaser off with water.
Cleaning
NOTICE
ECA10784

Avoid using strong acidic wheel
cleaners, especially on spoked
wheels. If such products are
used on hard-to-remove dirt, do
not leave the cleaner on the af-
fected area any longer than in-
structed. Also, thoroughly rinse
the area off with water, immedi-
ately dry it, and then apply a cor-
rosion protection spray.

Improper cleaning can damage
plastic parts (such as cowlings,
panels, windshields, headlight
lenses, meter lenses, etc.) and
the mufflers. Use only a soft,
clean cloth or sponge with wa-
ter to clean plastic. However, if
the plastic parts cannot be thor-
oughly cleaned with water, di-
luted mild detergent with water
may be used. Be sure to rinse
off any detergent residue using



SCOOTER CARE AND STORAGE
7-2
1
2
3
4
5
67
8
9plenty of water, as it is harmful
to plastic parts.

Do not use any harsh chemical
products on plastic parts. Be
sure to avoid using cloths or
sponges which have been in
contact with strong or abrasive
cleaning products, solvent or
thinner, fuel (gasoline), rust re-
movers or inhibitors, brake flu-
id, antifreeze or electrolyte.

Do not use high-pressure wash-
ers or steam-jet cleaners since
they cause water seepage and
deterioration in the following ar-
eas: seals (of wheel and swing-
arm bearings, fork and brakes),
electric components (couplers,
connectors, instruments,
switches and lights), breather
hoses and vents.

For scooters equipped with a
windshield: Do not use strong
cleaners or hard sponges as
they will cause dulling or
scratching. Some cleaning com-
pounds for plastic may leave
scratches on the windshield.
Test the product on a small hid- den part of the windshield to
make sure that it does not leave
any marks. If the windshield is
scratched, use a quality plastic
polishing compound after
washing.
After normal use
Remove dirt with warm water, a mild
detergent, and a soft, clean sponge,
and then rinse thoroughly with clean
water. Use a toothbrush or bottlebrush
for hard-to-reach areas. Stubborn dirt
and insects will come off more easily if
the area is covered with a wet cloth for
a few minutes before cleaning.
After riding in the rain, near the sea oron salt-sprayed roadsSince sea salt or salt sprayed on the
roads during winter are extremely cor-
rosive in combination with water, carry
out the following steps after each ride in
the rain, near the sea or on
salt-sprayed roads.TIPSalt sprayed on roads in the winter may
remain well into spring. 1. Clean the scooter with cold water and a mild detergent after the en-
gine has cooled down. NOTICE:
Do not use warm water since it
increases the corrosive action
of the salt.
[ECA10792]
2. Apply a corrosion protection spray on all metal, including chrome- and
nickel-plated, surfaces to prevent
corrosion.
Cleaning the windshieldAvoid using any alkaline or strong acid
cleaner, gasoline, brake fluid, or any
other solvent. Clean the windshield with
a cloth or sponge dampened with a mild
detergent, and then wash it off thor-
oughly with water. For additional clean-
ing, use Yamaha Windshield Cleaner
or another high-quality windshield
cleaner. Some cleaning compounds for
plastics may leave scratches on the
windshield. Before using such clean-
ers, test an area of the windshield
which does not affect your visibility and
which cannot be easily recognized.



SCOOTER CARE AND STORAGE
7-3
2
3
4
5
678
9
After cleaning
1. Dry the scooter with a chamois or an absorbing cloth.
2. Use a chrome polish to shine chrome, aluminum and stain-
less-steel parts, including the ex-
haust system. (Even the thermally
induced discoloring of stain-
less-steel exhaust systems can be
removed through polishing.)
3. To prevent corrosion, it is recom- mended to apply a corrosion pro-
tection spray on all metal,
including chrome- and nickel-plat-
ed, surfaces.
4. Use spray oil as a universal clean- er to remove any remaining dirt.
5. Touch up minor paint damage caused by stones, etc.
6. Wax all painted surfaces.
7. Let the scooter dry completely be- fore storing or covering it.
WARNING
EWA10943
Contaminants on the brakes or tires
can cause loss of control.
Make sure that there is no oil or
wax on the brakes or tires. If
necessary, clean the brake discs and brake linings with a
regular brake disc cleaner or ac-
etone, and wash the tires with
warm water and a mild deter-
gent.

Before operating the scooter
test its braking performanceand cornering behavior.
NOTICE
ECA10801

Apply spray oil and wax spar-
ingly and make sure to wipe off
any excess.

Never apply oil or wax to any
rubber and plastic parts, but
treat them with a suitable care
product.

Avoid using abrasive polishing
compounds as they will wearaway the paint.
TIP
Consult a Yamaha dealer for ad-
vice on what products to use.

Washing, rainy weather or humid
climates can cause the headlight
lens to fog. Turning the headlight
on for a short period of time will
help remove the moisture from the
lens.



SCOOTER CARE AND STORAGE
7-4
1
2
3
4
5
67
8
9
EAU36564
StorageShort-term
Always store your scooter in a cool, dry
place and, if necessary, protect it
against dust with a porous cover. Be
sure the engine and the exhaust sys-
tem are cool before covering the scoot-
er.NOTICE
ECA10821

Storing the scooter in a poorly
ventilated room or covering it
with a tarp, while it is still wet,
will allow water and humidity to
seep in and cause rust.

To prevent corrosion, avoid
damp cellars, stables (because
of the presence of ammonia)
and areas where strong chemi-cals are stored.
Long-term
Before storing your scooter for several
months: 1. Follow all the instructions in the “Care” section of this chapter. 2. Fill up the fuel tank and add fuel
stabilizer (if available) to prevent
the fuel tank from rusting and the
fuel from deteriorating.
3. Perform the following steps to pro- tect the cylinder, piston rings, etc.
from corrosion.
a. Remove the spark plug cap and spark plug.
b. Pour a teaspoonful of engine oil into the spark plug bore.
c. Install the spark plug cap onto the spark plug, and then place
the spark plug on the cylinder
head so that the electrodes are
grounded. (This will limit spark-
ing during the next step.)
d. Turn the engine over several times with the starter. (This will
coat the cylinder wall with oil.)
e. Remove the spark plug cap from the spark plug, and then
install the spark plug and the
spark plug cap. WARNING! To
prevent damage or injury
from sparking, make sure to
ground the spark plug elec-
trodes while turning the en-
gine over.
[EWA10952]
4. Lubricate all control cables and the pivoting points of all levers and
pedals as well as of the sidestand/
centerstand.
5. Check and, if necessary, correct the tire air pressure, and then lift
the scooter so that both of its
wheels are off the ground. Alterna-
tively, turn the wheels a little every
month in order to prevent the tires
from becoming degraded in one
spot.
6. Cover the muffler outlet with a plastic bag to prevent moisture
from entering it.
7. Remove the battery and fully charge it. Store it in a cool, dry
place and charge it once a month.
Do not store the battery in an ex-
cessively cold or warm place [less
than 0 ° C (30 °F) or more than 30
° C (90 °F)]. For more information
on storing the battery, see page
6-25.TIPMake any necessary repairs beforestoring the scooter.



8-1
2
3
4
5
6
789
SPECIFICATIONS
EAU5091K
Dimensions:Overall length:2030 mm (79.9 in)
Overall width: 715 mm (28.1 in)
Overall height: 1295 mm (51.0 in)
Seat height:
795 mm (31.3 in)
Wheelbase: 1405 mm (55.3 in)
Ground clearance: 93 mm (3.66 in)
Minimum turning radius:
2100 mm (82.7 in)Weight:Curb weight:148 kg (326 lb)Engine:Engine type:Liquid cooled 4-stroke, SOHC
Cylinder arrangement: Single cylinder
Displacement:
125 cm
3
Bore × stroke:
52.0 × 58.7 mm (2.05 × 2.31 in)
Compression ratio: 11.0 : 1
Starting system:
Electric starter
Lubrication system: Wet sump
Engine oil:Type:
SAE 10W-40
Recommended engine oil grade: API service SG type or higher, JASO stan-
dard MA or MB
*Engine oil quantity: Periodic oil change:
0.95 L (1.00 US qt, 0.84 Imp.qt)Final transmission oil:Type:SAE 10W-30 type SE motor oil
Quantity:
0.20 L (0.21 US qt, 0.18 Imp.qt)Cooling system:Coolant reservoir capacity (up to the maxi-
mum level mark):0.25 L (0.26 US qt, 0.22 Imp.qt)
Radiator capacity (including all routes): 0.56 L (0.59 US qt, 0.49 Imp.qt)
Air filter:Air filter element:Oil-coated paper elementFuel:Recommended fuel:Regular unleaded gasoline
Fuel tank capacity:
7.4 L (1.96 US gal, 1.63 Imp.gal)Fuel injection:*Throttle body:ID mark:52S1 01Spark plug(s):Manufacturer/model:
NGK / CPR8EA
Spark plug gap: 0.8–0.9 mm (0.031–0.035 in)Clutch:Clutch type:
Dry, centrifugal automaticTransmission:Primary reduction ratio:1.000
Final drive:
Gear
Secondary reduction ratio: 8.787 (45 / 13 × 33 / 13)
Transmission type: V-belt automaticChassis:Frame type:Backbone
Caster angle: 26.00 °
–20 –10 0 1020 30 40 50 C
10 30 50 70 90 110
0 130 F
SAE 10W-30
SAE 15W-40SAE 20W-40SAE 20W-50
SAE 10W-40SAE 10W-50



SPECIFICATIONS
8-2
1
2
3
4
5
6
78
9
Trail:82 mm (3.2 in)Front tire:Type:Tubeless
Size: 120 / 70 - 13 M/C 53P
Manufacturer/model:
KENDA / K703FRear tire:Type:Tubeless
Size:
130 / 70 - 13 M/C 57P
Manufacturer/model: KENDA / K703Loading:Maximum load:
160 kg (353 lb)
* (Total weight of rider, passenger, cargo and accessories)Tire air pressure (measured on cold
tires):Loading condition:90 kg (198 lb)
Front:
200 kPa (2.00 kgf/cm
2, 29 psi)
Rear:
200 kPa (2.00 kgf/cm2, 29 psi)
Loading condition: 90 kg - maximum load
Front:
200 kPa (2.00 kgf/cm2, 29 psi) Rear:
225 kPa (2.25 kgf/cm
2, 33 psi)
Front wheel:Wheel type:Cast wheel
Rim size: J 13 × MT3.00Rear wheel:Wheel type:Cast wheel
Rim size: J 13 × MT3.5Front brake:Type:Single disc brake
Operation: Right hand operation
Specified brake fluid:
DOT 4Rear brake:Type:Single disc brake
Operation:
Left hand operation
Specified brake fluid: DOT 4Front suspension:Type:
Telescopic fork
Spring/shock absorber type: Coil spring/oil damper
Wheel travel: 79 mm (3.1 in)
Rear suspension:Type: Swingarm
Spring/shock absorber type: Coil spring/oil damper
Wheel travel: 93 mm (3.7 in)Electrical system:Ignition system:TCI
Charging system: AC magnetoBattery:Model:GT7B-4
Voltage, capacity: 12 V, 6.5 AhHeadlight:Bulb type:Halogen bulbBulb voltage, wattage × quantity:Headlight:
12 V, 60.0 W/55.0 W × 1
Tail/brake light: LED
Front turn signal light: 12 V, 10.0 W × 2
Rear turn signal light:
12 V, 10.0 W × 2
Auxiliary light: LED
License plate light: 12 V, 5.0 W × 1



SPECIFICATIONS
8-3
2
3
4
5
6
789
Meter lighting:LED
High beam indicator light:
LED
Turn signal indicator light: LED
Coolant temperature warning light: LED
Engine trouble warning light:
LEDFuses:Main fuse:20.0 A
Signaling system fuse:
7.5 A× 2
Ignition fuse: 7.5 A
Backup fuse: 7.5 A



9-1
1
2
3
4
5
6
7
89
CONSUMER INFORMATION
EAU53562
Identification numbersRecord the vehicle identification num-
ber, engine serial number, and the
model label information in the spaces
provided below. These identification
numbers are needed when registering
the vehicle with the authorities in your
area and when ordering spare parts
from a Yamaha dealer.
VEHICLE IDENTIFICATION NUM-
BER:
ENGINE SERIAL NUMBER:
MODEL LABEL INFORMATION:
EAU26411
Vehicle identification number
The vehicle identification number is
stamped into the frame.TIPThe vehicle identification number is
used to identify your vehicle and may
be used to register it with the licensingauthority in your area.
EAU26441
Engine serial number
The engine serial number is stamped
into the crankcase.
EAU26501
Model label
1. Vehicle identification number
1
1. Engine serial number
1. Model label
1
1



CONSUMER INFORMATION
9-2
2
3
4
5
6
7
89
The model label is affixed to the inside
of the rear storage compartment. (See
page 3-12.) Record the information on
this label in the space provided. This in-
formation will be needed when ordering
spare parts from a Yamaha dealer.



INDEXAAcceleration and deceleration....................5-2
Air filter and V-belt case air filter
elements ................................................6-15
Auxiliary light ............................................6-30BBattery......................................................6-25
Brake fluid, changing ...............................6-22
Brake fluid level, checking .......................6-21
Brake lever, front........................................3-7
Brake lever, rear ........................................3-7
Brake levers, lubricating...........................6-23
Braking .......................................................5-3CCables, checking and lubricating .............6-22
Care ...........................................................7-1
Catalytic converter ...................................3-10
Centerstand and sidestand, checking and
lubricating ..............................................6-23
Coolant.....................................................6-13
Coolant temperature warning light .............3-3DDimmer switch ...........................................3-7EEngine break-in ..........................................5-3
Engine idling speed, checking .................6-16
Engine oil .................................................6-10
Engine serial number .................................9-1
Engine trouble warning light.......................3-3FFinal transmission oil ...............................6-12
Front and rear brak e lever free play,
checking ................................................6-20
Front and rear brake pads, checking .......6-20 Front fork, checking ................................. 6-24
Front turn signal light ............................... 6-28
Fuel............................................................ 3-8
Fuel consumption, tips
for reducing........... 5-3
Fuel gauge................................................. 3-4
Fuel tank breather hose and overflow hose ........................................................ 3-9
Fuel tank cap ............................................. 3-8
Fuses, replacing ...................................... 6-27
HHandlebar switches ................................... 3-6
Headlight bulb, replacing ......................... 6-28
Helmet holder .......................................... 3-11
High beam indicator light ........................... 3-2
Horn switch ................................................ 3-7IIdentification numbers ............................... 9-1
Ignition circuit cut-off system ................... 3-15
Indicator lights and warning lights ............. 3-2KKeyhole cover ............................................ 3-2LLicense plate light bulb, replacing ........... 6-30
Luggage hook .......................................... 3-14MMain switch/steering lock........................... 3-1
Maintenance and lubrication, periodic ....... 6-5
Maintenance, emission control system...... 6-4
Matte color, caution ................................... 7-1
Model label ................................................ 9-1
Multi-function display ................................. 3-4PPanels, removing and installing ................. 6-8
Parking ...................................................... 5-4 Part locations ............................................ 2-1
Passenger footrest .................................. 3-11
Pass switch ............................................... 3-7
SSafe-riding points ...................................... 1-5
Safety information ..................................... 1-1
Seat ......................................................... 3-10
Shock absorber assembly ....................... 3-13
Sidestand ................................................ 3-14
Spark plug, checking ................................. 6-9
Specifications ............................................ 8-1
Starting off ................................................. 5-2
Starting the engine .................................... 5-1
Start switch................................................ 3-7
Steering, checking................................... 6-25
Storage...................................................... 7-4
Storage compartments ............................ 3-12TTachometer ............................................... 3-3
Tail/brake light ......................................... 6-28
Throttle grip and cable, checking and
lubricating ............................................. 6-22
Throttle grip free play, checking .............. 6-17
Tires ........................................................ 6-17
Tool kit....................................................... 6-2
Troubleshooting ...................................... 6-30
Troubleshooting charts............................ 6-32
Turn signal indicator lights ........................ 3-2
Turn signal light bulb (rear), replacing..... 6-29
Turn signal switch ..................................... 3-7VValve clearance....................................... 6-17
Vehicle identification number .................... 9-1
